DG60-112
PANEL LAYOUT
Front Panel
Input Jack (INPUT HIGH, LOW)
Peak Indicator
Channel Select Switch
Channel Indicator
Amp Select Switch
Gain Volume (GAIN)
Master Volume (MASTER)
Tone Controls
(TREBLE, HIGH MID, LOW MID, BASS, PRESENCE)
Reverb Volume (REVERB)
Power Switch (POWER)
Rear Panel
Foot Switch (FOOT SW)
Speaker Mute Switch (SP MUTE)
Line Out/Head Phone Jack
(LINE OUT/PHONES)
Effect Send/Return Level Switch
(0 dB/-20 dB)
Effect Send Jack (EFFECT SEND)
Effect Return Jack (RETURN)
Blend Knob (BLEND)
4
