Sur-Gard MLR2000
Virtual Network Receiver
Installation
Manual
version 1.5
WARNING: This manual contains information on limitations regarding
product use and function and information on the limitations as to
liability of the manufacturer. The entire manual should be carefully read.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MLR2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sur-Gard MLR2000

Summary of Contents for Sur-Gard MLR2000

  • Page 1: Installation Manual

    Sur-Gard MLR2000 Virtual Network Receiver Installation Manual version 1.5 WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.
  • Page 2 If your home has specially wired alarm equipment connected to the telephone line, ensure the installa- IMPORTANT INFORMATION tion of this equipment Sur-Gard MLR2000 does not disable your alarm equipment. If you have ques- tions about what will disable alarm equipment, consult your telephone company or a qualified This equipment complies with Part 68 of the FCC Rules.

  • Page 3: Table Of Contents

    3.5 Computer Connections.......... 10 9.3 CPM Restoral ............31 3.6 Telephone Line Connections ........10 3.7 Grounding ............. 10 Section 10 - MLR2000 Computer Interface ..... 32 3.8 Power Supply............10 10.1 Virtual connectivity..........32 3.9 Battery Charging Current........10 10.2 Automation Mode..........32 3.10 Removing and Installing System Components ..

  • Page 4: Limited Warranty

    WARNING Limited Warranty Please Read Carefully Not e to Instal lers Digital Security Controls warrants the original purchaser that for a period of twelve months from the date This warning contains vital information. As the only individual in contact with system users, it is your of purchase, the product shall be free of defects in materials and workmanship under normal use.

  • Page 5: Section 1 - Introduction

    NOTES: Automation connections are considered first time on a central station receiver. The MLR2000 can supplementary per UL864 Listing. Compatibility decode a variety of popular and widely used communication with the automation software in a system used at a formats.

  • Page 6: Virtual Receiver Architecture

    Port 1024 A tool is provided for NT 4 + or Windows 9x/2000/XP The MLR2000 has a main power supply module for side A environments which provides graphical style menu for and for side B, and an optional stand-by power supply per configuration management.

  • Page 7: Section 2 - Quick Start

    Section 2 - Quick Start Receiver Setup and Operation • Take a 50-ohm coaxial cable and connect one end to the BNC connector (ETHERNET B) of the CPM2000. The 2.1.1 Unpacking other end of the coaxial cable should be connected to Carefully unpack the receiver and inspect for shipping the BNC connector (ENET B IN) of the backplane.
  • Page 8 Figure 2, 72 Line Cards Configuration (Expansion cabinet)
  • Page 9 2.1.3 Power Cable Connections • Take the power cables (10 gage) and connect one end • Take the power cable for the CPM2000 and connect the to the power terminals of the backplane marked PWR- labelled wire to the designated terminal on the back- GND (black cable) and +28 V A (red cable).
  • Page 10 Figure 4, 72 Line Cards Configuration (Expansion Cabinet) Fan Tray Ethernet Repeater A Ethernet Repeater A REC COL PA R P AR REC COL PA R P AR REC COL PA R P AR REC COL PA R P AR REC COL PA R P AR PW R J AM ACT PORT 1...
  • Page 11 2.1.4 Signaling/Supervisory Connections Figure 5, 60 Line Cards Configuration...
  • Page 12 Figure 6, 72 Line Cards Configuration (Expansion Cabinet)

  • Page 13: Bench Testing

    Ready to download. codes described in the 'DRL2000 Library Decoding and CCCC Event Codes Table' will be used with the Sur-Gard auto- 2. Point and click at 'Transfer' on the Hyper Terminal mation communication protocol to send signals to the menu and access the 'Send File' category.

  • Page 14: Section 3 - Installation

    Mounting the Receiver Ensure that all electrical connections are made correctly. Install the MLR2000 in a closed 19" rack or cabinet with a After verifying all connections, connect the RED and locking rear access door. Cover all unused spaces with BLACK leads to a 24 (2 ×...

  • Page 15: Section 4 - Drl2000 Digital Receiver Line Card

    Section 4 - DRL2000 Digital Receiver Line Card The DRL2000 acts as an interface between the digital DRL2000 Controls alarm transmitter and the CPM2000. Different communi- Each DRL2000 Module has one telephone line. cation formats can be used to transmit the information. Momentarily depressing and releasing a button will regis- The main functions of the line-cards are to continuously ter as a single input or keystroke.

