Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine. The use of any gasoline
exceeding 10% ethanol (E10) will void the product warranty.
Esta máquina puede utilizar gasolina con un contenido de hasta el 10% de etanol (E10). El uso de una
gasolina que supere el 10% de etanol (E10) anulará la garantía del producto. the product warranty.
Please read the operator's manual carefully and make sure you understand the instructions before using the
machine.
Por favor lea cuidadosamente y comprenda estas intrucciones antes de usar esta maquina.
583 87 96-49
Operator's Manual
Manual de Operario
Original Instructions in English, all others are translations.
M24-54T
English/Spanish

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M24-54T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for McCulloch M24-54T

  • Page 1 Operator’s Manual Manual de Operario M24-54T English/Spanish Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine. The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty. Esta máquina puede utilizar gasolina con un contenido de hasta el 10% de etanol (E10). El uso de una gasolina que supere el 10% de etanol (E10) anulará...
  • Page 2: Safety Rules

    SAFETY RULES Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. • Never leave a running machine unattended. Always turn WARNING: In order to prevent ac ci den tal off blades, set parking brake, stop engine, and remove starting when setting up, trans port ing,...
  • Page 3 SAFETY RULES Safe Operation Practices for Ride-On Mowers III. CHILDREN • If fuel is spilled on clothing, change clothing immediately. • Never overfill fuel tank. Replace gas cap and tighten securely. WARNING. CHILDREN CAN BE INJURED BY THIS EQUIPMENT. The American Academy GENERAL SERVICE of Pediatrics recommends that children be a •...
  • Page 4: Table Of Contents

    PRODUCT SPECIFICATIONS CONGRATULATIONS on your purchase of a new tractor. It has been designed, engineered and manu fac tured to Gasoline Capacity 3 Gallons give you the best possible dependability and performance. and type: Unleaded Regular Should you experience any problem you cannot easily Oil Type (API-SG-SL): SAE 30 (above 32°F) remedy, please contact your nearest authorized service...
  • Page 5: Unassembled Parts

    UNASSEMBLED PARTS Mower Mower Front Wheel (2) Rear Lift Link Assemblies (1) Shoulder Bolt (1) 1-1/4 O.D. Washer (1) Small Retainer Springs (1) Front Lift Link (1) 3/8-16 Assembly (1) Wheel Locknut (5) Large Retainer Springs If Equipped (1) Small Retainer (1) 3/4 O.D.
  • Page 6: Assembly

    ASSEMBLY Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to ensure proper tightness.
  • Page 7 ASSEMBLY 4. SLIDE MOWER UNDER TRACTOR (See Fig. 8) • Bring belt forward and check belt for proper routing in LIFT all mower pulley grooves. LEVER NOTE: Be sure mower side suspension arms (A) are point- ing forward before sliding mower under tractor. •...
  • Page 8 ASSEMBLY 7. ATTACH REAR LIFT LINKS (C) (See Fig. 13) • Insert rod end of rear lift link (C) into hole (U) in tractor lift ANTI-SWAY BAR TRANSAXLE (S) LOCATION BRACKET (T) shaft suspension arm and pivot link down to mower. LOCATED •...
  • Page 9 ASSEMBLY ✓ 9 INSTALL BELT ON ENGINE CLUTCH PULLEY (M) CHECKLIST (See Fig. 7 & 15) • Disengage belt tension rod (K) from locking bracket (L). BEFORE YOU OPERATE YOUR NEW TRAC TOR, WE WISH TO ENSURE THAT YOU RECEIVE THE BEST •...
  • Page 10: Operation

    OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. FAST SLOW REVERSE HIGH NEUTRAL CHOKE IGNITION SWITCH ENGINE START MOWER HEIGHT MOWER LIFT REVERSE ENGINE ON PARKING BRAKE ENGINE OFF OPERATION SYSTEM (ROS) CLUTCH/BRAKE...
  • Page 11 OPERATION KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. Fig.
  • Page 12 OPERATION The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while operating your tractor or per form ing any ad just ments or repairs. We rec om mend standard safety glasses or a wide vision safety mask worn over spectacles.
  • Page 13 OPERATION TO ADJUST GAUGE WHEELS (See Fig. 22) Gauge wheels are properly adjusted when they are slightly off the ground when mower is at the desired cutting height in operating position. Gauge wheels then keep the deck in prop- er position to help prevent scalping in most terrain conditions. NOTE:Adjust gauge wheels with tractor on a flat level surface.
  • Page 14 OPERATION REVERSE OPERATION SYSTEM (ROS) TO TRANSPORT (See Fig. 25) Your tractor is equipped with a Reverse Operation System When push ing or tow ing your trac tor, ensure transmission (ROS). Any attempt by the operator to travel in the reverse is disengaged by placing freewheel control in free wheel ing direction with the attachment clutch engaged will shut off po si tion.
  • Page 15 OPERATION BEFORE STARTING THE ENGINE TO START ENGINE (See Fig. 16) When starting the engine for the first time or if the engine CHECK ENGINE OIL LEVEL has run out of fuel, it will take extra cranking time to move fuel from the tank to the engine.
  • Page 16 OPERATION MOWING TIPS • DO NOT use tire chains when the mower hous ing is attached to tractor. • Mower should be properly leveled for best mowing performance. See “TO LEVEL MOWER HOUSING” in the Service and Adjustments section of this manual. •...
  • Page 17: Maintenance Schedule

    MAINTENANCE BEFORE EVERY EVERY EVERY EVERY EVERY BEFORE MAINTENANCE EACH SEASON STORAGE SCHEDULE HOURS HOURS HOURS HOURS Check Brake Operation Check Tire Pressure Check Operator Presence & ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Clean Debris Off Steering Plate Check Mower Levelness...
  • Page 18: Maintenance

    MAINTENANCE TRACTOR BLADE CARE For best results mower blades must be kept sharp. Re place Always observe safety rules when per form ing any bent or damaged blades. main te nance. CAUTION: Use only a replacement blade ap- BRAKE OPERATION proved by the manufacturer of your tractor.
  • Page 19: Engine Cooling System

    MAINTENANCE V-BELTS • Unlock drain valve by pushing inward and turning coun ter clock wise. Check V-belts for deterioration and wear after 100 hours • To open, pull out on the drain valve. of operation and replace if necessary. The belts are not ad just able.
  • Page 20 MAINTENANCE IN-LINE FUEL FILTER (See Fig. 30) DECK WASHOUT PORT (See Fig. 32) The fuel filter should be replaced once each season. If fuel Your tractor’s deck is equipped with a washout port as part filter becomes clogged, ob struct ing fuel flow to car bu re tor, of its deck wash system.
  • Page 21: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST MENTS: • Depress brake pedal fully and set parking brake. • Place attachment clutch in “DISENGAGED” position. • Turn ignition key to “STOP” and remove key. •...
  • Page 22 SERVICE AND ADJUSTMENTS TO LEVEL MOWER • If adjustment is necessary, see steps in Visual Adjust- ment instructions above. Make sure tires are properly inflated to the PSI shown on • Recheck measurements, adjust if necessary until both tires. If tires are over or under inflated, it may affect the sides are equal.
  • Page 23 SERVICE AND ADJUSTMENTS TO CHECK BRAKE TO REPLACE MOTION DRIVE BELT (See Fig. 39) If tractor requires more than five (5) feet to stop at highest speed in high est gear on a level, dry concrete or paved Park the tractor on level surface. En gage parking brake. surface, then brake must be serviced.
  • Page 24 SERVICE AND ADJUSTMENTS TO START ENGINE WITH A WEAK BATTERY REPLACING BATTERY (See Fig. 42) (See Fig. 41) WARNING: Do not short battery ter mi- nals by allowing a wrench or any other WARNING: Lead-acid batteries gen- object to contact both terminals at the er ate ex plo sive gases.
  • Page 25 SERVICE AND ADJUSTMENTS ENGINE TO REPLACE HEADLIGHT BULB • Raise hood. TO AD JUST THROTTLE CON TROL CABLE • Pull bulb holder out of the hole in the backside of the grill. The throttle control has been preset at the factory and ad just ment should not be necessary.
  • Page 26: Storage

