User's Manual
Please visit the website(www.navinc.co.kr) to get information of latest firmware and dedicated viewer.
Product specification and function can be changed in order to improve performance of the product without notice.
Read user's manual carefully in order to protect the user's safety and ensure the accurate use of the product.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for JAEWONCNC IROAD IONE-900HD
Summary of Contents for JAEWONCNC IROAD IONE-900HD
- Page 1 User’s Manual Please visit the website(www.navinc.co.kr) to get information of latest firmware and dedicated viewer. Product specification and function can be changed in order to improve performance of the product without notice. Read user’s manual carefully in order to protect the user’s safety and ensure the accurate use of the product.
-
Page 2: Table Of Contents
Contents Before using this product Warranty and Limitation of Liability Precaution Product Features Name of Each Part Buttons Product Package Optional Product Product Specification Additional Functions Storage / Capacity How to install SD Card Format Third-Party Video Player Main Functions Dedicated Viewer Product Warranty Card... -
Page 3: Before Using This Product .2
Warranty and Limitation of Liability JAEWONCNC Inc. is not liable for any problems caused by violating the statements written in the this manual - JAEWONCNC is not liable for the product malfunction, loss of data and any damages incurred... -
Page 4: Precaution
3. Precaution SD CARD Make sure that the power cable should be plugged off and LED should be turned off before inserting or removing the SD memory card in order to check the saved data in the SD card - Do not disassemble the SD card by force, it can cause the damage to the product - Do not disconnect the SD card while the product activates, it can cause data corruption and damage of the SD card - Be advised to keep the SD card with the card case when you keep or move it, otherwise data can... - Page 5 Please make sure follow guidelines below, otherwise it can cause damage of the SD card or fires It is highly recommended to use the SD card which is designated by JAEWONCNC Make sure to prevent IONE-290V from malfunctioning by staying under the shelter to escape direct light as the interal temperature of vehicle can jump up in summer season Do not try to control the product while driving.
-
Page 6: Product Features
5. Product Features MOTiON Automatic Motion Detection The parking mode is changed into the Motion Detection Mode in 20 minutes if no movement is detected by the sensor. Recorded data files are saved in the park directory Recording 10 seconds before and 20 seconds after motion detect This function can be operated with using the uninterrupted power cable PARKING... - Page 7 Product Features .6 SMART Simple Smartphone Playback Wherever simply check the recordings from smartphone(Android). there are also various ways to check the video file Uninterrupted Recording and Event Recording - Continuous Recording : Every 60 seconds recording - Event Recording : Separately save video recordings in the event folder when it detects Voice Recording Playback video recordings and sound at the same time...
-
Page 8: Name Of Each Part
7. Name of Each Part Cradle/ Adhesive Tape Security LED Camera V-Out Power SD Card Slot GPS(Option) EVENT Button MODE Button GPS LED REC LED... -
Page 9: Buttons
Button/LED .8... -
Page 10: Product Package
AV Cable Power Cable Apart from the Main unit, MicroSD, SD card reader are contained that JAEWONCNC is not liable for After-Service (SD card and Micro SD card Reader could be exchanged within 14days of purchase in case of malfunctioning) - Page 11 11. Specification Resolution 640 X 480 (VGA) Video Frames 20~30 Frame/sec (VFR) Video Format MPEG4 Support Memory Micro SD 4GB~32GB(Class 4 or higher) Recording Time Event 30 seconds(Impact before 10 sec/ after 20sec) /Continuous variable format rate recording Buttons EVENT(Manual recording/SD format), MODE(Mute/Parking) Video Angle View angle 130˚...
-
Page 12: Additional Functions .12
Additional Functions .12 A/V OUT Watch the real-time recording video by connecting with external device The size of AV input port could be different by different models of navigation system Simple Buttons EVENT (EVENT / SD Card Format) - Short press the “EVENT “ button that records manually as event happened - Press ”EVENT“... -
Page 13: Storage / Capacity
13. Storage / Capacity Connect the microSD Card which saves the recorded Video files into Smart Phone or PC. There are three different folders and the explanations for each folder follow as below Video Recording Length on each Micro SD Card 60 seconds 60 seconds 240 seconds... - Page 14 The right way to maintain SD Card .14 The right way to maintain SD Card prevent errors on the SD Card, it's also the way to use SD Card longer 1. Format SD Card regularly By the particular feature of SD Memory, It highly recommend to format regularly per every 1 week in order to prevent memory errors and it makes the lifetime of SD Card longer Simply format SD Card when you press "EVENT"...
-
Page 15: Sd Card Format
15. SD Card Format... - Page 16 SD Card Format .16...
-
Page 17: Third-Party Video Player
17. Third-Party Video Player Player and Codec installation Visity Gom player or VLC player download website, you can free download - Gom Player download : http://player.gomlab.com/eng/download - VLC Player download : http://www.videolan.org/vlc/index.html GOM PLAYER Gom Player download : http://player.gomlab.com/eng/download VLC PLAYER VLC Player download : http://www.videolan.org/vlc/index.html You might need to download integrated codec after installing video player You can also playback with other video player like Quick time Player... -
Page 18: Main Functions .18
Main Functions .18 Smartphone Playback Easy playback the recorded files on the SD card with smartphone or various digital media devices One-Touch Format Easy format the SD card by the one-touch format function without remove SD car from the device - Press “EVENT”... -
Page 19: Dedicated Viewer
19. Dedicated Viewer PLAYBACK (1) Map On/Off, Screen Capture, Print, Video Convert, Setting, Program Information, Minimize, Exit (2) Folder : Select the path Where video data recorded (3) Recording order : Asending or Descending (4) Recording list: List up recording files (5) Memo function : Create new memo and update (This function is only activated while playback) (6) Speedmeter : Display driving speed... - Page 20 Dedicated Viewer .20 PLAYBACK Previous/Previous bookmark/5 Seconds back/Play or Pause/5 Seconds forward/Next bookmark/Next (1) Playback Speed : [-] Slow/ [1X] Normal/ [+] Fast (2) Playback Searching Bar : Display playback section mark (3) Bookmark : Set or Delete bookmark (4) Playback Control Panel : - Previous : Playback the previous recording from the recording list - Previous bookmark : Go to previous bookmark if there is previous bookmark - 5 Seconds back : Go to 5 seconds back from current playback time...
- Page 21 21. Dedicated Viewer PLAY Function <Activate MAP> (1) The map appears when you click this icon (2) The location is displayed on the map (3) Map scroll On/Off (4) Normal/Satellite map swiching (5) Map screen:[+]Enlargement / [-]Reduction The map is appeared only if there is the stable internet connection The map service is available when you purchase optional GPS device...
-
Page 22: Product Warranty Card
Dealer (Market) : Thank you for purchasing IROAD IONE-900HD, Vehicle Black-box. JAEWONCNC warrants the product to be free from defects in materials and workmanship pursuant to terms and conditions of consumer injury compensation rules as follows. • Be advised to contact with the agent or sales representative when you find any defects of your product. - Page 23 JAEWONCNC Co.,Ltd 132-24 Wontac Bldg 3F, Chunggol-dong, Gwangjin-gu, Seoul 143-891, R. Korea www.navinc.co.kr / www.jaewoncnc.co.kr...
