Silvan Selecta Selecta MANSECURE01 Instruction Manual page 9

Model
Image Sensor
Lens
IR Flash
LCD Screen
Operation Keypad
Memory Compatibility
Picture Size (pixels)
Video Size
PIR (Motion) Sensitivity
PIR Sensing Distance
PIR (Motion) Sensors
Central PIR Sensing angle
Side PIR Sensing Angle
Operation Mode
Trigger Time
Trigger Interval
Photo Playback Zoom
Time Stamp
Timer
Password
Device Serial No.
Time Lapse
Audio
Language
Power Supply
Stand-by Current
Stand-by Time
Auto Power Off
Power Consumption when
activated by motion
Low Battery Alert
Interface
Mounting
Waterproof
Operation Temperature
Operation Humidity
Certificate
Installing the additional Battery Box (Tree Hugger)
Appendix: TECHNICAL SPECIFICATION
Parameters
12 Mega Pixels Colour CMOS
F=3.1; FOV=52°; Auto IR-Cut
20 Meters / 65 Feet (Non-Visible Flash, no glow LEDs)
48x35.69mm(2.36"); 16.7M Colour
6 Keys
SD Card (8MB ~16GB)
12MP=4000x3000;
5MP = 2560x1920;
1280x720p: 30fps; 720x480: 20fps; 640x480: 20fps; 320x240: 20fps
High/Normal/Low
20m /65ft (On the Normal sensitivity and temperature is below 25°C/77°F)
1 x Central PIR Sensor, 2 x Side (Peripheral) PIR Sensors
35°
When Side PIR active the total sense angle is 100°
Day/Night
1 Second (When using the 2G SD card)
0sec. - 60min; Programmable
1~16 Times
On /Off; Include serial no.,
On /Off; Timer Set
4-Digit Numbers
4 character alphanumeric
1 Second ~ 24 Hours
On/Off
English/Chinese/French/Norwegian/Deutsch/Spanish/Portuguese/Japanese/Russian
4xAA; Expandable to 8xAA (With additional battery box)
0.4mA
Maximum 3 or 6 Months (using 4xAA or 8xAA)
Auto power off in 2 minutes while no keypad controlling
150mA (+500mA when IR LED lights up)
4.2~4.3V
TV out (NTSC); USB; SD Card Slot; 6V DC External
Strap; Tripod Nail
IP54
-30 to 70°C (-22 to 158°F)
5% ~ 95%
FCC & CE & RoHS