  • Page 16: Section 5 - Drl2000 Operating Mode

    19-Nov-1998 10:40:56 - Nov 19 1998-11:32:25-F3/00- When the CPM2000 Error condition is corrected, the SG -19-069-123F—SUR-GARD SECURT alarm messages in the event buffer will be transmitted to the CPM2000 with the corresponding time/ date the alarm have been received.

  • Page 17: Section 6 - Advanced Programming

    (or a receiver itself) devoted to certain or Caller ID customers, the MLR2000 can "handle" any format at any time through the use of profiles. Each line card holds its own look-up table that can be shared through line pools, Send string to or shared within the entire receiver.

  • Page 18: Automatic Handshake Selection)

    NOTE: Enabling 2-way audio will affect NFPA 72 sys- tem loading requirements. Refer to Par. 4-5.3.2.2.2 of On the MLR2000, it will replace the RRLLL, which is normally NFPA 72 for details. the receiver number and the line card number, by the DNIS If the alarm panel sends a listen-in code activation received or the convert data found in the table.
  • Page 19 The second nibble of this option controls the user/zone Option [13]: Caller Source to SG Computer - number conversion. The Sur-Gard 4/3 DTMF format is Default [00] made up of a 4-digit account code, a 1-digit event code, Option [13] allows the transmission of the Caller Identifica- and a 2-digit hexadecimal zone code or user number.
  • Page 20 DNIS (for example, Caller-ID), then the table lookup the A.H.S. database with the MLR2000 Console software. functionalities remain the same. If the entry is If the operator wishes to call block a particular customer...

  • Page 21: Dynamic Options: [30] - [Ff]

    Options [30] - [3F]: 3/1 - 4/1 Digit 0-F formats to determine the message and event code. The The DRL2000 uses a unique Sur-Gard communication for- event code will then be transmitted to the central station mat to transmit data through the CPM2000 to the central computer.
  • Page 22 (Hex 20) can be used as the common event code with cer- tain automation software packages to avoid account code database changes when switching over from other brand receivers to the Sur-Gard receiver. Values programmed in Options[30]-[5F],[70] other than in this table will default to UAxx for Undecoded Alarm.
  • Page 23 So it will convert account code NOTE: Option [7B] may be used with any 3-digit 9876 as indicated below: account code formats supported by the MLR2000. 1RRLLLsssss9-876sXssYZ Option [7C]: Alarm Codes to Activate 2-Way Audio - Default [00] * This will not affect SIA.
  • Page 24 Option - [7A] [7C] Switch Reason (or [7B]) to Audio Options [81] through [88]: Handshake Selection - 00 1-2 Alarm code 2 falls within the code Default: [81] [85] range 1-2. [82] [86] 1-1 00 Account code 1234 falls within the range 1-1.
  • Page 25 Option [91]: Inter-Handshake Duration - Default [00] The DRL2000 line card will usually wait for signals from the Value 5 Digit Setting 6 Digit Setting control panels for 4 seconds before sending the next hand- select 4/1 format select 4/2 format shake, if there are no signals received.
  • Page 26 = space The Ademco 4/1 Express format may cause conflicts with C = Channel 9 the Sur-Gard DTMF 4/3 with checksum format or FBI Super [DC4] terminator fast without checksum. Therefore, this option must be pro- grammed to inform the DRL2000 which of the 3 formats Option [A0]: 11 / 12-Digit DTMF (Acron or may be used.
  • Page 27 Example 2: Code B1 Options [A8] - [AF]: Dial-out Number For 2-way Computer output: 604091sssssss022sOsss1 Audio Transfer - Default [00] If Option A3 is set to 05: the hex digit will be stripped for These 8 options are used to provide the dial-out number if 1-digit reporting and BFSK.

  • Page 28: Section 7 - Drl2000 Communication Formats

    Computer:901123ssss1234AAAAA78A[14][6] Sur-Gard DTMF Formats Ademco Contact ID Sur-Gard DTMF 4/3 and 4/3 with checksum formats pro- This DTMF format requires a dual tone handshake and vide fast, reliable and easy-to-understand and decode 1400 Hz kiss-off, or 1400 Hz handshake and 1400 Hz data transmission.
  • Page 29 Low temp Loss of radio supervision O/C Partial Arm Loss of air flow Loss of central polling exit Error Fire supervisory - 200 and 210 Radio Xmtr VSWR User on Premises Fire supervisory Protection Loop Troubles - 370 Recent Close Low water pressure Protection loop System Disables - 500 and 510...

