Your dishwasher has been checked
thoroughly in the factory to ensure that it
is in working order. This may cause
small water stains. These will disappear
after the first wash cycle.
max. 60 kg
220–240 V, 50 Hz or 60 Hz
10/16 A (UK 13A)
switched off 0.1 W
not switched off 0.1 W
at least 0.05 MPa (0.5 bar), maximum
1 MPa (10 bar). At a higher water
pressure: connect pressure-reducing
minimum 10 litres/minute
cold water; hot water max. temperature
Installation and connection
The required installation dimensions can
be found in the installation instructions.
Level the appliance with the aid of the
height-adjustable feet. Ensure that the
appliance is situated securely on the
A built-under or integrated appliance
which is installed subsequently as a
free-standing appliance must be
secured to prevent it from
overturning, e.g. by screwing it to the
wall or by installing it under
a continuous worktop which is
screwed to adjacent cupboards.
The appliance can easily be
installed in a fitted kitchen between
wooden and plastic walls.
1. The required work sequence can be
found in the installation instructions.
If required, fit a siphon with an
2. Connect the waste-water hose to the
drainage connection of the siphon
with the enclosed parts.
Ensure that the drainage hose is not
kinked, crushed or twisted and that
there is no cover plate in the
drainage to prevent the waste water
from flowing out!
