User Manual
SRP-150
Thermal Printer
Rev. 1.07
http://www.bixolon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRP-150 and is the answer not in the manual?

Questions and answers

Related Manuals for BIXOLON SRP-150

Summary of Contents for BIXOLON SRP-150

  • Page 1 User Manual SRP-150 Thermal Printer Rev. 1.07 http://www.bixolon.com...

  • Page 2: Safety Warning

    SRP-150 ■ Safety Warning Proper use of this product can prevent hazardous or physical harm. Make sure all following instructions are followed when using this product. Warning Violation of following instructions may cause serious injure or risk of life. Please use the adapter provided.
  • Page 3 SRP-150 Caution Violation of following instructions may cause slight injure or damage to the product. Power off and take following actions immediately in Keep the drier out of reach of children. case of the product producing smoke, or strange Eating the drier may result in serious harm to health.
  • Page 4 SRP-150 ■ Warning - U.S.A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 EMI (electromagnetic interference). If you sell or purchase by mistake, please change back into the household type. We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. In following, product specifications and/or user manual content may be changed without prior notice.
  • Page 6 Its main features are shown as follows: 1. High speed printing; 2. Thermal printing with low noise; 3. RS-232 series interface(SRP-150), IEEE1284 parallel interface(SRP-150P), USB2.0 interface(SRP-150U). 4. Reception of data is possible via Data buffer, even in printing process. 5. The Document Image Processing button enables selection of different printing density.

  • Page 7: Table Of Contents

    SRP-150 ■ Table of Contents 1. Installation and basic operations · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 8 1-1 Unpacking ·...

  • Page 8: Installation And Basic Operations

    SRP-150 1. Installation and basic operations 1-1 Unpacking Make sure all following items are available. Please contact the distributor immediately in case of loss or damage. User Manual Printer Paper Cable interface Power cord Cable interface Serial, parallel cable - Only one of the following cable interfaces is provided according to the model you purchase, USB, parallel or serial interface.

  • Page 9: Operation Panel

    SRP-150 1-3 Operation Panel The Panel consists of one button and two indicators. Button FEED To print one paper, press the FEED button. To continuously print, press and hold the FEED button. Indicator The indicator indicates the state of the printer.

  • Page 10: Connection

    SRP-150 2. Connection 2-1 AC Adapter Connection It is required to used the power cord and adapter accompanied with the printer. ※ Warning Improper power unit may cause a fire or hazard. ※ Note 1. Operate the product in the following orders for safety and durability after power on.

  • Page 11: Interface Connection

    SRP-150 2-2 Interface Connection USB, serial or parallel interface cable is required for connecting the printer to the computer. - Make sure the power of the printer and computer is switched on, then connect the cable interface to the printer.

  • Page 12: Srp-150S Serial Interface

    SRP-150 2-2-1 SRP-150S Serial Interface Printer Case Main --------------------- --------------------- --------------------- --------------------- --------------------- --------------------- --------------------- Shield --------------------- Shield 9PIN MALE 9 PIN FEMALE - 12 - Rev. 1.07...

  • Page 13: Srp-150P Parallel Interface

    SRP-150 2-2-2 SRP-150P Parallel Interface Printer Case Main ---------------- nStrobe nStrobe ---------------- Data 0 (LSB) Data 0 (LSB) ---------------- Data 1 Data 1 ---------------- Data 2 Data 2 ---------------- Data 3 Data 3 ---------------- Data 4 Data 4 ---------------- Data 5...

  • Page 14: Cash Drawer Cable Connection (Option)

    SRP-150 2-2-4 Cash Drawer Cable Connection (Option) Pin No. Description Direction Frame GND Drawer Kick-Out Driver Signal #1 Output Drawer Open / Close Signal Input +12V Drawer Kick-Out Driver Signal #2 Output Signal GND - 14 - Rev. 1.07...

  • Page 15: Dip Switch Setting

    SRP-150 3. DIP Switch Setting ※ Note It is required to turn off the printer when setting the DIP switch to prevent electrical rejection and damage to the printer. Replacement of the contact device or the printing density can be set on the DIP switch.

