- Page 1 PRIMERGY 400 SERVER PRIMERGY 400 SERVER PRIMERGY 400 SERVER PRIMERGY 400 SERVER TOWER SERVER ↔ RACK SERVER UMRÜSTANLEITUNG UMRÜSTANLEITUNG UMRÜSTANLEITUNG UMRÜSTANLEITUNG CONVERSION GUIDE CONVERSION GUIDE CONVERSION GUIDE CONVERSION GUIDE...
- Page 2 Sie haben ..technische Fragen oder Probleme? Wenden Sie sich bitte an: • einen unserer Servicepartner • Ihren zuständigen Vertriebspartner • Ihre Verkaufsstelle Die Adressen Ihrer Servicepartner finden Sie im Garantieheft oder im Service-Adressenheft. Aktuelle Informationen zu unseren Produkten, Tips, Updates usw. finden Sie im Internet: http://www.fujitsu-siemens.com Is there ...
- Page 4 Este manual ha sido impreso sobre papel reciclado. Questo manuale è stato stampato su carta da riciclaggio. Denna handbok är tryckt på recyclingpapper. Dit handboek werd op recycling-papier gedrukt. Herausgegeben von/Published by Fujitsu Siemens Computers GmbH A26361-K482-Z121-2-7419 A26361-K482-Z121-2-7419 A26361-K482-Z121-2-7419 A26361-K482-Z121-2-7419 Bestell-Nr./Order No.:...
- Page 5 Einleitung Umrüstung Tower-Server in Rack-Server PRIMERGY 400 SERVER Umrüstung Rack-Server in Tower-Server TOWER-SERVER ↔ RACK-SERVER UMRÜSTANLEITUNG Ausgabe Mai 2000...
- Page 6 Alle genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt. Copyright ã Fujitsu Siemens Computers GmbH 2000 Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
-
Page 7: Table Of Contents
Contents Introduction .............................1 Notational conventions ........................1 Important notes ..........................2 Converting a tower server into a rack server ................3 Checking the contents of delivery ......................3 Modifying the tower server.........................5 Converting rack server to tower server ..................19 Checking the contents of delivery .................... -
Page 9: Introduction
Introduction The two casing variants for PRIMERGY 400 servers offer great flexibility. The option of a subsequent conversion to the alternate casing offers still greater flexibility and security against obsolescence. These instructions describe the steps necessary to change from tower server to rack server and vice versa. -
Page 10: Important Notes
Introduction Important notes You should also observe the safety notes in the operating manual for your server or your memory expansion unit. Boards with electrostatic sensitive devices (ESD) may be identified by labels. When you handle boards fitted with ESDs, you must observe the following points under all circumstances: •... -
Page 11: Converting A Tower Server Into A Rack Server
Converting a tower server into a rack server This chapter describes how to convert a tower server into a rack server. Checking the contents of delivery The shipment comprises a conversion kit for the rack server and the installation kit for the rack. Ê... - Page 12 Converting a tower server into a rack server Installation kit for the rack • 2 extending rails with carrier rails (left and right) • 1 Articulated cable carrier assembly (mounting base, angled mounting brackets, locking and mounting bars) 1 cable chain assembly (chain, 2 angled mounting brackets) From the rack assembly set you require: •...
-
Page 13: Modifying The Tower Server
Converting a tower server into a rack server Modifying the tower server Please take note of the safety information in the section "Important notes". Ê Switch the server off. Pull the power plug out of the power outlet! Ê Disconnect all cables from the back of the server. Ê... - Page 14 Converting a tower server into a rack server Ê Tilt the side cover (1) and remove it (2). Ê Press in the securing clips on the underside of the upper part of the casing (1), and push it backwards as far as possible (2) and then remove it (3). 6 - English A26361-K482-Z121-2-7419...
- Page 15 Converting a tower server into a rack server Ê Remove the service compartment. Ê Lever the two plastic guides for the service compartment out of the casing with a suitable tool (e.g. screwdriver) (1 + 2). English - 7 A26361-K482-Z121-2-7419...
- Page 16 Converting a tower server into a rack server Ê Press the two retaining clips of the control panel trim plate downward (1), fold out the control panel trim plate (2) and remove it (3). Ê Pull the cables from all the installed accessible 5 ¼-inch drives. Ê...
- Page 17 Converting a tower server into a rack server Drive in lower slot Ê Remove the two knurled screws on the left-hand side (1), and remove the drive from the slot (2). Drive in middle and upper slot Ê Remove the right-hand side cover. Ê...
- Page 18 Converting a tower server into a rack server Ê Lay the bottom tray on the table with the open side facing up if the bottom tray has an open rear side, and lay the bottom tray on the table with the open side facing down if the bottom tray has a closed rear side.
- Page 19 Converting a tower server into a rack server Ê Mount the spacer strip for the front panel at the bottom of the front (1). The stamped shape (a) on the spacer strip is important. This shape must fit into the recess in the casing. Ê...
- Page 20 Converting a tower server into a rack server Ê Align the server on the bottom tray and screw the front panel securely to the spacer strip with two countersunk screws (1). Ê Now screw the front panel to the spacer strip at the top, with three countersunk screws (1). 12 - English A26361-K482-Z121-2-7419...
