Summary of Contents for Loewe Connect

  • Page 1 Connect Connect 26 LED Operating instructions...
  • Page 2: Overview Of The Most Important Functions

    Overview of the most important functions Set operating mode Colour key function during radio operation TV operation Red button: On/Off screen Yellow button: Last selecting station Radio operation (standard assignment) The assignment of the AUDIO button can be changed (see page 87). Button functions On/Off of the television set Call MediaPortal,...
  • Page 3: Remote Control - Tv Functions

    Remote control – TV functions Functions of Loewe TV set Sound off/on ......................(page 32) LED display for current operating mode ..............(page 87) Switch over to TV mode ..................(page 20; 87) Switch over to operate recorder ................(page 87) Timer overview on/off .....................(page 85) Set picture format ....................(page 35)
  • Page 4: Acknowledgements

    Acknowledgements Printed in Germany Loewe Opta GmbH Industriestraße 11 Date of issue 11/10-2.0 TB/FP D-96317 Kronach © Loewe Opta GmbH, Kronach www.loewe.de ID: 3.9.0 All rights including translation, technical modifications and errors reserved.
  • Page 5: Table Of Contents

    Contents Overview of the most important functions ..........2 Daily operation ..................30 Select station ..................30 Remote control – TV functions ..............3 Selecting audio/video source ..............31 Adjusting the sound ................32 Acknowledgements .................. 4 Adjusting the picture ................34 Welcome ....................
  • Page 6 Service ....................110 Serial interface (RS-232C) (retrofittable) ..........83 The direct way to record ............... 84 Timer recording with external devices ........... 86 Operating Loewe equipment ..............87 Software update ..................88 Basic information .................. 88 USB stick....................88 Download ..................... 88...
  • Page 7: Welcome

    Welcome Thank you! Scope of delivery Loewe stands for the highest demands in technology, design and user LCD TV set friendliness. This applies equally for TV, video and accessories. Antenna cable In addition to the elegant design and the many different possible colour...
  • Page 8: For Your Safety

    For your safety For your own safety and to prevent unnecessary damage to your device, Power supply read and comply with the following safety instructions: The wrong voltage can damage the set. This equipment must only be connected to a mains power supply which has the same voltage and Proper use and environmental conditions frequency as that specified on the rating plate.
  • Page 9 Clean the TV set, the screen, and the remote control unit with a soft, Only use original accessories such as Loewe stands if possible (see Acces- moist, and clean cloth only, without any aggressive or scouring cleaning sories on pages 97 and 100).
  • Page 10: Control Unit Front Side Of The Device

    Control unit front side of the device Functions of the operating elements Mains switch: The mains switch is located on the bottom of the set. On/Off button: Switch on from the standby mode Switch off to the standby mode Display: = Standby green = Operation...
  • Page 11: Connections Rear Side Of The Device

    Connections rear side of the device Mains cable ANT-TV - Antenna/cable analogue/digital HDMI 1 - HDMI input 1 ANT SAT - Satellite antenna (Sat tuner) HDMI 2 - HDMI input 2 RS-232C - Serial interface PC IN - VGA/XGA input CI-COMMON INTERFACE - Common Interface (CI slot) AV - Euro-AV socket USB - USB connection...
  • Page 12: Operating Convenience

    Operating convenience General information on menu operation Menu operation (example: TV menu) Menus for the individual modes (TV, Radio, PIP, EPG, Teletext and Me- The operation can be divided basically into two areas: The operation of diaPortal) are called with the MENU button. dropdown lists (e.g.
  • Page 13: Operating Convenience With Wizards

    The recording wizard helps you to programme a recoring with a VCR or DVD recorder (see page 84). Software update You can download the latest software for your TV set from the Loewe Service site and update using a USB stick (see page 88). Equipment and upgrade options, see page 99.
  • Page 14: Mediaportal

    DR archive. The menu Radio digital DR archive MediaHome item appears as soon as a network connection to a Loewe TV set with an enabled DR archive is MediaNet Index established. RECOMMENDATIONS You can find more information in the Digital- Recorder + operating instructions.
  • Page 15: The Index In The Tv Set