  • Page 16: Setting The Dip Switches

    SRP-150 Refer to the following settings of the DIP switch. 3-1 Setting the DIP Switches 3-1-1 Setting the DIP switch (RS-232C Serial Interface) • DIP Switch Function Default Auto Cutter Disable Enable Reserved Baud Rate Refer to Table 1 • Table 1 – Baud rate (bps) Selection...
  • Page 17 SRP-150 MSW2 Switch Function Reserved Fixed to OFF Auto Cutter Function Full Cutting Partial Cutting Code Page Selection Refer to following Table MSW2-8 MSW2-7 MSW2-6 MSW2-5 MSW2-4 MSW2-3 Character Table Page 0 437 (USA,standard Europe) Page 1 Katakana Page 2...
  • Page 18 SRP-150 MSW9 Switch Function Language Selection Korean/Chinese Reserved Fixed to OFF International Character Set Refer to following Table Selection MSW9-8 MSW9-7 MSW9-6 MSW9-5 International Character Set 0. USA 1. France 2. Germany 3. UK 4. Denmark 5. Sweden 6. Italy 7.

  • Page 19: Paper Loading

    SRP-150 4. Paper Loading Please use the standard paper. ※ Note It is important to power off the printer in the process of paper loading. 1. Open the paper cover and take out all used paper. 2. Load the paper in the proper direction as the following shown in case of paper jam.

  • Page 20: Sample Test

    SRP-150 5. Sample Test 1. Sample Printing Test * Sample Test Start-up After loading paper and close the cover and the PAPER FEED button pressed and held, the sample test will start upon power on. The self-test will conduct printing according to the existing setting of the following information available.

  • Page 21: Hexadecimal Dumping

    SRP-150 6. Hexadecimal Dumping This function is designed for advanced user to send and receive the data accurately and identify the software problems. The Hexadecimal Dumping function is helpful for searching special terms because all data and command statements are printed in hexadecimal form.

  • Page 22: Specification

    SRP-150 7. Specification Printing Method Thermal printing Resolution 203Dpi (8 dot/mm) Printing Width 48mm Paper Width 58.0±0.5mm Strings Per Line 32 (Font A) (12x24) / 42 (Font C) (9x24) About 19 lines/sec Max. 65 mm/sec Printing Speed at 25℃/printing duty 12.5% Thickness: 0.062 ~ 0.075mm...

  • Page 23: Windows Driver Setting

    8. WINDOWS Driver Setting 8-1 Serial (RS-232C) Interface Model Windows Driver Setting 1. After executing the proudct setting CD, go to Thermal Printer > SRP-150 > Drivers > Windows Driver > Drivers folder > exectute SRP-150_WIN_Vx.x.xx.exe 2. Select “Next” from the window at the initial setting.

  • Page 24: Parallel (Ieee1284) Interface Windows Driver Setting

    SRP-150 8-2 Parallel (IEEE1284) Interface Windows Driver Setting 1. After executing the proudct setting CD, go to Thermal Printer > SRP-150 > Drivers > Windows Driver > Drivers folder > exectute SRP-150_WIN_Vx.x.xx.exe 2. Select “Next” from the window at the initial setting.

  • Page 25: Control Command List

    SRP-150 9. Control Command List Command Name Horizontal tab To print and Line Feed To print and Carriage Return DLE EOT To send the real time status ESC SP To set the right side space of the characters ESC !

