CAUTION: THESE INSTRUCTIONS MUST
REMAIN WITH THE HOMEOWNER.
WARNING: IF THE INFORMATION IN THESE
INSTRUCTIONS IS NOT FOLLOWED ExACTLY,
A FIRE OR ExpLOSION MAY RESULT CAUSING
pROpERTY DAMAGE, pERSONAL INJURY OR
LOSS OF LIFE.
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call you gas supplier from a
neighbor's phone. Follow the gas supplier's
instruction.
• If you cannot reach your gas supplier, call
the fire department.
– Installation and service must be performed
by a qualfied installer, service agency or
the gas supplier.
– In the Commonwealth of Massachusetts,
a carbon monoxide (CO) detector shall
be installed in the same room as the
appliance.
Installation and

Operation Instructions

ATTENTION : CES INSTRUCTIONS DOIVENT
DEMUERER AVEC LE pROpRIéTERE D'UNE
MAISON.
AVERTISSEMENT: ASSUREZ-VOUS DE bIEN
SUIVRELES INSTRUCTIONS DONNéES DANS
CETTE NOTICE pOUR RéDUIRE AUNINIMUM
LE RISQUE D'INCENDIE OU D'ExpLOSION OU
pOUR éVITER TOUT DOMMAGE MATéRIEL,
TOUTE bLESSURE OU LA MORT.
– Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables
dans le voisinage de cet appareil ou de tout
autre appareil.
– QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
• Ne pas tenter d'allumer l'appareil.
• Ne touchez à aucum interrupteur. Ne
pas vous servir des téléphones se trou-
vant dans le bâtiment où vous trouvez.
• Appelez immédiatement votre fournis-
seur de gaz depuis un voisin. Suivez les
instructions du fournisseur.
• Si vou ne pouvez rejoindre le fournis-
seur de gaz, appelez le service des incend-
ies.
– L'installatione l'entretien doivent être
assurés par un installateur ou un service
d'entretien qualifié ou par le fournisseur
de gaz.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GI 350 DV Scan 65i and is the answer not in the manual?

Questions and answers

Summary of Contents for Jøtul GI 350 DV Scan 65i

  • Page 1: Operation Instructions

    Installation and Operation Instructions ATTENTION : CES INSTRUCTIONS DOIVENT CAUTION: THESE INSTRUCTIONS MUST DEMUERER AVEC LE pROpRIéTERE D’UNE REMAIN WITH THE HOMEOWNER. MAISON. AVERTISSEMENT: ASSUREZ-VOUS DE bIEN SUIVRELES INSTRUCTIONS DONNéES DANS WARNING: IF THE INFORMATION IN THESE CETTE NOTICE pOUR RéDUIRE AUNINIMUM INSTRUCTIONS IS NOT FOLLOWED ExACTLY, LE RISQUE D’INCENDIE OU D’ExpLOSION OU A FIRE OR ExpLOSION MAY RESULT CAUSING...
  • Page 2: Installation & Service Tools

    pLEASE READ THESE INSTRUCTIONS IN THEIR ENTIRETY AND MAKE THEM AVAILAbLE TO ANYONE USING OR SERVICING THIS AppLIANCE. This producT musT be insTalled by a licensed masTer or journeyman plumber or gas-fiTTer when insTalled in The com- monwealTh of massachuseTTs. We recommend that our gas products be installed and serviced by professionals who...
  • Page 3: Table Of Contents

    Table of Contents Installation & Service Tools ..2 Unpacking the Fireplace Specifications ........4 General Information ......5 1. The Log Set is packaged inside the firebox. Remove Safety Information ......6 the Glass Panel Frame to unpack the firebox: Installation •...
  • Page 4: Specifications

    Jøtul GI 350 DV / Scan 65i Direct Vent Gas Fireplace Manufactured and Distributed by: Jøtul AS Fredrikstad, Norway Jøtul North America Gorham, Maine USA MEA 430-07-E Accessories Test Standards This appliance complies with Basket Screen ....#156416 (for Cast Iron Double Doors) National Safety standards and Reversible Brick Panel Kit, ..
  • Page 5: General Information

    General Information lished in the National Fuel Code, ANSI Z223.1.(NFPA 54). In Canada, the codes have been established in CAN/CGA B149 Fuel Installation Code. THIS HEATER MUST bE INSTALLED AND Installer l’appareil selon les codes ou reglements MAINTAINED bY A QUALIFIED SERVICE AGENCY. locaux, ou, en l’absence de tels reglements, selon DO NOT ATTEMpT TO ALTER OR MODIFY les Codes d’installation CAN/CGA-B149.
  • Page 6: Safety Information

