Specifications

[Recording unit]
Channels
Input impedance
Maximum output voltage
Output impedance
Amplification
Low-cut filter
(PC control, Stimulation 64 CH switch)
Frequency range (low-cut: 0.1 Hz)
Internal noise
[Stimulus unit]
Channels
with variable dial (V)
without variable dial (F)
Amplification adjustment
Maximum output voltage
Maximum output amplitude
with variable dial (V)
without variable dial (F)
[General]
Power requirement
Power consumption
Weight
Dimensions
Specifications may not be satisfied depending upon the type of computer or operating environments used.
Only for use in animal studies research.
Specifications and external appearance are subject to change without notice.
64
> 10 MΩ
+/- 12 Vp
150 Ω
1000 times (1 mV/V, 60 dB)
4 mode: 0.1, 1, 10 and 100 Hz
0.1 Hz to 10 kHz, +0 dB to -3 dB
< 10 mV (signal source impedance: 50 kΩ)
2
2
0 to 10 times (in 0.1 steps)
+/- 12 Vp
2 mAp
2 mAp
AC 120V, 60 Hz
33 W
13.0 kg
W 483 x H 186 x D 430 mm
9
October, 2005