    Operating convenience The index in the TV set The info display The index explains the TV functions and the terms that you may be con- The info display provides an info text appropriate to the on-screen display fronted with when operating the TV set. You can start all the assistants that can assist you further with the operation of your TV set.
  • Page 16: Tv Menu - Overview Diagram

    Operating convenience TV menu – Overview diagram TV menu Recording Picture Sound Connections Settings Sound effects Stations Picture adjustment Recording wizard Sound components Search wizard Contrast Sound adjustment Timer list Antenna DVB Manual adjustment Headphone volume Pre-record time AV connecting settings Colour intensity Change stations Loudness...
  • Page 17: Radio Menu - Overview Diagram

    Operating convenience Radio menu – Overview diagram Radio menu Stations Sound Timer functions Sound effects Search wizard Switch off once Sound adjustment Manual adjustment Switch off daily Headphone volume Change stations One-time alarm Loudness Select/change favourites Wake up Mon-Fri more... Wake up Sat Wake up Sun Auto volume...
  • Page 18: Initial Installation

    Initial installation Installing the TV set Installation notes Choose a place for installing your TV where no bright light or sunlight shines directly onto the screen. This could cause reflections which impair the picture. 3 times the screen diagonal can be taken as a guide value or the viewing distance (for 26-inch set approx.
  • Page 19: Connecting The Tv Set

    Initial installation Connecting the TV Set Connecting the TV set to the Home network You can connect your TV set to the home network by a wired connection Connecting to the mains (Ethernet, Powerline). Please contact your specialist dealer for more information on Powerline.
  • Page 20: Preparing The Remote Control Unit

    Push the cover back on from below after inserting the batteries. Adjusting the remote control for operating the TV set Press the TV button. See page 87 for how to operate other Loewe appliances and how to reprogramme the remote control buttons. - 20...
  • Page 21: Turning The Set On/Off

    Initial installation Turning the set on/off Switching the set on with the remote control Press the on/off button Switching the TV set to standby mode Press the mains switch on the bottom right of the set. The display in the control panel on the front lights up first orange and numeric buttons then red.
  • Page 22: First Installation Wizard

     Select Energy efficiency. Select antenna cable. Decide how energy efficiently you want to operate Yellow button: Connect/disconnect antenna cable. your TV set. The value for the contrast (and thus the brightness of the background lighting) is adapted. Antenna/cable (analogue): analogue stations via...
  • Page 23 Initial installation Selecting DVB-S can only be selected if the set is equipped with Setting options for DVB-T reception: antennas a satellite tuner. Depending on which antenna(s) was If you have not selected a DVB-T antenna in the antenna (continued) (were) selected, the appropriate settings are called later selection: Continue with setting options for DVB-C recep- during the routine.
  • Page 24 Initial installation Setting options for DVB-C reception: Setting options for DVB-S reception: If you have not selected a DVB-S antenna in the antenna If you have not selected a DVB-C antenna in the antenna selection: Continue with Setting options for all types of selection: Continue with Setting options for DVB-S recep- reception on page 28.
  • Page 25 Initial installation Setting options for the satellite system (single satellite): Setting options for the satellite system (2 satellites on 22 kHz switchbox / 2 satellites on toneburst switch): Select single INITIAL INSTALLATION (DVB-S) Satellite satellite Select single satellite INITIAL INSTALLATION (DVB-S) selection Astra1 19,2°E Hellas Sat2 39°E...
  • Page 26 Initial installation Setting options for the satellite system Setting options for the satellite system (max. 4 satellites on DiSEqC multiswitch): (DiSEqC one cable communal system): Settings DiSEqC one INITIAL INSTALLATION (DVB-S) INITIAL INSTALLATION (DVB-S) DiSEqC cable Select DiSEqC single cable communal installation Repeat rate none multiswitch...
  • Page 27 If your set is connected to a single-cable system without Supply voltage may differ depending on the selected satellite. external voltage supply, you can connect the antenna supply (13V or 18V / max. 450mA). You can state whether coded stations are to be searched Encrypted for in the search/update.
  • Page 28 Initial installation Setting options for all types of reception: Info FIRST INSTALLATION WIZARD TV stations The automatic TV station search and sorting has ended. Favoured 966 new TV station(s) has (have) been found. INITIAL INSTALLATION signal source Favoured signal source The number of found TV stations is displayed.
  • Page 29: Positioning/Aligning Dvb-T Antenna