    Safety Information The blower is supplied with a three-prong (ground-  ing) plug for protection against shock hazard and should be connected directly into a properly Due to the high operating temperatures, this ap-  grounded three-prong receptacle. DO NOT CUT pliance should be located out of traffic and away OR REMOVE THE GROUNDING pRONG FROM THE from furniture, draperies, etc.
  • Page 7: Installation Fireplace Requirements

    ��� ������� �� ������ ��� �� ��� ������� ������ ��� ������ ������� ������� ������� ��� ������� ������ ������ ���� ����������� ������� Figure 2. Jøtul GI 350 DV / Scan 65i dimensions. Minimum Fireplace Requirements The Jøtul GI 350 DV gas insert has been specifically �...
  • Page 8: Hearth Protection

    Clearance to Combustible Materials Fireplace Facing Options A combustible material is anything that can burn (i.e. sheet rock, wallpaper, wood, fabrics etc.). Jøtul Cast Iron Surround - 34 1/2” x 24 1/2” These surfaces are not limited to those that are vis- w/ Plinth - 34 1/2”...
  • Page 9: Vent Guidelines

    Vent Guidelines Mantel Clearance Requirements • All vent components must be installed in accor- dance with the listing terms and manufacturer’s instructions. • Vent Height: Measured from the top of the insert to the top of the termination cap. ������ ����...
  • Page 10: Masonry Fireplaces

    Masonry Fireplaces Masonry Fireplace Vent Installation A solid-fuel fireplace chimney must be clean and in good working order. It must be constructed of no- 1. Measure height of the chimney to fireplace open- combustible materials. Chimney clean-outs must fit ing. Determine if both the intake and exhaust will properly.
  • Page 11: Prefabricated Fireplaces

    prefabricated (Factory-built) Exhaust Fireplaces Listed, Standard Intake This appliance may be installed into a prefabricated or High-Wind fireplace listed per UL 127 or ULC S610.The chimney Termination Cap must be clean and in good working order. It must be constructed of noncombustible materials. Chimney clean-outs must fit properly.
  • Page 12 GAS VENT RULE IMpORTANT: bEFORE STARTING THIS INSTALLATION, THE GAS Minimum Height Roof Slope From Roof SUppLY LINE MUST bE INSTALLED TO THE FIREbOx. THIS SHOULD ONLY bE DONE bY A QUALIFIED OR Flat to 6/12 1’0” 0.3M LICENSED pLUMbER OR GAS FITTER. Over 7/12 to 9/12 2’0”...
  • Page 13: Vent Requirements

    Vent Connection prefabricated Fireplace Vent Installation 1. Measure height of the chimney to fireplace open- The Vent Collar Plate, located on top of the cabinet, ing. Determine if both the intake and exhaust will is removable to ease connection of the vent liners in be extended to the top of the chimney.
  • Page 14: Fireplace Assembly Gas Connection

    Connecting the Gas Supply Final positioning 1. blower power Cord: Gas Supply Requirements Extend the blower power cord out forward of the ALL INSTALLATIONS MUST COMpLY WITH LOCAL fireplace, routing it to the nearest power source. CODE OR IN THE AbSENCE OF LOCAL CODE, MUST .
  • Page 15: Gas Pressure

    Soap Solution Leak Test The appliance must be isolated from the gas sup- ply line by closing its individual manual gas shut-off • Mix a 50-50 solution of water and dish soap. valve (gas cock) during any pressure testing of the gas •...
  • Page 16: Fuel Conversion

    Fuel Conversion Conversion Kit Contents: #1 - Lp #1 - NG The Jøtul GI 350 Fireplace is designed to for use with • 1 Regulator Tower labeled for the appropriate fuel either Natural gas or Propane. It is shipped from the •...
  • Page 17 . Replace the burner Assembly: Slide the venturi tube into the Air Shutter and engage the tube Burner Orifice fully over the orifice. The burner should engage with the three support brackets on the floor of the firebox. Properly located, the burner will be level and locked into correct alignment with the pilot assembly as in fig.
  • Page 18: Wall Thermostat

    Remote Control CAUTION: LAbEL ALL WIRES pRIOR TO DISCON- The optional Jøtul Remote Control 129706 may be NECTION WHEN SERVICING THE CONTROLS. WIR- installed in place of the factory-installed manual ING ERRORS CAN CAUSE IMpROpER AND DAN- Burner switch. GEROUS OpERATION. ALWAYS VERIFY pROpER 1.
  • Page 19: Optional Wall Panel Kits