  • Page 26: Summary Of Control Command

    SRP-150 10. Summary of Control Command [Name] Horizontal Tab [Type] ASCII Decimal [Description] Set the horizontal tab if you want to use the print position. [Name] To print and line feed [Type] ASCII DECIMAL 10 [Description] To print the data in the printer buffer and feed one line.
  • Page 27 SRP-150 n = 1: Printer Status Off/On DECIMAL Function Not used. Fixed to Off Not used. Fixed to On Not used On-line Off-line Not used. Fixed to On Not defined Not used. Fixed to Off n = 2: Off-line Status...
  • Page 28 SRP-150 ESC SP n [Name] To set the right side space of the characters [Type] ASCII DECIMAL [Range] 0 ≤ n ≤ 255 [Description] To set the right side space of the characters ESC ! n [Name] To set the printer mode...
  • Page 29 SRP-150 ESC % n [Name] To select/cancel user defined character set [Type] ASCII DECIMAL 27 [Range] 0 ≤ n ≤ 255 [Description] To select/cancel user-defined character set. User-defined character set is cancelled when LBS of n is 0, User-defined character set is selected when LBS of n is 1.
  • Page 30 SRP-150 ESC – n [Name] To set/clear underline mode [Type] ASCII DECIMAL 27 [Range] 0 ≤ n ≤ 2, 48 ≤ n ≤ 50 [Description] Underline mode is set or cleared depending on the value of n. Function 0,48 Underline mode is cleared Underline mode is selected (Dot thickness –...
  • Page 31 SRP-150 ESC ? n [Name] To cancel the user defined character set [Type] ASCII DECIMAL 27 [Range] 32 ≤ n ≤126 [Description] To cancel the user-defined character sets. ESC @ [Name] To initialize the printer [Type] ASCII DECIMAL 27 [Description] This function purges the data in the buffer when the power is on or recovers the printer mode.
  • Page 32 SRP-150 ESC R n [Name] To select multilanguage character sets [Type] ASCII DECIMAL 27 [Range] 0 ≤ n ≤ 10 [Description] To select the multilanguage character set with n. Chinese version is not supported. Character set Character set U.S.A. Italy...
  • Page 33 SRP-150 ESC V n [Name] To set/clear 90° clockwise rotated character sets [Type] ASCII DECIMAL 27 [Range] 0 ≤ n ≤ 1, 48 ≤ n ≤ 49 [Description] To set/clear 90° clockwise rotated character sets depending on the value of...
  • Page 34 SRP-150 ESC p m t1 t2 [Name] To generate pulse [Format] ASCII Decimal [Range] m = 0, 1, 48, 49 0 ≤t1 ≤255, 0 ≤t2 ≤255 [Description] Outputs the pulse specified by t1 and t2 to connector pin m as follows.
  • Page 35 SRP-150 FS p n m [Name] NV image output [Type] ASCII DECIMAL 28 [Range] 1  n  255, 0  m 3 , 48  m  51 [Description] NV image is printed in various sizes depending on the value of m.
  • Page 36 SRP-150 GS * x y d1...d (x X y X 8) [Name] To define the download bit image [Type] ASCII d1...d (x X y X 8) d1...d (x X y X 8) DECIMAL 29 d1...d (x X y X 8) [Range] 1 ≤...
  • Page 37 SRP-150 GS H n [Name] To select the printing position of the HRI characters [Type] ASCII DECIMAL 29 [Range] 0 ≤ n ≤ 3 , 48 ≤ n ≤51 [Description] To select the printing position of HRI characters when printing the bar code...
  • Page 38 SRP-150 ① GS V m ② GS V m n [Name] To Select cut mode and cut paper ① ASCII [Type] DECIMAL 29 ② ASCII DECIMAL 29 [Range] ① m = 1, 49 ② m = 66, 0 ≤ n ≤ 255 [Description] Selects a mode for cutting paper and executes paper cutting.
  • Page 39 SRP-150 GS f n [Name] To select the font of HRI (Human Readable interpretation) characters [Type] ASCII DECIMAL 29 [Range] n = 0, 48 [Description] To select the font of HRI characters used for barcode printing Chinese version is not supported.
  • Page 40 SRP-150 ① GS k m d1...dk NUL ② GS k m n d1...dn [Name] To printer barcode ① ASCII [Type] d1...dk d1...dk DECIMAL d1...dk ② ASCII d1...dn d1...dn DECIMAL d1...dn [Range] ① 0 ≤ m ≤ 6 (Values for k and d are determined by the barcode system.) ②...
  • Page 41 SRP-150 Control character Control character character character ASCII DECIMAL ASCII DECIMAL ■U ■P ■A ■Q ■B ■R ■C ■S ■D ■T ■E ■U ■F ■V ■G ■W ■H ■X ■I ■Y ■J ■Z ■K ■A ■L ■B ■M ■C ■N ■D...
  • Page 42 SRP-150 The following characters can be represented by the CODE128 barcode. * SHIFT characters In the code set A, the character right next to the SHIFT follows the process of code set B. SHIFT character cannot be used in code set C.
  • Page 43 SRP-150 GS v 0 m xL xH yL yH dl…dk [Name] To print raster bit image dl…dk [Type] ASCII dl…dk dl…dk DECIMAL 29 [Range] 0  m  3 , 48  m ( 51 0 ≤ xL ≤ 255 , 0 ≤ xH ≤ 255 , 0 ≤ yL ≤ 255...
  • Page 44 (Address) (CA3)#11 Luyi 2 Road, Tangxia Town, Dongguan City, Guangdong Province,P.R.China (Tel) +86 769 8262 0704~07 ● American Office (Address) BIXOLON America Inc., 3171 Fujita St, Torrance, CA 90505 (Tel) +1-858 764 4580 ● European Office (Address) BIXOLON Europe GmbH, Tiefenbroicher Weg 35 40472 Düsseldorf...
