Schematic Diagram - Panasonic CW-C51LE Service Manual

Schematic Diagram

POWER SUPPLY CORD
1Φ 220-240V,50H
BROWN
COMPRESSOR
R
MAIN SWITCH (Contact at position shown)
Z
0 1
2
3
BLUE
S
YELLOW
C
Resistance of Compressor Windings and the rated
Capacitor
Connection
C -- R
C -- S
Capacitor (CWA31332)
Resistance of Fan Motor Windings and the rated
Capacitor
Connection
Blue - Yellow
Yellow - Orange
Red - Yellow
Capacitor (CWA31604MS)
BLUE
(R) Blue
2RS080D3AB02
6.79 Ω
10.90 Ω
15 µF 370 V
CWA951090
199.2 Ω
117.4 Ω
405.1 Ω
1.5 µF 400 V
- 4-
ORANGE
YELLOW
YELLOW
/GREEN
CAPACITOR
(C) Yellow
MARK
Compressor Terminal
(S) Red