  • Page 30: Ademco Express

    Zero regular 4/1 or 4/2 format. Option [99] must be pro- Opening grammed as ‘01’ to decode the 4/1 Express format Closing instead of the Sur-Gard 4/3 with checksum format. Abort Example: Restore • Option 99 set to 00 Trouble...

  • Page 31: Modem Ii, Modem Iie, Modem Iiia² And Bfsk Formats

    7.10 Modem II, Modem IIE, Modem IIIa² 7.12 Silent Knight FSK1, FSK2 and BFSK Formats 7.12.1 Silent Knight FSK1 Protocol ERRLLLssssAAAAAAXXssss[DC4] BFSK, Modem II, Modem IIIa or Modem IIE formats (refer Where: to appendix D) can be decoded by the DRL2000. FSK protocol identifier 7.10.1 Modem II Receiver number...

  • Page 32: Sescoa Super Speed

    AAAAAA Account number (if the account is 4 or 5 dig- E60z Expand trouble device ID z its, the leading “A”s will be replaced by EE0z Expand restore device ID z spaces) E6zz Expand trouble station ID zz (zz=17-31) Event code EEzz Expand restore station ID zz (zz=17-31) Zone/user number...
  • Page 33 7.15.2 3/1-4/1 Extended, 3/2 & 4/2 Alarm Library 7.15.4 Event Codes Summary Alarm 0x (Ax) PER TEST REPORT Code Event Alarm FIRE ALARM Automatic Test Alarm PANIC ALARM Fire Alarm Alarm BURGLARY Panic Alarm Alarm GENERAL ALARM Burglary Alarm Alarm GENERAL ALARM Closing by User Number Alarm...

  • Page 34: Section 8 - Cpm2000 Central Processing Module

    Section 8 - CPM2000 Central Processing Module The CPM2000 is the central processing module that monitors • Ethernet A and B to DRL2000 line-cards • TCP/IP output to automation software and MLR2000 the DRL2000 Line Cards and forwards the information from the console software.

  • Page 35: Section 9 - Cpm2000 Wiring Diagram

    Loss of Socket/Automation The Manual Restore rule is a command that may be issued on the Sur-Gard console to jump back to the first entry. It is estimated that sockets may appear and disappear reg- The CPM and automation must connect to all resources ularly as processes are terminated and reconstituted.

  • Page 36: Section 10 - Mlr2000 Computer Interface

    CPM2000(A) Poll Manual Re-start from Ethernet Port Automation ciated ports. Each MLR2000 receiver may have up to two Console (Reset Fallback) Active? CPM2000's, configured as a primary CPM plus an optional 'hot backup' CPM. Internally, socket program- ming uses specific ports for expected tasks. The MLR2000...

  • Page 37: Client Side Connects

    'server as per the following diagram after Stevens 'UNIX The line-cards will be assigned by shelf and slot number. Network Programming' Prentice Hall 1990 section 6.2. All device status information is in Sur-Gard format. The reporting of status on this port, automation output, CPM 10.5 Stream Packet Structure display and printer will relate to physical addressing.
  • Page 38 CPM2000 Internal Status Messages: Description Printer Message Automation message 24V Battery Low 24V Battery Low YT0000 24V Battery Restored 24V Battery Restored YR0000 5V Failure 5V Failure YT0001 5V Restored 5V Restored YR0001 Fan Circuit Failure Fan Circuit Failure YX0000 Fan Circuit Restored Fan Circuit Restored YZ0000...

  • Page 39: Console Spcifies Which Sg Automation To Supervise

    CPM2000 LCD Messages by priority: VZ0000: Parallel port Printer Error VZ0001: TCP/IP Printer Error YC0001: COM#1 Absent YC0002: COM#2 Absent YT0000: 12V Battery Low YT0001: 5V Failure AT0000: AC CPMA Failure AT0001: AC CPMB Failure Special Messages: S67890[#0000|ABLOCKEDCALL 1234567890][14] S01001[#0000|ABLOCKEDCALL 12345 1234567890][14] S01001[#0000|AAHS TABLE FULL] 10.8 Console Specifies which SG Automation to Supervise...

  • Page 40: Section 11 - Psu2000 Power Supply Module

    Section 11 - PSU2000 Power supply Module 'AC' LED It indicates the presence of AC. 'BATTERY OK' LED It indicates the battery status (ON when battery is charged). 'Trouble' LED It indicates a trouble in the power supply.

  • Page 41: Section 12 - Automation Protocols

    Section 12 - Automation Protocols The Sur-Gard MLR2000 receiver sends the various protocols to report signals to the central station computer via an RS232 port. The complete description of protocols is available upon request. 12.1 Data Byte protocol The Sur-Gard MLR2000 receiver uses a default configura-...