    Initial installation Time and date Positioning/aligning DVB-T antenna INITIAL INSTALLATION Time and date If you are receiving one or more DVB-T stations with picture and sound Time 09:19:14 Date 26.02.2010 interference then you should change the installation location and align- Proceed Back ment of the antenna.
  • Page 30: Daily Operation

    Daily operation Select station Select station with the station list InterActive ➠ In normal TV operation, without further displays, no Select station with P+ / P– favourites selected: P+/P– Station up/down. OK Call Station list. The status display with station title, progress bar, time and sound identification signal is shown briefly (see page 38).
  • Page 31: Selecting Audio/Video Source

    Daily operation Select station via favourites list Selecting audio/video source You can save and call your favourite stations in 6 favourites lists (e.g. for Select the AV source via the AV selection multiple users). Each favourites list can contain up to 99 stations. After ➠...
  • Page 32: Adjusting The Sound

    Daily operation Adjusting the sound Explanations of the sound settings: Sound via Playback over the TV speakers or an external hi-fi amplifier. Switching sound off/on The menu item Sound via only appears if HiFi/AV amplifier Sound off. or TV speakers (switchable) is set in the audio components Sound on: Press button again or set volume V+.
  • Page 33 Daily operation Explanations of the sound settings: more ... Loudspeaker/ Selection possibility Mono/Stereo or Sound 1 or Sound Headphone 2 for two-sound broadcasts separately for speakers and sound headphones. Only available for analogue stations. Auto Volume Reduces volume differences, e.g. for advertisements that are too loud.
  • Page 34: Adjusting The Picture

    Daily operation Adjusting the picture Presettings / Personal settings for picture adjustment MENU: Call TV menu. MENU: Call TV menu.  Select Picture,  Select Picture,  go to the menu line below.  go to the menu line below.  Select Picture adjustment,  go to the menu line below.
  • Page 35 Daily operation Selecting the picture format Move picture vertically InterActive ➠ In normal TV mode without other displays. Press the Picture format button until the desired picture format is set or press Move picture up/down. Picture format Bild vert. verschieben Move picture up/down Panorama Cinema...
  • Page 36: Button Functions

    Daily operation Button functions Coloured buttons in TV mode (continuation) Green button: Open the Teletext functions menu. Every operating mode of the TV set (TV, Radio, MediaPortal, Teletext, EPG and PIP) has its own menu and own functions for the coloured buttons. TELETEXT FUNCTIONS The function of the coloured buttons is shown at the bottom of the menus btitles...
  • Page 37: Operation Without Remote Control

    Daily operation Permanent display of time Operation without remote control Press twice in rapid succession: Changing the station on the TV set Time is shown/hidden permanently. + / – Station up/down. Switching radio on or off or switching to radio Radio on or switch between TV and Radio.
  • Page 38: Status Display

    Daily operation Status display Explanations of the symbols for sound identification/display: Transmitted audio signal: ➠ In normal TV mode, without other displays. Mono audio transmission analogue Mono INFO: Show status display. Two-sound transmission (Sound1/Sound2) analogue 2-sound Stereo Stereo sound transmission analogue  'DV (UVWH 6WHUHR ...
  • Page 39 Daily operation Selection possibilities for DVB stations Other setting options for DVB stations In the status display additional selection possibilities can be offered for You can make general presettings for DVB stations under TV menu specific programmes depending on the DVB programme provider. Settings Miscellaneous DVB settings.
  • Page 40: Managing Stations

    Managing stations TV stations Explanations of some search settings: Set location Select the country for country-specific defaults and Various options for managing stations are available via the TV menu. For example the description for TV stations. For radio stations the same ap- station sorting.
  • Page 41 Managing stations Search for/update stations – handling of new and no longer found stations Search/update station – manual search / settings ➠ If you want to adapt the parameters of an existing station, first select The number of new stations found is displayed after the automatic search/ update has been completed.
  • Page 42 Managing stations Rename station Change, delete, move, rename, restore station ➠ Change station can also be called via the station list (page 30). ➠ DVB stations for which the station name is also broadcast ➠ If at least one station is locked the access code must cannot be renamed.
  • Page 43: Put Together / Change Favourites Lists

