Flush Wood Plus Insert
SAFETY NOTICE:
If this appliance is not properly installed, a house fire may
result. For your safety, follow the installation directions.
Contact local building or fire officials about restrictions and
installation inspection requirements in your area.
Travis Industries, Inc.
4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275
www.travisproducts.com
(Arched)
Owner's Manual
• Masonry Fireplace Insert
• Zero-Clearance (Metal) Fireplace Insert
Save these instructions for future reference
© Copyright 2011, T.I.
$10.00
100-01269
4110712
Tested to: U.L. 1482 & ULC S628
Listed
Advertisement
Table of Contents
Related Manuals for Travis Industries Flush Wood Plus
Summary of Contents for Travis Industries Flush Wood Plus
-
Page 1: Safety Notice
Flush Wood Plus Insert (Arched) Owner's Manual • Masonry Fireplace Insert • Zero-Clearance (Metal) Fireplace Insert Save these instructions for future reference SAFETY NOTICE: If this appliance is not properly installed, a house fire may result. For your safety, follow the installation directions. -
Page 2: General Information Introduction & Important Information
Or, mail your warranty card to: This serial number will be needed in case you require Travis Industries House of Fire service of any type. 4800 Harbour Pointe Blvd. SW Mukilteo, WA 98275 Model: Flush Wood Plus Save Your Bill of Sale. -
Page 3: Table Of Contents
Blower and Electrical Parts ........28 Firebox Parts .............. 28 Baffle Removal and Replacement ......29 Air Tube Removal and Replacement ......30 Brick Removal & Replacement ........31 Warranty ............... 32 Listing Information ............ 34 Index ................36 © Travis Industries 100-01269 4110712... -
Page 4: Safety Precautions
(UL 103 HT) cause a house fire. Liner residential type chimney or an Do not connect this appliance to approved masonry chimney with any chimney serving another a standard clay tile, or stainless appliance. steel liner. © Travis Industries 100-01269 4110712... - Page 5 Always follow the instructions in this manual. Travis Industries, Inc. grants no warranty, implied or stated, for the installation or maintenance of your appliance, and assumes no responsibility of any consequential damage(s).
-
Page 6: Features & Specifications
6-3/8" (162mm) 18-7/8" (480mm) 19-3/4" (502mm) 21-1/2" (547mm) 10" (254mm) 17-3/4" (451mm) 1-1/4" (32mm) Figure 1 (a) Measure clearances from base of insert (b) Fireplace Opening Emissions 4.4 Grams Per Hour (EPA Phase II Approved) © Travis Industries 100-01269 4110712... -
Page 7: Fireplace Insert Installation
Planning The Installation We suggest that you have an authorized Travis Industries dealer install your fireplace insert. If you install the fireplace insert yourself, your authorized dealer should review your installation plans. Check with local building officials for any permits required for installation of this fireplace insert and notify your insurance company before proceeding with installation. -
Page 8: Fireplace Requirements
Attach the "This fireplace has been altered..." plate to the fireplace (use two screws or other suitable method). You may wish to place it in a location where it will be covered by the surround panels. © Travis Industries 100-01269... -
Page 9: Insert Placement Requirements
Chimney height: 15' (4.5M) minimum; 33' (10M) maximum (measured from base of insert). • Entire fireplace, including chimney, must meet local building requirements. • The fireplace insert must be placed on a masonry hearth built to UBC standards. © Travis Industries 100-01269 4110712... -
Page 10: Zero-Clearance (Metal) Fireplace Requirements
This appliance relies upon natural draft to operate. External forces, such as wind, barometric pressure, topography, or factors of the home (negative pressure from exhaust fans, chimneys, air infiltration, etc.), may adversely affect draft. Travis Industries can not be responsible for external forces leading to less than optimal performance. -
Page 11: Insert Rollers
Flue Bracket suit your application. components to secure the flue to the They are secured from fireplace insert. inside the firebox, making Self-Drilling Screws installation much easier. Contact RLH for additional details: Flue Opening www.chim-flex.com © Travis Industries 100-01269 4110712... -
Page 12: Surround Panel Installation
Emblem Installation (included with the face) Secure the emblem to the right side panel with the two nuts (included with the face). Run the power cord behind the surround panel (cut the lock-tie holding it in place). © Travis Industries 100-01269 4110712... - Page 13 Attach the rheostat wires (orientation does not matter). Knock-Out for Power Cord A knock-out is provided on both sides the trim. Use pliers to remove the knock-out. This allows the power cord to pass under the trim. © Travis Industries 100-01269 4110712...
