Optional Parts (Not Included) - Whirlpool Lsv9244Dq0 Parts List

Illus. Part
No. No. DESCRIPTION
1 357213 Nut, Push−In (2)
2 Top
3358200 For White Model
3358201 For Almond Model
3 62750 Spacer, Cabinet To
Top (4)
5 Cabinet
63424 For White Model
63425 For Almond Model
Illus. Part
No. No. DESCRIPTION
LITERATURE PARTS
LIT3360057 Sheet, Installation
Instructions
LIT3363556 Guide, Use and
Care
LIT3361390 Energy Guide
LIT3948145 Label, Wiring
Diagram
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
LIT4313896 Manual, (Washer)
Do−It−Yourself
TOP AND CABINET PARTS
For Models: LSV9244DQ0, LSV9244DZ0
(Designer White) (Designer Almond)
Illus. Part
No.
6
8 3356311 Screw & Washer,
11 3352629 Switch, Lid
13 3351355 Screw, Lid Hinge
15
16
17

OPTIONAL PARTS (NOT INCLUDED)

Illus. Part
No.
PAINT, TOUCH−UP (1/2oz.)
PAINT, PRESSURIZED SPRAY
(13 oz.)
350938 Primer, Gray
350930 White
350956 Almond
261890 Golden Harvest
PAINT, BULK (1 qt.)
799344 White (Uncut)
978883 Almond (Uncut)
261891 Golden Harvest
OIL
350572 Oil, Gearcase
No. DESCRIPTION
62780 Clip, Top & Cabinet
& Rear Panel (2)
Lid Switch (2)
Mounting (4)
54584 Hinge, Lid (L.H.)
54583 Hinge, Lid (R.H.)
19119 Bumper, Lid Hinge
No. DESCRIPTION
OPTIONAL PARTS NOT INCLUDED
72017 White
72107 Almond
72110 Golden Harvest
(Uncut)
(16 Oz.)
2
Illus. Part
No. No. DESCRIPTION
18 21258 Bearing, Lid
Hinge (2)
19 Lid
3361392 For White Model
3361393 For Almond Model
20 358684 Strike, Lid Switch
22 93770 Bumper, Lid (2)
28 384435 Screw,
10−16 x 1/2 (5)
31 90016 Clip, Harness
32 3362952 Dispenser, Bleach
Illus. Part
No. No. DESCRIPTION
LUBRICANT
285208 Lubricant (Use
Only in Brake
Shoe Assembly
On Roller and
Pin)
SEALER
285195 Sealer, Gasket
(.20 Fl. Oz.) (6 ml)
SHIPPING KIT
3348675 Shipping Kit
ACCESSORY PARTS
63580 Fabric Dispenser
89121 Stand−Pipe Kit
367031 Drain Protector
285320 Siphon Break Kit
881267