    Managing stations Put together / change favourites lists Add station to favourites list ➠ All stations (left column) must be selected. Each favourites list can contain up to 99 stations. You can put together If not, change the list with . the favourites lists to suit your requirements (e.g.
  • Page 44: Picture In Picture

    Picture in Picture Picture in Picture ( PIP) Starting and ending PIP mode The concurrent display of two different images is referred to as Picture Show/hide PIP. in Picture. Select the PIP picture A green frame around the PIP picture indicates that the station selection affects the PIP picture.
  • Page 45: Configure Picture In Picture (Pip) Mode

    Picture in Picture Configure Picture in Picture (PIP) mode Switch PIP Type ( Small PIP / Split screen) ➠ PIP menu is opened. You can set different parameters for the picture in picture mode in the PIP menu. Sie können wählen, ob Sie Ihr Zweitbild als überblendetes Kleinbild oder als Open the PIP menu ein die rechte Schirmhälfte füllendes Bild ("Split Screen") sehen wollen.
  • Page 46: Electronic Programme Guide

    Electronic Programme Guide Electronic Programme Guide – EPG Adjusting the programme list InterActive ➠ The selection is at the top of the specifications, EPG stands for Electronic Programme Guide and provides you with if not, press the blue button. on-screen programme details. With the system, as with a printed pro- gramme guide, you can learn about the current programme.
  • Page 47: Configuring Epg

    Electronic Programme Guide Paging through the programme list Configuring EPG P+/P– Page backwards / forwards. Start the EPG menu In the entries for Date and Time, you will see changes in ➠ EPG mode is started, time as well as in date when paging. Scrolling in the if not, press the EPG button.
  • Page 48: Teletext

    Teletext Teletext InterActive Additional page selection possibilities Your TV set supports the two operating systems TOP Text and FLOF. 1st possibility: Up to 2,000 pages are stored so that you have quick access . Call overview page 100. Starting and ending Teletext 2nd possibility: Switch Teletext on / off.
  • Page 49: Teletext Menu

    Teletext Programming timer recordings via Teletext Teletext menu ➠ Teletext is started, In the Teletext menu you can activate messages, reveal pages and con- if not, press the TEXT button. figure the teletext with the Settings menu function. Call the programme pages of the current station. Starting the Teletext menu Green button: Go to the appropriate page.
  • Page 50: Interactive Data Services

    Teletext Digital radio Interactive data services Radio mode InterActive ( Digital teletext/MHEG-5) The TV set can receive digital radio stations over DVB or over the internet. In addition you can play the sound from an external device through the TV set via the audio/AV inputs of the TV set (see page 51). In some countries, the stations also transmit interactive data services with ➠...
  • Page 51: Epg - Electronic Programme Guide (Radio)

    Connecting an external appliance (e.g. MP3 player) The LED display on the TV set (see page 10) changes from Connect the output (jack) of the MP3 player to the cinch audio in sockets green to orange. L/R (white/red) of the TV set.
  • Page 52: Other Settings

    Other settings Parental lock Explanations of setting possibilities in the Parental lock menu: Lock all The TV set is locked immediately the menu is exited. All You can select and set various security options to prevent unauthorised use stations programmes can then only be watched after entering the of the TV set and to protect your children from unsuitable programmes.
  • Page 53: Timer Functions

    Other settings Timer functions Explanations of setting possibilities in the Timer functions menu: This menu offers you convenient alarm services. Programmed alarms are Wake up Specify whether the TV set switches on in the event of an also active when the TV set has been switched off to standby. with alarm from the standby mode in TV or radio mode with If the TV set switches on from the standby mode by alarm, a screen...
  • Page 54: On-Screen Displays

    Other settings On-screen displays Time and date You can select different settings in this menu which affect the on-screen If you receive a station with teletext after switching on the TV, the time displays. and date are recorded automatically. The date may have to be entered manually for some stations.
  • Page 55: Coded Stations