- Page 21 Converting a tower server into a rack server Depending on the design of the bottom tray (open or closed at rear) and the planned cable routing (articulated cable carrier or cable chain), there are three different versions for fixing the server to the bottom tray at the back: Ê...
- Page 22 Converting a tower server into a rack server Ê If the bottom tray is open at the rear and you want to use the cable chain for cable routing, then use the narrow bottom angle piece shown and two Torx M5 screws (1) and one Torx M4 screws (2) to fix the server to the bottom tray at the rear.
- Page 23 Converting a tower server into a rack server CD RO M A uto Loader Ê Insert the externally-accessible drives previously removed into the new cage (1), and secure with screws on both sides (2). Ensure when assembling that the stamped shapes with hole (a) on the brackets are at the top.
- Page 24 Converting a tower server into a rack server Ê Insert the ready-assembled drive cage for 2/3 in the casing (1), and connect the cables to the corresponding drive. Ê Insert the drive cage completely into the server (1) and fasten it using four Torx-M3 screws (2). Ê...
- Page 25 Converting a tower server into a rack server Ê Mount the control panel trim plate into the front panel (1 + 2). Make sure that the retaining clips of the control panel trim plate engage in the front panel. Ê Insert the cover (beforehand the left-hand side cover) in the casing on the left-hand side (1), slide it forward as far as possible (2) and fold it down at the right (3).
- Page 26 Converting a tower server into a rack server Ê Slide the cover back as far as possible (1) and screw it in place behind the front panel (between front panel and casing), using the knurled screw you removed before (2). Ê...
-
Page 27: Converting Rack Server To Tower Server
Check whether the delivery agrees with the details in the delivery note. Should you discover that the delivery does not correspond to the delivery note, notify your supplier immediately. Conversion kit PRIMERGY 400 rack server to tower server • 1 Door •... -
Page 28: Converting The Rack Server
Converting rack server to tower server Converting the rack server Please take note of the safety information in the section "Important notes". Ê Switch the server off. Pull the power plug out of the power outlet! Ê Disconnect all cables from the back of the server. Ê... - Page 29 Converting rack server to tower server Ê With a cable chain, release the bayonet latch on the fixing angle piece (1) and take the cable chain out of the anchor on the bottom tray (2). Ê Release the four knurled screws (1) and withdraw the server from the rack as far as it will go (2).
- Page 30 Converting rack server to tower server If you need to lift or transport the server, ask someone to help you. Ê Press sideways on the locking spring (1), and remove the server from the rack (2). Ê Put the server onto a table. Ê...
- Page 31 Converting rack server to tower server Ê Lift the cover on the right-hand side (1) and remove it (2). Ê Press the two retaining clips of the control panel trim plate behind the front panel firmly downward (1), fold out the control panel trim plate (2) and remove it (3). English - 23 A26361-K482-Z121-2-7419...
- Page 32 Converting rack server to tower server Ê Remove the four screws from the top of the drive cage (1), and remove the drive cage 1/3 from the casing (2). Ê Pull the cables from the accessible drives installed in the drive carrier. Ê...
- Page 33 Converting rack server to tower server Ê Remove the three spacer angle pieces (1) and the spacer strip (2) on the front. Ê Remove the screw (1) to detach the server from the bottom tray at the rear and lift the server down out of the bottom tray (2).
- Page 34 Converting rack server to tower server Ê Lay the server on its right-hand side, and fasten both feet (1). Ê Place the server in an upright position. Ê Remove the screws that attach the accessible drives to the drive carrier (1) and take the drives out of the carrier (2).
- Page 35 Converting rack server to tower server Ê Reinstall the drives previously removed in the server (1). You do not need the drive cage that contained the drives in the rack variant. Drive in lower slot Ê Fix the drive in position on the left-hand side, using two knurled screws (2). Ê...
- Page 36 Converting rack server to tower server Ê Install the EMC spring supplied at the top of the casing (1). Ê Install one of the EMC covers supplied in each free drive slot (2). Ê Mount the inserts from the "old" control panel trim plate in the new control panel trim plate as per the position of the externally-accessible drives installed (1).
- Page 37 Converting rack server to tower server Ê Insert the two plastic guides for the service compartment up into the corresponding holes in the casing (1 + 2). Ê Locate the service compartment in the plastic guides. English - 29 A26361-K482-Z121-2-7419...
- Page 38 Converting rack server to tower server Ê Locate the upper part of the casing slightly offset to the rear (1), and push it forward as far as possible (2). The top cover must engage in the casing. Ê Fit the side cover into the recesses in the casing (1), and tip it upwards onto the casing (2). 30 - English A26361-K482-Z121-2-7419...
- Page 39 Converting rack server to tower server Ê Slide the side cover back as far as possible (1) and screw it in place with the knurled screw you removed before (2). Ê Install the door (1 + 2), and close if appropriate (3). English - 31 A26361-K482-Z121-2-7419...
- Page 40 Copyright Fujitsu Technology Solutions, 2009 Hinweise zum vorliegenden Dokument Zum 1. April 2009 ist Fujitsu Siemens Computers in den alleinigen Besitz von Fujitsu übergegangen. Diese neue Tochtergesellschaft von Fujitsu trägt seit- dem den Namen Fujitsu Technology Solutions.