-
Page 14: Face Installation
Install the bypass and air control knob following the directions below. Bypass Knob Screw the bypass knob onto the damper control rod. Air Control Handle Screw the air control handle (with rod attached) onto the air control. © Travis Industries 100-01269 4110712... -
Page 15: Re-Routing The Electrical Cord To The Left Side
Cord Re-attach the strain relief to the left side (use pliers to compress the strain relief from the top and bottom while pushing it into the hole). Remove the button plug from the left side. © Travis Industries 100-01269 4110712... -
Page 16: Insert With Positive Connection
See the section providing the chimney "Insert Placement system with sufficient Block-off plate or Requirements" for draft. damper adapter minimum clearances and hearth required. Figure 10 © Travis Industries 100-01269 4110712... -
Page 17: Operating Your Appliance
Shut the air control down to low and allow the stove to cool before proceeding. Over-firing may lead to damage of plated surfaces. If any portion of the heater glows red, it is considered over-firing and will void the warranty. © Travis Industries 100-01269 4110712... -
Page 18: Opening The Door
You can also open the door a small amount and let air enter the firebox. Opening the Doors Rotate the handle up. Swing the door open. Closing the Doors Rotate the handle down to secure Lift the handle and close the door. the door. © Travis Industries 100-01269 4110712... -
Page 19: Bypass Operation
When starting or re-loading, pull the bypass out. • During normal operation, push the bypass in. Use the included pull tool Bypass Pulled Out to operate the bypass rod Used for starting and re-loading Bypass Pushed In Used for normal operation © Travis Industries 100-01269 4110712... -
Page 20: Starting A Fire
When you light the newspaper this “top-down” fire will burn its way to the center, igniting the larger pieces. With some practice, this method should work for you. © Travis Industries 100-01269 4110712... -
Page 21: Adjusting The Burn Rate
If the ashes are disposed of by burial in soil or otherwise locally ASHES dispersed, they should be retained in the closed container until all cinders have thoroughly cooled. © Travis Industries 100-01269 4110712... -
Page 22: Blower Operation
Normal Operating Sounds The steel may creak or click when the stove heats up and cools down - this is normal. Blower Sounds: The blower will make a slight "humm" as it pushes air through the stove. © Travis Industries 100-01269 4110712... -
Page 23: Hints For Burning
Wood Cutting and Storage Cut wood to length and Store the wood off the ground in a chop into quarters. covered area. Allow for airflow Air Flow around the wood to dry the wood. Air Flow Air Flow © Travis Industries 100-01269 4110712... -
Page 24: Troubleshooting
See the section "Door and Glass Inspection" on page 26 for details. • Check the ash bed for coals. Often, coals are still glowing under a slight bed of flyash. By raking these into a pile you can re-start your stove quickly. © Travis Industries 100-01269 4110712... -
Page 25: Maintaining Your Appliance
For stubborn creosote, dip a moist paper towel or newspaper in cold ash before cleaning. The ash acts as a mild abrasive. The glass will develop a very slight haze over time. This is normal and will not affect viewing of the fire. © Travis Industries 100-01269 4110712... -
Page 26: Monthly Maintenance
Excess creosote buildup may cause a chimney fire, that may result in property damage, injury, or death. Operating this appliance continually at a low burn rate (air starvation) or using green (un-seasoned) wood will increase the formation of creosote. © Travis Industries 100-01269 4110712... -
Page 27: Yearly Maintenance
Slight scaling or rusting of the metal is normal. Make sure the air tubes are secured correctly. Floor and Wall Firebricks - replace any severely damaged firebrick along the side or floor of the firebox. © Travis Industries 100-01269 4110712... -
Page 28: Door Parts
Blower and Electrical Parts ID # Description Part # ID # Description Part # Left Blower 228-10069 Right Blower 228-10070 (4) Blower Grommets w Spacers 250-00369 Rheostat 250-00302 Rhoestat Knob w Nut 250-00869 Power Cord 250-00316 Thermodisk 228-30050 © Travis Industries 100-01269 4110712... -
Page 29: Firebox Parts
Remove the bypass plate and damper assembly by pulling forward and leaning the front edge down. Remove the four rear bricks. Remove baffle front and baffle plate (rotate it forward). © Travis Industries 100-01269 4110712... -
Page 30: Air Tube Removal And Replacement
(you may wish to rotate the tube slightly). Second Tube = 25-7/8” Third Tube = 22-5/8” Back Tube = 19-3/8” Pivot the air tube downwards and slide it out of the air channel on the opposite side. © Travis Industries 100-01269 4110712... -
Page 31: Brick Removal & Replacement
Remove the floor bricks first. The side bricks are pinned in place by the floor firebrick. Clean the firebox prior to replacing the brick. Refer to the section "Baffle Removal" on page 29 for details on removing the baffle bricks. © Travis Industries 100-01269 4110712... -
Page 32: Warranty
TRAVIS INDUSTRIES, INC., 4800 Harbour Pointe Blvd. SW, Mukilteo, WA 98275. TRAVIS INDUSTRIES, INC. warrants this appliance (appliance is defined as the equipment manufactured by Travis Industries, Inc.) to be defect-free in material and workmanship to the original purchaser from the date of purchase as follows: Check with your dealer in advance for any costs to you when arranging a warranty call. -
Page 33: If Warranty Service Is Needed
14. TRAVIS INDUSTRIES, INC. is free of liability for any damages caused by the appliance, as well as inconvenience expenses and materials. Incidental or consequential damages are not covered by this warranty. In some states, the exclusion of incidental or consequential damage may not apply. -
Page 34: Listing Label
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT INSTALLATION AND RESTRICTIONS IN YOUR AREA. SUITABLE FOR USE IN FACTORY-BUILT (Z.C.) FIREPLACES AND MASONRY FIREPLACES. SERIAL NO: MODEL: FLUSH WOOD PLUS Report No. 100289794PRT-001 Certified for USA and Canada Control No. 4000515 Tested to: UL 1482 and ULC S628-93 FACTORY-BUILT (Z.C.) FIREPLACE OR MASONRY FIREPLACE INSTALLATION... -
Page 35: Listing Information
Listing Information © Travis Industries 100-01269 4110712... -
Page 36: Index
Overnight Burn ............22 Paint (Touch-Up Paint) .......... 27 Paint Curing ............17 Re-Loading the Stove ........... 22 Safety Label ............34 Safety Precautions ..........4 Smell (from paint curing) ........17 Smoke Enters Room (Troubleshooting) ....24 © Travis Industries 100-01269 4110712...
