Installing The Stand - Samsung PN51E550 User Manual

Stand Parts:
A
Stand x 1
Follow the steps below to connect the TV to the stand. For more detailed instructions, see the separate
stand installation guide.
1
2
C x4 (M4 X L12)
B
A
Rear
4 Side View
5
[PE550-ZC]BN68-04071B-X0L02.indb 5

Installing the Stand

B
Guide Stand x 1
Top View
Front
ATTENTION
DO NOT USE DO NOT USE DO NOT
CHEMICALS GREASE USE OIL
(Correct assembly)
English - 5
C
3
✎
Place a soft cloth over a table to protect the TV, and then
place the TV on the cloth screen side down.
✎
Insert the Stand Guide into the slot on the TV's bottom.
(Incorrect assembly)
C
(M4 X L12)
Screws x 8
x4 (M4 X L12)