  • Page 42: Section 13 - Detailed Description Of Computers

    Section 13 - Detailed Description of Computers 13.1 COM Responses 13.2 Automation Absent When the CPM2000 sends an event to the computer, it When the computer is not responding to transmissions, checks for 3 responses: Ack, Nack or Unknown/No the CPM will generate a 'COMx Absent' or 'TCP/IP Response Absent' trouble.

  • Page 43: Appendix A - Drl2000 Communication Formats

    Silent Knight Fast 1400Hz 1900Hz 14bps 4/2,4/1,3/1 1400Hz Silent Knight FSK0 1400Hz 1400Hz Silent Knight FSK1 1400Hz 1400Hz Silent Knight FSK2 1400Hz 1400Hz Sur-Gard 2300Hz DTMF DTMF 4/1,4/2,4/3 2300Hz Sur-Gard 2300Hz DTMF DTMF 4/3+Checksum 2300Hz Sur-Gard Dual Tone DTMF DTMF...

  • Page 44: Appendix B - Decimal - Hex - Binary Conversion Chart

    Appendix B - Decimal - HEX - Binary Conversion Chart Binary Binary Binary Binary 0000 0000 0100 0000 0100 0000 0100 0000 0000 0001 0100 0001 0100 0001 0100 0001 0000 0010 0100 0010 0100 0010 0100 0010 0000 0011 0100 0011 0100 0011 0100 0011...

  • Page 45: Appendix C - Ascii Character Chart

    Appendix C - ASCII Character Chart Corresponding ASCII HEX Character with library on printer (Option 70) Space...

  • Page 46: Appendix D - Printer Words: Options [60-6F]

    Appendix D - Printer Words: Options [60-6F] The English Printer Library is provided and can be selected by programming the event codes to the corresponding word. Words available: Hex # Printer Words Hex # Printer Words MEDICAL FIRE SUPERVISORY PENDANT TRANSMITTER LOW WATER PRESSURE FAIL TO REPORT IN LOW CO2...
  • Page 47 Hex # Printer Words Hex # Printer Words RF TRANSMITTER. LOW BATTERY BELL 2 DISABLE SMOKE HI-SENSOR ALARM RELAY DISABLE SMOKE LOW-SENSOR TROUBLE RELAY DISABLE INTRUSION HI-SENSOR REVERSING RELAY DISABLE INTRUSION LOW-SENSOR RESERVED SELF TEST FAIL RESERVED OPEN/CLOSE RESERVED O/C BY USER RESERVED GROUP O/C DIALER DISABLED...

  • Page 48: Appendix E - Panels Compatibility List

    Appendix E - Panels Compatibility List Panel Formats Passed/Failed Panel Formats Passed/Failed Acron Avenger 4000 20 BPS Not Verified C&K System 236 10 BPS Passed Acron Superfast Not Verified 20 BPS Passed Adcor PPD-3 Not Verified Any DTMF Format Passed ADT Safewatch Pro 3000 Ademco Contact ID Passed...
  • Page 49 10 BPS Passed 20 BPS Passed 20 BPS Passed 40 BPS Passed 40 BPS Passed Any DTMF Format Passed Sur-Gard 4/3 Passed Passed DSC SN4030 V2.0Y Passed DSC PC4010 V2.X 10 BPS Passed DSC SN4030 V3.0Y Passed 20 BPS Passed...
  • Page 50 Panel Formats Passed/Failed Panel Formats Passed/Failed ITI Simon ITI FSK Not Verified BFSK Passed ITI SX-IVB ITI FSK Not Verified Modem IIA Passed ITI SX-V ITI FSK Passed Radionics D7112 BFSK Passed ITI SX-V Special ITI FSK Passed Modem IIA Passed ITI RF Commander ITI FSK...
  • Page 51 Panel Formats Passed/Failed Sur Gard P1664LC 10 BPS Passed 20 BPS Passed 40 BPS Passed Any DTMF Format Passed Passed Linear 1704/SSD Linear FSK Not Supported Westec 800 Westec Format 3 Not Supported Westec 900 Westec Format 1 Not Supported Westec 2000 Old Westec Format 2 Not Supported...
  • Page 52 ©2004 Digital Security Controls Printed in Canada Toronto, Canada • www.dsc.com Sales: 1-888-888-7838 Tech. Support (Canada & USA): 1-800-503-5869 2 9 0 3 4 6 37 R00 2...
