- Page 1 INSTALLATION INSTRUCTIONS DishDrawer dishwasher DD90SDF(H)TX2, DD90SDFTM2 (Designer) & DD90S(H)TI2 (Integrated) models NZ AU GB IE 590202D 04.13...
- Page 2 FOLLOW THE INSTALLATION SEQUENCE RELEVANT TO YOUR MODEL ONLY AVAILABLE IN NZ AU ONLY AVAILABLE IN GB IE Designer Integrated (Remote control) Integrated (Badge control) DD90STI2 DD90SHTI2 DD90SDF(H)TX2 DD90SDFTM2 PARTS SUPPLIED PARTS SUPPLIED + PARTS SUPPLIED EXTERNAL VENTING KIT PRODUCT & CABINETRY PRODUCT & CABINETRY DIMENSIONS PRODUCT &...
-
Page 3: Important Safety Instructions
SAFETY AND WARNINGS - ALL MODELS IMPORTANT SAFETY INSTRUCTIONS! WARNING! Installation of this dishwasher requires basic mechanical and electrical skills. Electrical shock hazard Be sure to leave these Instructions with the Customer. Installation must comply with your local building and electricity regulations. Before installing the dishwasher, remove the house fuse or open the circuit breaker. - Page 4 PARTS SUPPLIED - ALL MODELS Side mounting Clamp (1) Drain hose Drain hose Wire clip (1) Phillips 38 mm Rubber Moisture bracket kit support (1) joiner (1) 16 mm bottom washer for protection (for securing (for securing (A and B) (2) screws (7) fixing screws inlet hose (1)
- Page 5 ADDITIONAL PARTS SUPPLIED WITH INTEGRATED MODELS External Venting kit (1) Panel bracket (1) Panel mounting Integrated rectangular badge (1) (attached to product) screws (14) (Satin chrome supplied) supplied with Integrated models with remote (NZ AU) only supplied with Integrated models with badge (GB IE) only...
-
Page 6: Product Dimensions
PRODUCT DIMENSIONS Plan Side Product dimensions (mm) overall height of product (incl. front panel height) overall width of product min. 855 min. 855 overall depth of product (excl. handle) depth of chassis (to back of front panel) maximum extension of drawer (excl. -
Page 7: Cabinetry Dimensions
CABINETRY DIMENSIONS 18 mm 2 mm Plan Side 2 mm Important! Ensure correct chassis position. In order for product to function, cabinetry must not block the drawer front from closing hard against the chassis. Minimum clearances from adjacent cabinetry min. 13 mm clearance from a min. - Page 8 INTEGRATED MODELS WITH REMOTE (NZ AU) ONLY - CUSTOM FRONT PANEL CALCULATIONS FRONT PANEL SPECIFICATIONS min. 2mm 16 -20 mm panel thickness Maximum weight of panel: 9 kg Adequately sealed to withstand moisture (50 C @ 80% RH). Because of it being a hot and wet environment generally, the back and sides of the panel should be completely sealed with a waterproof vapour barrier (ie polyurethane) to prevent damage to the panel.
- Page 9 INTEGRATED MODELS WITH BADGE (GB IE) ONLY - CUSTOM FRONT PANEL CALCULATIONS FRONT PANEL SPECIFICATIONS min. 2mm 16 -20 mm panel thickness Maximum weight of panel: 9 kg Adequately sealed to withstand moisture (50 C @ 80% RH). Because of it being a hot and wet environment generally, the back and sides of the panel should be completely sealed with a waterproof vapour barrier (ie polyurethane) to prevent damage to the panel.
-
Page 10: Cavity Preparation
CAVITY PREPARATION 10 mm Important! BENCHTOP Moisture The power outlet must be protection located in a cabinet adjacent tape must to the dishwasher cavity. be applied. 2 mm 220-240 VAC min. 7 A Water Connection Recommended COLD (Maximum 60°C). These marks indicate ¾... - Page 11 INTEGRATED MODELS WITH REMOTE (NZ AU) ONLY - PREPARATION FOR EXTERNAL VENTING THROUGH SAME CABINET Services can be located either side of dishwasher External Venting kit (1) Shelf cutouts max. 5 mm VENT HOSE ø 60 mm min.100 mm SERVICES 220 mm Important! 100 mm...