    The CA module and the Smart Card are not part of the TV set’s scope MENU: Call TV menu. of delivery. They are usually available from your dealer. Loewe does not provide any guarantee for the functioning of the CA module.
  • Page 56: Media

    Media menu (see page 58). MediaUpdate - additional functions Your Loewe TV set supports the UPnP AV standard for data playback in Additional functions in the MediaPortal are planned, particularly for Loewe the home network. You can find more detailed information on this in Media + .
  • Page 57: Accessing Your Media

    Media + Accessing your media Playing music and videos, displaying images The windows for playing music and videos and for displaying photos are comparable for all cases irrespective of the media source. The relevant MEDIA: Call MediaPortal. players are therefore grouped together: MEDIA PORTAL MediaMusic (including Internet radio): see page 70.
  • Page 58: Media Menu

    Media + Media menu Explanation of the setting possibilities in Network settings menu Network You can activate or deactivate the network settings of The Media menu is used for making settings to your network adapter access your TV set here. and the various types of media (photo, music, video).
  • Page 59 Media + Configuration of the built-in LAN adapter Explanation of the adapter settings: You will see an overview of the current settings for the The current assignment method for the IP address of selected network adapter (for an explanation of the points, configuration your TV set.
  • Page 60 Media + Explanation of the setting possibilities in Network settings menu (continued) Other This menu contains settings which have to be changed less frequently. MEDIA MENU Network settings access Other Network  Select Other, OK call further networking settings.  Select desired setting,  or numeric buttons: Perform changes.
  • Page 61 Media + Explanation of the setting possibilities in the Photo settings menu ➠ The menu can only be opened when a photo is displayed (see page 72). Go to ... Skip to a definite picture or to the start/end of the cur- rent folder.
  • Page 62: Mediahome

    Media + MediaHome MediaCenter A Loewe MediaCenter connected to your home network. TwonkyMedia Examples with media servers in your home network. The MediaHome includes both storage media directly connected to the TV WMP11 exact designation depends on the media server used.
  • Page 63 Media +  Select media file (example below: music title). General navigation in the media overview OK Play/display selected media file.  Select desired folder. LOEWE_USB (USB) Album Title Ammonia Avenue Prime Time Let Me Go Home LOEWE_USB (USB) Eye In The Sky One Good Reason Music Titles...
  • Page 64 Media + Playing/displaying data from USB storage media Playing files from the home network If a USB storage medium is selected as a source (see page 62), the following When using a media server in your home network as a source (see page 62), special features apply for actions and the media overview: the names of the folders displayed are specified by the media server.
  • Page 65: Medianet

    Personal area Settings The upper section of the MediaNet basis dialog contains Loewe Recommendations. The middle section displays your own Favourites (Edit favourites, see page 68). Depending on the topic selected (see right column), all the available online content matching the topic is displayed in the lower section.
  • Page 66 Media + Internet Navigation in websites Green button: Call Internet. P+/P– Scroll the page vertically. MEDIA NET - INTERNET  Select link or text input field, www.loewe.de| www. .org .com .net HISTORY OK open link or confirm text input. www.loewe.de <...
  • Page 67 It appears encrypted  Select Favourites entry, (****) when entering for security reasons. OK transfer the Internet address to the input line. MEDIA NET - PERSONAL AREA OK View the website. www.loewe.de| www. .org .com .net HISTORY www.loewe.de...
  • Page 68 Media + Edit MediaNet favourites Change the sequence of MediaNet favourites The middle section of the basic MediaNet dialogue contains the MediaNet  Select entry under Favourites. favourites. You can define and delete these favourites or change their sequence as desired. Green button: Move selected favourite.
  • Page 69 Media + MediaNet settings Here, you can find more setting options for MediaNet. ➠ MediaNet is open (page 65). Blue button: Call Settings. MEDIA NET - SETTINGS Access code Personal area Country selection You can change your access code to your personal area here. * * * * Mentions légales Back...
  • Page 70: Mediamusic