    STORAGE Immediately prepare your tractor for storage at the end ENGINE of the season or if the tractor will not be used for 30 days or more. FUEL SYSTEM IMPORTANT: IT IS IMPORTANT TO PREVENT GUM DEPOSITS WARNING: Never store the trac tor with FROM FORMING IN ES SEN TIAL FUEL SYSTEM PARTS SUCH gas o line in the tank inside a building AS CARBURETOR, FUEL FIL TER, FUEL HOSE, OR TANK...
  • Page 27: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE CORRECTION 1. Out of fuel. 1. Fill fuel tank. Will not start 2. Engine not “CHOKED” properly. 2. See “TO START ENGINE” in Operation section. 3. Engine flooded. 3. Wait several minutes before attempting to start. 4. Bad spark plug. 4.
  • Page 28 TROUBLESHOOTING PROBLEM CAUSE CORRECTION Engine continues to 1. Faulty operator-safety presence control 1. Check wiring, switches and connections. If not run when operator system. corrected, contact an authorized service center/ department. leaves seat with attachment clutch CAUTION: DO NOT operate machine until engaged problem is corrected.
  • Page 30: Limited Warranty

    LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in mate- rials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
  • Page 31: Español

    REGLAS DE SEGURIDAD Prácticas de Operación Seguras para las Segadoras Conducibles PELIGRO: ESTA MAQUINA CORTADORA ES CAPAZ DE AMPUTAR LAS MANOS Y LOS PIES Y DE LANZAR OBJETOS. SI NO SE OBSERVAN LAS INSTRUCCIONES DE SEGURIDAD SIGUIENTES SE PUEDEN PRODUCIR LESIONES GRAVES O LA MUERTE. •...
  • Page 32 REGLAS DE SEGURIDAD Prácticas de Operación Seguras para las Segadoras Conducibles III. NIÑOS • Si se vierte carburante sobre la ropa, cambiarse la ropa inmediatamente. • Nunca llenar el depósito más de lo debido. Volver a colocar ADVERTENCIA: LOS NIÑOS PUEDEN SUFRIR DA- el tapón del gas y cerrar de modo firme.
  • Page 33: Especificaciones Del Producto

    ESPECIFICACIONES DEL PRODUCTO FELICITACIONES por la compra de su tractor. Ha sido diseñado, planificado y fabricado para darle la mejor confiabilidad y el mejor Capacidad y Tipo 3 Galones (11,35 L) rendimiento posible. de gasolina: Regular Sin Plomo En el caso de que se encuentre con cualquier problema que no SAE 30 (Sobre 32°F/0°C ) Tipo de Aceite: pueda solucionar fácilmente, haga el favor de ponerse en con-...
  • Page 34 PIEZAS SIN MONTAR Segadora Rueda Delantera De La Segadora (2) Conjunto de eslabones de levantamiento (5) 1-3/16” (1) Perno traseros Arandela (1) 1-1/4” Arandela (1) Abrazadera pequeño de retención (1) Eslabones de levantamiento (1) 3/8-16” delanteros (1) Rueda Tuerca (5) Abrazadera grande de retención Si Los Tiene (1) Barra Antioscilación...
  • Page 35: Montaje

    MONTAJE Su tractor nuevo ha sido montado en la fábrica con la excepción de aquellas partes que no se han montado por razones de envío. Para asegurarse que su tractor funcione en forma adecuada y segura todas las partes y los artículos de ferretería que se monten tienen que ser apretados en forma segura.
  • Page 36 MONTAJE 4. DESLICE LA CORTADORA DE CÉSPED DEBAJO DEL TRACTOR (Vea Fig. 8) PALANCA DE • Lleve la correa hacia adelante y verifique que su trayectoria LEVANTAMIENTO sea correcta en todos los surcos de la polea de la cortadora de césped. NOTA: asegúrese de que los brazos de suspensión lateral de la cortadora de césped (A) estén orientados hacia adelante antes de deslizar la cortadora de césped debajo del tractor.
  • Page 37 MONTAJE 7. INSTALE LOS ESLABONES DE LEVANTAMIENTO TRA- UBICACIÓN ESCUADRA DE SEROS (C) (Vea Fig. 13) DE LA BARRA TRANSEJE (T) ANTIBALANCEO (S) • Inserte el extremo de varilla del eslabón de levantamiento UBICADA ENTRE trasero (C) dentro del agujero (U) en el brazo de suspensión LAS RUEDAS del eje de levantamiento del tractor y haga oscilar el eslabón hacia abajo hacia la cortadora de césped.
  • Page 38 MONTAJE 9. INSTALE LA CORREA EN LA POLEA DEL EMBRAGUE ✓ DEL MOTOR (M) (Vea Fig. 7 & 15) LISTA DE REVISIÓN • Desenganche la varilla tensora de la correa (K) de la escuadra ANTES DE OPERAR Y DE DISFRUTAR DE SU TRACTOR de bloqueo (L).
  • Page 39: Operación