- Page 12 MAXIMUM DISTANCE OF HOSES & CORD FROM CHASSIS EDGE Left hand side Right hand side Drain hose - 2000 mm Drain hose - 1500 mm Drain hose - 2000 mm Drain hose - 1500 mm Inlet hose - 1650 mm Inlet hose - 1650 mm Inlet hose - 950 mm Inlet hose - 37 3⁄8"...
- Page 14 NOW CHOOSE WHICH INSTALLATION METHOD (a) or (b) IS MORE SUITABLE FOR YOUR CABINETRY... RECOMMENDED METHOD (a) - SECURE WITHOUT DRAWER REMOVAL (FRAMELESS CABINETRY ONLY) INTEGRATED MODELS WITH REMOTE (NZ AU) ONLY - ATTACH SIDE MOUNTING BRACKETS ATTACH VENTING HOSE Clip all four side mounting brackets into their slots Check that the fitted elbow is rotated...
- Page 15 PULL THROUGH HOSES & MOVE INTO THE CAVITY SECURE THE DRAWER Open the drawer halfway. Using a flat-bladed Vent Hose (Integrated models screwdriver, prise with remote (NZAU) the grey rubber Replace the grey only) plug out of the trim rubber plug back into moulding.
- Page 16 ALTERNATIVE METHOD (b) - SECURE BY DRAWER REMOVAL INTEGRATED MODELS WITH REMOTE (NZ AU) ONLY - PULL THROUGH HOSES & MOVE INTO THE CAVITY ATTACH VENTING HOSE Check that the fitted elbow is rotated left or right (depending Vent Hose on the direction of the routing), (Integrated models then ensure the venting hose is...
- Page 17 REMOVE THE DRAWER SECURE THE DRAWER TO THE CABINETRY Product may The product has three pairs move. Mark of fixing points: chassis position on cavity To prevent kinked hoses, we recommend rotating the drawer Ensure the sound insulation anti-clockwise and is repositioned correctly.
- Page 18 INTEGRATED MODELS WITH REMOTE (NZ AU) ONLY - INSTALLING THE FRONT PANEL ATTACH PANEL TO PANEL BRACKET REMOVE BRACKET FROM PRODUCT WARNING! Important! Electrical Shock Hazard Use all 14 screws provided as shown. Before continuing, ensure that the product is disconnected from the power supply.
- Page 19 INTEGRATED MODELS WITH REMOTE (NZ AU) ONLY - INSTALLING THE FRONT PANEL EARTH THE PANEL ATTACH PANEL TO PRODUCT Important! Ensure the rubber seal between the drawer and panel is kept in place. We recommend pushing the drawer runners back 100 mm before attaching the panel.
- Page 20 INTEGRATED MODELS WITH BADGE (GB IE) ONLY - INSTALLING THE FRONT PANEL & BADGE CONTROLS DETERMINE BADGE CUTOUT LOCATION REMOVE BRACKET & DISCONNECT BADGE WARNING! Electrical Shock Hazard Before continuing, ensure that the product is disconnected from the power supply. Failure to follow this warning may result in electrical shock, injury or fire.
- Page 21 INTEGRATED MODELS WITH BADGE (GB IE) ONLY - INSTALLING THE FRONT PANEL & BADGE CONTROLS REATTACH BADGE & EARTH THE PANEL ATTACH PANEL TO PRODUCT Important! WARNING! Ensure the rubber seal between the drawer and panel is kept in place. When refitting the door pins, ensure they are orientated as shown.
- Page 22 ADJUST PANEL HEIGHT TO ALIGN THE CABINETRY GAPS Insert an appropriately sized Philips screwdriver into the hole above the door pin and rotate the panel up or down to align the gaps in your cabinetry. Repeat on the other side if necessary. The panel has a maximum travel of 2 mm up or down.
- Page 23 THERE ARE TWO DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE. Dishwasher using sink trap with drain hose joiner Dishwasher and Standpipe Ø 38 mm If space is limited If space is limited for fixing, push for fixing, push Supplied drain hose joiner hose through drain hose through drain...
-
Page 24: Final Checklist
FINAL CHECKLIST TROUBLESHOOTING Check all parts are installed. Excessive water remaining above the filter plate, after the rinse cycle Check for a kinked drain hose or blocked waste connection, highloop not Ensure product is level, securely fastened to the cabinetry and opens and properly installed or drain hose not routed correctly.