    Media + MediaMusic Play music files ➠ A music title is highlighted. ➠ A music title is highlighted in the media overview. OK Play music title. LOEWE_USB (USB) MUSIC PLAYER Albums Title "Dark Diamond" 6WHUHR Ammonia Avenue Prime Time Let Me Go Home Artist: Elton John Eye In The Sky...
  • Page 71 Media + Explanation of the symbols in the playback window The symbols at the top right show you information about the current playback. Playback Pause Rewind Fast-forward _ Replay current title Replay all titles in the current folder Random play activated The bar behind the playtime shows you how far the music file has been played.
  • Page 72: Mediaphoto

    Media + MediaPhoto Slide show PLAY button: Start slide show. ➠ from photo overview: Start slide show with marked ➠ A picture is selected in the media overview. picture. ➠ in full screen mode: Start slide show with displayed picture. LOEWE_USB (USB) Photo Loewe_1_highres...
  • Page 73: Mediavideo

    Media + MediaVideo Wind You can fast-forward/rewind videos to search for desired scenes. Rewind at double speed. ➠ A video is selected in the media overview. Press again for four times speed. Fast-forward at double speed. Press again for four times speed. LOEWE_USB (USB) Photos video1.avi...
  • Page 74: External Devices

    External devices Connections menu AV connection settings Settings for the connection of external appliances are made in this menu. In the AV connection settings menu the parameters for the AV and AVS connection sockets can be adapted. Calling the connections menu Calling AV connection settings MENU: Call TV menu.
  • Page 75 External devices Connections – Miscellaneous Various settings (e.g. Digital Link, Decoder etc.) in connection with ex- ternal appliances are made in this menu. Calling up other settings for connections MENU: Call TV menu.  Select Connections,  go to the menu line below.  Select Miscellaneous,  go to the menu line below.
  • Page 76: Devices To The Connections Av/Avs

    The AV input AVS (see page 11) offers the possibility of connecting a digital camera or a Camcorder for example. Connect the Euro-AV output of the DVD player to the AV socket of the TV set. The AV sockets can process different signal types. Which signal type your accessory device provides can be found in the operating manual of the Use a fully equipped Euro-AV cable (available from your dealer) for this.
  • Page 77 AUDIO IN L (white) and AUDIO IN R (red) and the AVS connection of the Switch off all equipment before connecting. side AV sockets of the TV set. Connect the Euro-AV output of the DVD recorder to the AV socket of Use the AV cable enclosed with the camcorder for this. the TV set.
  • Page 78: Devices To The Hdmi Connections

    Start playback on the connected HDMI device. The best Switch off all equipment before connecting. possible format for the picture is detected and set auto- Connect the device by an HDMI cable (Type A, 19-pole) to one of the matically. HDMI sockets of the TV set.
  • Page 79: Digital Link Hd

    HDMI connection of a put signal at your PC beforehand so that it corresponds to one of the TV set to compatible HDMI devices, such as e.g. Loewe AudioVision. You signals in the table on page 94.
  • Page 80: Devices To The Pc In Connection

    Playback from the device Call AV selection. You can connect a PC to the PC IN socket for example and thus use the TV screen as a monitor. ➠ When connecting a PCs or accessory device to the PC IN socket of the...
  • Page 81: Sound Components Wizard

    The sound components wizard helps you to configure the components used to play the TV sound. SOUND COMPONENTS Sound playback via ... You can also connect a digital HiFi/AV amplifier in addition to the TV TV speakers speakers. HiFi/AV amplifier or TV speakers (switchable)
  • Page 82: Connecting Audio Amplifiers

    Continuation of the left column above ... The Sound Component Wizard allows the configuration of different Connect the digital audio output of the TV set AUDIO DIGITAL OUT with audio amplifiers (digital stereo and surround amplifiers) with different the digital audio input of the amplifier via a cinch cable: digital sound formats (Dolby Digital, dts, MPEG and Stereo/PCM).
  • Page 83: Assignment Of The Digital Audio Input

    If an external device with DVI interface is connected via a HDMI/DVI Select Miscellaneous, adapter to one of the HDMI sockets of the TV set, you can connect the  go to the menu line below. digital sound of the external device to the digital audio input socket Select Assign digital audio input, AUDIO DIGITAL IN.
  • Page 84: The Direct Way To Record