    OPERACIÓN Estos símbolos pueden aparecer sobre su tractor o en la literatura proporcionada con el producto. Aprenda y comprenda sus significados.
  • Page 40 OPERACIÓN FAMILIARICESE CON SU TRACTOR LEA ESTE MANUAL DEL DUEÑO Y LAS REGLAS DE SEGURIDAD ANTES DE OPERAR SU TRACTOR Compare las ilustraciones con su tractor para familiarizarse con las ubicaciones de los diversos controles y ajustes. Guarde este manual para referencia en el futuro.
  • Page 41 OPERACIÓN La operación de cualquier tractor puede hacer que salten objetos extraños dentro de sus ojos, lo que puede producir daños graves en éstos. Siempre use anteojos de seguridad o pro tec cio nes para los ojos mientras opere su tractor o cuando haga ajustes o reparaciones. Recomendamos gafas de seguridad o una máscara de visión amplia de seguridad usada sobre las gafas.
  • Page 42 OPERACIÓN PARA AJUSTAR LAS RUEDAS CALIBRADORAS (Vea Fig. 22) Las ruedas calibradoras están bien ajustadas cuando se en- cuentran un poco a distancia del terreno al mismo tiempo que la segadora esté a la altura de corte deseada. Entonces las ruedas calibradoras mantienen el conjunto segador en posición para prevenir el corte raspeo en casi todos los terrenos.
  • Page 43 OPERACIÓN FUNCIONAMIENTO ATRÁS (ROS) PARA TRANSPORTAR (Vea Fig. 25) Tu tractor está equipado con el Sistema de Funcionamiento Atrás Cuando empuje o arrastre su tractor asegúrese de desenganchar (ROS). Cualquier tentativa del operador de viajar marcha atrás la transmisión poniendo el control de la rueda libre en la posición con el embrague puesto apagará...
  • Page 44 OPERACIÓN ANTES DE HACER ARRANCAR EL MO TOR PARA HACER ARRANCAR EL MOTOR (Vea Fig. 16) Al hacer arrancar el motor por la primera vez o si se ha acabado REVISE EL NIVEL DE ACEITE DEL MOTOR el combustible del motor, se necesitará tiempo para el arranque El motor de su tractor se envía de fábrica ya lleno con aceite de extra para mover el combustible desde el estanque hasta el motor.
  • Page 45 OPERACIÓN CONSEJOS PARA SEGAR • NO use cadenas de llanta cuando la carcasa de la cortadora de césped esté colocada en el tractor. • La segadora debe estar nivelada en forma adecuada para obtener el mejor rendimiento al segar. Vea “PARA NIVELAR LA CAJA DE LA SEGADORA”...
  • Page 46: Tabla Del Mantenimiento

    MANTENIMIENTO ANTES DE CADA CADA CADA CADA CADA PROGRAMA DE MANTENIMIENTO ALMACENAMIENTO CADA USO 8 HORAS 25 HORAS 50 HORAS 100 HORAS TEMPORADA Revisar la operación del freno Revisar la presión de las llantas Verificar la sistemas presencia del operador y sistemas "ROS" Revisar si hay sujetadores sueltos Afilar/cambiar las cuchillas de la segadora Tabla de lubricación...
  • Page 47 MANTENIMIENTO TRACTOR CUIDADO DE LA CUCHILLA Para obtener resultados óptimos, las cuchillas de la cortadora Siempre observe las reglas de seguridad cuando dé mante ni- deben estar afiladas. Reemplace las cuchillas que estén gastadas, mien to. dobladas o dañadas. OPERACIÓN DEL FRENO PRECAUCIÓN: Usar solamente la hojas de Si el tractor necesita más de cinco (5) pies para detenerse repuesto aprobada por el fabricante de su...
  • Page 48 MANTENIMIENTO CORREAS "V" • Abra la válvula de desagüe empujando hacia dentro y dando vuelta a la izquierda. Revise las correas "V" para verificar si existe deterioro y desgaste • Para abrirse, tire hacia fuera la válvula de desagüe. después de 100 horas de operación y cámbielas si es necesario. •...
  • Page 49 MANTENIMIENTO PUERTO DE LAVADO DE LA CUBIERTA SILENCIADOR (Vea Fig. 32) Inspeccione y cambie el silenciador corroído y el amortiguador La plataforma del tractor está equipada con un puerto de lavado de chispas (si viene equipado) pues pueden crear un peligro de como parte del sistema de lavado de la plataforma.
  • Page 50: Servicio Y Ajustes

