Summary of Contents for Elkron TC680-IP
- Page 1 TC680-IP IP Camera IS1160-AA...
-
Page 2: Table Of Contents
2.10.1 Motion Detection Setting ........................13 2.10.2 Mail Setting............................. 13 2.10.3 FTP Setting ............................14 2.11 CCD Module ..............................15 2.12 Advance Setting ..............................15 2.13 Setting up a multiple IP camera web server...................... 16 CHAPTER 3. FAQ ................................17 17/32 TC680-IP... -
Page 3: Chapter 1. Minimal System Requirement
1.3 Installation As there are different network systems, therefore there are a few different installation methods that will be introduced separately. 1. (Static IP) fixed IP 2. (Dynamic IP) dynamic IP 3. (PPPoE) dialing method For various installation methods. 18/32 TC680-IP... -
Page 4: Chapter 2. Operation Manual
The above three options are all based on reselect as the prompt. As indicated in the diagram. 1. Tool 2. Internet option 3. Safety 4. Self assigned level The above three are all set as prompt. During registration, please select yes 19/32 TC680-IP... -
Page 5: Network On-Line
After setting up the IP based on the above step, connect to the intended network or LAN. Execute IE directly on PC. Directly input IP to conduct on-line as the following diagram: Default User name admin password admin The left side of the above diagram is the control panel and the right side is image display. 20/32 TC680-IP... -
Page 6: Network Control
Save as AVI will record as AVI file with one section image video recording. JPEG and AVI can be set separately: No limit no limitation on the size of file. Number will limit how many frames in the file is the maximum number. 21/32 TC680-IP... -
Page 7: View Log
For detail description, please refer to “2.13 Setting up a multiple IP camera web server”. 2.5 View Log These records include IP that connects to the computer MAC address time However, after the DVR power is turned off, these records will be removed. 22/32 TC680-IP... -
Page 8: System Setting
Reboot IP Camera: After pressing, the IP Camera will reboot the machine. Firmware update: Program of network update on-line. Attach file name .bin Attention: Please confirm the source of the firmware update, invalid file will cause the camera malfunctioning. 23/32 TC680-IP... -
Page 9: User Management
Admin Name, Password and confirm require being the same. Then press “Set/Change” to input. System will need to reboot when once the administrator username is modified. Guest Add a user or change password, Admin Name, Password and confirm require being the same. Then press “Set/Change” to input. 24/32 TC680-IP... -
Page 10: Network Setting
DHCP Subject e-mail subject DNS Setting: DNS1 / DNS2 / DNS3 Port Setting: setting http port Reboot immediately: When the button is selected, system will reboot automatically. Actions will be done in 60 seconds. Then press “Save Setting” to input. 25/32 TC680-IP... -
Page 11: Pppoe
You can use semicolon to separate receivers in the same field. You can easily add up as many receivers as you wish. For an example, below figure indicates 3 receivers are in the receiving list. ydm.nx@msa.hinet.net; myfor@sinamail.com; xlinx@pchome.com.tw 26/32 TC680-IP... -
Page 12: Ddns
There are 2 ways to transmit captured picture during motion detection, FTP or Email. 2.10.1 Motion Detection Setting Circle your motion detection area by using mouse dragging. Then click on [Set Detection Area] Sensitivity: Can select 3 kinds – High / Middle / Low。 27/32 TC680-IP... -
Page 13: Mail Setting
When motions are triggered, images uploading can be interval between uploading session to next uploading session. Maxima value is 5 second. Upload images when motion detected: Check it to upload images when motions are triggered. Save Setting: Save setting including FTP and e-mail. 28/32 TC680-IP... -
Page 14: Ccd Module
Call out a status bar in the bottom of video screen. 2. Image Record: Record setup or press “F11” hotkey to perform. Please refer to 2.4 Network control. 3. Save Current Picture As: Snap Shot，or press “F12” hotkey. 29/32 TC680-IP... -
Page 15: Setting Up A Multiple Ip Camera Web Server
Enter compatible IP camera or web server IP addresses in the field of “Watching” then press “Add” button. This function is capable support up to 9 compatible IP devices. You can delete camera windows by pressing “Delete Camera” which is under “Delete a camera” section. Picture below indicates 4 IP cameras are connected to the web server. 30/32 TC680-IP... -
Page 16: Chapter 3. Faq
For an example of IP address 192.168.1.217: http://192.168.1.217/SetLanguage.cgi?Language=0 English http://192.168.1.217/SetLanguage.cgi?Language=1 Chinese How come the camera network functions are not able to perform properly? Please make sure you have correct configuration on IP table such as DNS, subnet mask and IP address. 31/32 TC680-IP... - Page 17 ELKRON S.p.A. Via G. Carducci, 3 – 10092 Beinasco (TO) – ITALY Tel. +39 (0)11.3986711 – Fax +39 (0)11.3499434 www.elkron.it - mailto: info@elkron.it...