    External devices The direct way to record Entering the Timer data After selecting the station you wish to record, timer data You can programme timer recordings for connected recorders. The record- will be displayed. ing wizard is integrated at several places for programming a recording. The setting options for the timer data differ depending Programming a timer recording with the EPG on the recorder selection, whether an analogue or DVB...
  • Page 85 External devices Programming the timer with the timer overview New entry: Programme timer recording manually ➠ Timer list is opened. All programmed recordings, marked programmes and copy orders listed in the timer overview. You can also programme new recordings and Red button: Call New timer entry.
  • Page 86: Timer Recording With External Devices

    External devices Timer recording with external devices ➠ The recording of HDTV stations with external devices is only possible to a limited degree. The HD transmission is scaled down to SD quality and output at the AV output for the recording. Recorder with Digital Link Plus If you use an externally connected recorder with Digital Link Plus or a similar system, the TV set and connected recorder exchange data (e.g.
  • Page 87: Operating Loewe Equipment

    Using the remote control for the TV mode of the TV set Setting the remote control for other Loewe devices You can operate various Loewe devices with the remote control. The Press the TV button, the display above it will light for device keys REC –...
  • Page 88: Software Update

    Calling Software update Requirements of USB stick MENU: Call TV menu. USB sticks tested by Loewe and compatible in type and format can be ordered from the Loewe dealer using the article no. 90437.950.  Select Settings,  go to the menu line below.
  • Page 89 Software update New software package found SOFTWARE UPDATE WIZARD Software package: current V1.2.0.0 new V1.5.0.0 If you want to load the new software now please press . Otherwise you can stop it with Proceed OK Proceed. OK Start loading software. END: Exit wizard.
  • Page 90: Troubleshooting

    EURO-AV cable is not connected. b) Connect EURO-AV cable (page 77). General problems when connecting a) The AV standard is set incorrectly. a) Set the correct standard (page 74).
  • Page 91 Status display (INFO) – Language/sound (green button). b) TV set and external digital audio amplifier are b) Connect AUDIO DIGITAL OUT from the TV set not connected with each other. to a digital input of the external digital audio amplifier and select the appropriate input to this.
  • Page 92 This will also cancel any mute setting. b) An audio device that does not exist or that is b) Connect up the audio device and switch it not connected is registered in the TV menu under Connections Sound components (e.g.
  • Page 93: Technical Data

    Technical data General data Type Connect 26 LED Article number 50428xxx Dimensions for device without stand (W x H x D) in cm 68.4 x 45.6 x 9.4 Dimensions for device with stand (W x H x D) in cm 68.4 x 50.5 x 20.3...
  • Page 94: Electrical Data

    Technical data Electrical data Signals via PC IN / HDMI The following table lists the compatible signals which your TV set can show via the PC IN connection and the HDMI connections (HDMI1, Chassis designation: SL 121 HDMI2). Power supply: 220 V –...
  • Page 95: Connections (Max. Equipment)

    Technical data Connections (max. equipment) Designation Type Function / Signal HDMI type A (2x) Digital Video/Audio IN: Digital video and audio D-SUB 15-pole Video IN PC/STB video signal Video IN: Y/C (S-VHS/Hi 8) CVBS (VHS/8 mm) EURO-AV Video OUT: CVBS (VHS/8 mm) Y/C (S-VHS/Hi 8) Audio IN: Audio OUT:...
  • Page 96: Mediahome

    Technical data MediaHome File formats supported Media server software Pictures: JPG To play multimedia contents from devices in your home network, you ➠ Picture files may not exceed a size of 10 MB. require media server software which makes the relevant files available Music: MP3, WAV (without ADPCM), WMA 9 (compressed), flac to you.
  • Page 97: Accessories

    Loewe Blu-ray player: With the Loewe Blu-ray player BluTech Vision Interactive you are ideally equipped for the successor format to DVD. With the Loewe system in- tegration you control BluTech Vision Interactive and your Loewe TV set simultaneously with the Assist remote control.
  • Page 98: Upgrade Kits / Conversion Kits / Cables