    SERVICIO Y AJUSTES ADVERTENCIA: PARA EVITAR LESIÓNES SERIAS, ANTES DE DAR CUALQUIER SERVICIO O DE HACER AJUSTES: • Presione el pedal de freno completamente y aplique el freno de estacionamiento. • Aseguráis que el transmisión en la posición de neutro. •...
  • Page 51 SERVICIO Y AJUSTES PARA NIVELAR LA SEGADORA • Vuelva a verificar las medidas y ajuste nuevamente, en caso necesario, hasta que ambos lados queden iguales. Asegúrese de que los neumáticos estén inflados a la PSI que se indica en estos. Si están demasiado inflados o poco AJUSTE DE DELANTE A ATRÁS (Vea Fig.
  • Page 52 SERVICIO Y AJUSTES CONTROLAR Y AJUSTAR EL FRENO PARA REEMPLAZAR LA CORREA DE TRANSMISIÓN Si el tractor exige más de cinco (5) pies para pararse a una velo- (Vea Fig. 39) cidad más alta en el cambio más alto en una superficie nivelada Estacione el tractor en una superficie nivelada.
  • Page 53 SERVICIO Y AJUSTES PARA HACER ARRANCAR EL MOTOR CON UNA REEMPLAZAR LA BATERIA (Vea Fig. 42) BATERÍA BAJA (Vea Fig. 41) ADVERTENCIA: No haga cortocircuito con los terminales de la batería al permitir que una ADVERTENCIA: Las baterías de ácido- llave de tuerca o cualquier otro objeto entre plo mo generan gases explosivos.
  • Page 54 SERVICIO Y AJUSTES MOTOR PARA CAMBIAR LA BOMBILLA DE LA LUZ DEL- ANTERA PARA AJUSTAR EL CABLE DE CONTROL DE LA • Levante el capota. ACELERACIÓN • Tire el sujetador de la bombilla fuera del agujero en la parte El control de la aceleración ha sido preajustado en la fábrica y no trasera del enrejado.
  • Page 55: Almacenamiento

    ALMACENAMIENTO MOTOR Inmediatamente prepare su tractor para el almacenamiento al final de la temporada o si el tractor no se va a usar por 30 días o más. SISTEMA DE COMBUSTIBLE IMPORTANTE: Es important evitar que se forman depositos Advertencia: Nunca almacene el tractor con de goma en partes fundamentales del sistema de combus-tible gasolina en el estanque dentro de un edificio tales como el carburador, el filtro del com bus ti ble, la manguera...
  • Page 56: Identificación De Problemas

    IDENTIFICACIÓN DE PROBLEMAS PROBLEMA CAUSA CORRECCIÓN No arranca Sin combustible. Llene el estanque de combustible. Motor sin la “ESTRANGULACIÓN” (CHOKE) Vea “PARA HACER ARRANCAR EL MOTOR” en la sec- adecuada. ción de operación. Motor ahogado. Espere varios minutos antes detratar de arrancar. Bujía mala.
  • Page 57 IDENTIFICACIÓN DE PROBLEMAS PROBLEMA CAUSA CORRECCIÓN El motor continúa Sistema de control que exige la presencia del Revise el alambrado, los interruptores y la conexiones.Si operador –seguridad fallado. no están correctas, pongase en contacto con un centro funcionando cuando de servicio cualificado. el operador se baja del asiento con el PRECAUCIÓN: NO opere la máquina sino hasta haber...
  • Page 59: Garantía

    GARANTÍA LIMITADO El fabricante le garantiza al comprador consumidor original que este producto no tendrá defectos en los materiales ni en la mano de obra. Le repararemos o reemplazaremos, a nuestra opción, cualquier pieza que encontremos defectuosa a causa de los materiales o mano de obra, sin incluir los costos de las piezas o de mano de obra incurridos en el reemplazo de las piezas y durante un período de dos (2) años desde la fecha de compra del comprador consumidor original.
  • Page 60 01.31.13 TH Printed in U.S.A.