    Optional brick panel Kit Assembly CAUTION: THESE pANELS ARE ExTREMELY FRAGILE! SUppORT EACH pIECE WITH bOTH HANDS AND HANDLE GENTLY. Install the optional Brick Panel Kits before installing the log set. No fasteners or tools are required. Brick panels are shown here, however, Corrugated panels install in the same way.
  • Page 20: Log Set Installation

    Log Set Assembly This is the heart of your fireplace. Much time and effort has been devoted to attaining a lively, real- istic flame picture while simultaneously achieving efficient fuel combustion and effective heat output under a variety of installation conditions. The flame picture you experience, however, will be affected by a number of variables peculiar to your installation such as venting configuration, environmental and...
  • Page 21: System Check

    System Check Flame Appearance / Air Shutter 1. pURGING THE GAS LINE: When lighting the appli- ance for the first time it will take a few moments Adjustment to clear the gas line of air. Once this purge is com- THIS FIREPLACE IS SHIPPED FROM THE FACTORY plete, the appliance will operate as described in EQUIPPED TO USE NATURAL GAS.
  • Page 22: Surround Assembly

    Surround Assembly Each of the surround assemblies and front facings is completely assembled at the factory. No further as- sembly is required. All assemblies utilize hooked brack- ets (fig. 30) that simply hang onto the inboard tabs on the fireplace cabinet as shown in fig. 10 on page 14. •...
  • Page 23: Operation

    Operation 1. Your fireplace can be operated manually using the On/Off/T-stat rocker switch or it can be automati- cally controlled using an optional wall-mounted thermostat or remote control device. A separate switch is provided for the built-in forced air blower. Familiarize yourself with the location and function of the controls.
  • Page 24: Blower Controls

    Maintenance Figure 33. GI 350 DV Burner The Jøtul GI 350 DV gas fireplace and its venting Control system should be inspected before use and at least ������ Switch. annually by a qualified service technician. �� ��� IMpORTANT: ����� ALWAYS TURN OFF THE GAS SUppLY TO THE FIREpLACE AND UNpLUG THE FORCED AIR bLOWER bEFORE ANY SERVICE WORK IS pERFORMED ON THE FIREpLACE.
  • Page 25: Glass Replacement

    Gasket Inspection Glass panel or Gasket Replacement 1. Wrap the new gasket material evenly around the It is important that the glass gasket be inspected at edge of the glass, peeling back the protective least annually. Examine the ribbon gasket for signs of strip to expose the adhesive as you go.
  • Page 26: Illustrated Part Breakdown

    Jøtul GI 350 lllustrated part breakdown �� � �� � �� � �� �� � �� � �� � �� �� � �� � �� �� � �� �� �� �� �� �� �� �� �� �� �� �� �� ��...
  • Page 27: Replacement Parts List

    Jøtul GI 350 DV part List Description part Number Description part Number Screw, Pan Head 10-32 x 3/8 117911 Heat Shield, Right 222092 Valve Bracket 221385 Screw, #8 x 1/2” Blk 117917 Screw, #8 x 1/2” Blk 117917 Glass Frame Latch Release Tool 222268 Piezo Ignitor Button 3902573...
  • Page 28: Appendix A: Remote Installation

    Appendix A Remote Control Installation The optional Jøtul Remote Control 129706 may be in- stalled in place of the factory-installed manual burner switch. Follow this procedure: Receiver 1. Remove the Burner Switch Box from the valve compartment. Remove the switch coverplate and disconnect the wires from the TH and TH/TP termi- nals under the valve.
  • Page 30: Service Log

    RETAIN THIS MANUAL FOR REFERENCE AND MAKE IT AVAILAbLE TO ANYONE USING OR SERVICING THE SERVICE LOG: FIREpLACE. Record your serial number stamped on the rating plate Name of Technician ________________________ in the valve compartment. Company Name ____________________________ MODEL NAME: Jøtul GI 350 DV Gas Fireplace Insert Date of service _____________________________ SERIAL NUMBER:_____________________________ Work Performed ____________________________...
  • Page 31: Lighting Instructions

    LIGHTING INSTRUCTIONS FOR YOUR SAFETY, READ bEFORE LIGHTING. WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS ExACTLY, A FIRE OR ExpLOSION MAY RESULT CAUSING pROpERTY DAMAGE, pERSONAL INJURY, OR LOSS OF LIFE. A. This appliance has a pilot which must be lit by hand. •...
  • Page 32 This appliance must be installed in conformance with local and national building regulations. Before beginning the installation, it is important that the these instructions be carefully read and understood. Jøtul maintains a policy of continual product development. Consequently, products may differ in specifi- cation, color or type of accessories from those illustrated or described in various publications.