    Accessories Upgrade Kits / Conversion Kits / Cables Module DVB-S2 Single (Art.No. 70622.080): Module DVB-T2/C Single (Art.No. 70913.080): You can receive digital satellite and HDTV stations with the upgrade kit. With the DVB-T2/C Single conversion kit you add the Standard DVB-T2 The tuner is integrated in the TV set and is operated with the remote to the reception possibilities of your TV set.
  • Page 99: Equipment Variants

    Accessories Equipment variants The equipment of the individual set variants and their upgrade/conversion possibilities is listed in the table below. Set variants Connect 26 LED DVB-T/C Single DVB-T2/C Single … Art.No. 70913.080 DVB-S2 Single Art.No. 70622.080 RJ12 Art.No. 71025.080 TV set equipment...
  • Page 100: Setup Possibilities

    Table Stand Floor Stand C 22/26 Wall Mount Flex 26 S Connect 26 Table Stand (delivery status) Floor Stand C 22/26 Wall Mount Flex 26 S (see note in right-hand column) Now mount the wall holder as described in the installation instructions.
  • Page 101: Environment

    Environment Miscellaneous Environmental protection Character table Energy consumption Key assignment for text input Your TV set is equipped with an eco-standby power supply. In the standby For certain functions the input of letters or characters is required. As with mode, the power consumption drops to low power (see Technical data a cell phone press the numeric button (0-9) repeatedly until the desired on page 93).
  • Page 102: Legal Notes

    Bitstream Vera is a trademark of Bitstream Inc. APPLICABILITY FOR A CERTAIN PURPOSE. Details can be found in the GNU General Public License. You can order the software from Loewe This set contains a software which is based partly on the work of the Customer Service.
  • Page 103: Glossary

    Digital Link: System for controlling recorders (for video and DVD recorders DVDs fit onto one Blu-ray Disc (abbreviated BD). Therefore, the Blu-ray from Loewe) via the Euro AV sockets of the Loewe TV set with concealed disc provides enough space for high-resolution images and multi-channel setup.
  • Page 104 IR-Link: The IR-Link function allows the operation of accessory devices EPG: Electronic Programme Guide is the electronic variant of a printed with concealed installation made by other manufacturers via the Loewe TV guide. Using the EPG you can watch the TV programme of the TV TV set.
  • Page 105 The stations are sorted according to these channel location numbers. Page Catching: For teletext, refers to going to and calling a page L-Link: Intelligent system connection between Loewe devices for the number. automatic exchange of information. Makes the operation of TV and PAL: European standard.
  • Page 106 Glossary Stereo: Dual-channel audio. Switch: Device for connecting several computers to a network. RGB: Colour signals red, green and blue. Switch voltage: Video devices specify this voltage to switch the TV device Router: Device for connecting up several networks, e.g. home network to playback.
  • Page 107 Glossary Ycc/Ypp: Colour standards for Set-Top-Boxes. YCbCr: Digital colour model, see COMPONENT IN. YPbPr: Analogue colour model, see COMPONENT IN. 107 -...
  • Page 108: Index

    Index Contrast .............34 24p format ..........78 Control unit ..........10 Index in the TV set ........15 Copy protection .........86 Info display ..........15 Installing the TV set ........18 Access code ..........52 Interactive data services ......50 Adjusting the picture ........34 Data capture ..........47 Adjusting the sound ........32 Decoder .............75 Language ........
  • Page 109 Index Numeric buttons ......12, 15, 30 Safety ............8, 9 Teletext ............48 Scope of delivery ..........7 Teletext functions ........36 Search wizard ..........40 Teletext subtitles ........36 On/Off button ..........10 Selecting Audio/Video Source ....31 Time ............37 On-screen displays ........54 Select satellite installation ......24 Time and date ..........54 Overview diagram ........16 Select station ..........30...
  • Page 110: Service

    Fax +40 - 21 200 64 65 E-mail: loewe@mad.co.za Kingdom of Saudi Arabia Tel +44 - 1294 315 000 E-mail:Camelia.Achelaritei@eltek.ro Tel +966 (2) 665 4616 Fax +44 - 1294 315 001 Fax +966 (2) 660 7864 E-mail: enquiries@loewe-uk.com E-mail: hkurkjian@aol.com © by Loewe Opta 09.09.10...
  • Page 111 111 -...
  • Page 112 - 112...

This manual is also suitable for:
