FACTORY PRESET TIMING TABLE

STANDARD
RESOLUTION
IBM
VGA
VESA/75
VESA/85
VESA/75
VESA/85
VESA/75
VESA/85
VESA/60
PIN NO. DESCRIPTION
1. Red
2. Green
3. Blue
4. Ground
5. Ground
6. R-Ground
7. G-Ground
8. B-Ground
720 × 400
640 × 480
640 × 480
640 × 480
800 × 600
800 × 600
1024 × 768
1024 × 768
1280 × 1024

CONNECTOR PIN ASSIGNMENT

1
6
11
15 - Pin Color Display Signal Cable
HORIZONTAL
FREQUENCY
31.47kHz
31.47kHz
37.5kHz
43.3kHz
46.875kHz
53.67kHz
60.02kHz
68.6kHz
64.0kHz
5
10
15
PI N NO.
9.
10.
11.
12.
13.
14.
15.
∗
15
VERTICAL
FREQUENCY
70Hz
60Hz
75Hz
85Hz
75Hz
85Hz
75Hz
85Hz
60Hz
DESCRIPTION
NC
Ground
Monitor Ground
DDC-Serial Data
H-Sync
V-Sync / ∗V-Clk
DDC-Serial Clock
For DDC
