Page 1: Ceiling Fan
CEILING FAN OWNER'S MANUAL READ AND SAVE THESE INSTRUCTIONS MODEL: VILLAMOURNA FAN RATING AC 120V. 60Hz CUL LISTED MODEL : AC-552 MRM... -
Page 2: Tools And Materials Required
1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items; a. Set of blades (5) b. Hanger bracket assembly Downrod d. -
Page 3: Safety Rules
3. SAFETY RULES 1. To reduce the risk of electric shock, 7. Do not operate reversing switch while insure electricity has been turned off fan blades are in motion. Fan must be at the circuit breaker or fuse box turned off and blades stopped before before beginning. -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the Outlet box building structure. Use appropriate fasteners and building materials. -
Page 5: Hanging The Fan
5. Hanging the Fan Ceiling mounting plate REMEMBER to turn off the power. Follow the steps below to hang your fan properly: Ceiling canopy Step 1. Remove the decorative canopy bottom cover from the canopy by turning the cover counter clockwise.(Fig. 5) Canopy cover Step 2. -
Page 6: Installation Of Safety Support
6. INSTALLATION OF SAFETY SUPPORT An additional safety support is provided Hanger bracket Safety cable to prevent the fan from falling. Secure the safety cable to the ceiling joist with screw and washer, as illustrated in Figure 9. Figure 9 7. - Page 7 NOTE: LIGHT KITS ARE AVAILABLE AT YOU POWER LINES 120V SAVOY HOUSE RETAILER. THE FAN IS ALREADY WIRED TO SUPPORT THE LIGHT GREEN GROUND KIT OPTION. WIRING LIGHT WARNING: TO REDUCE THE RISK OF FIRE, GROUND TO MOUNTING ELECTRIC SHOCK, OR OTHER PERSONAL BRACKET INJURY.
-
Page 8: Attaching The Fan Blades
9. ATTACHING THE FAN BLADES Caution: Remove 5 rubber packing mounts and discard before installation. Step 1 Attach the blade to the blade bracket using the screws and fibber washers as shown in Figure 14. Start screw into bracket. Repeat for the two remaining screws. -
Page 9: Installing The Switch Housing
11. INSTALLING THE SWITCH HOUSING NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. 1. Remove the screws from the mounting plate under the fan motor. -
Page 10: Troubleshooting
13. TROUBLESHOOTING Problem Solution Fan will not start. 1.Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds 1. Make sure all motor housing screws are snug. noisy.
