Mitsubishi Electric PEHD-P1.6EAH Technical & Service Manual page 10

Rating Conditions (ISO T1)
Service Ref. With Electric heater
Item
Function
Capacity 1
Total input 1
Service Ref.
Power supply
Input
Running current
Starting current
External finish
Heat exchanger
Fan (drive) × No.
Fan
Fan motor output
Airflow (Lo-Hi)
External static pressure
Booster heater
Operation control & Thermostat
Noise level (Lo-Hi)
Unit drain pipe O.D
Dimensions
With Electric heater
Weight
Without Electric heater
Service Ref.
Power supply
Input
Running current
Starting current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan (drive) × No.
Fan
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D
Connection method
Between the indoor &
outdoor unit
Notes 1. Rating Conditions (ISO T1)
Cooling: Indoor: D.B.27°C (80°F), W.B.19°C (66°F)
Outdoor: D.B.35°C (95°F), W.B.24°C (75°F)
Heating: Indoor: D.B.20°C (68°F)
Outdoor: D.B.7°C (45°F), W.B.6°C (43°F)
Refrigerant piping length (one way): 5m (16ft)
3. Above data based on indicated voltage
Indoor Unit: Single phase 240V 50Hz
Outdoor Unit: Single phase 240V 50Hz / 3 phase 415V 50Hz
9
Without Electric heater
Btu/h
W
kW
With Electric heater
Without Electric heater
2 kW
2 A
2 A
kW
3
m /min (CFM)
Pa (mmAq)
2 kW
dB
mm (in.)
W mm (in.)
D mm (in.)
H mm (in.)
kg (lbs)
kg (lbs)
kW
A
A
kW
W
kW
m 3 /min (CFM)
Cooling dB
Heating dB
W mm (in.)
D mm (in.)
H mm (in.)
kg (lbs)
kg (lbs)
L
Liquid mm (in.)
Gas mm (in.)
Indoor side
Outdoor side
Height difference
Piping length
PEHD-P3EAH
PEAD-P3EA
Cooling Heating
26,300 31,000 (38,200)
7,700 9,100 (11,200)
3.41 3.24 (5.34)
PEHD-P3EAH
PEAD-P3EA
Single phase,50Hz,220-240V
0.40 0.40 <2.50>
1.70 1.70 <10.41>
– –
Centrifugal (direct)
0.15
20-25 <706-883>
<2.1>
Built in remote controller
37-41
1,175 (46-1/8)
46 (101)
44 (97)
PUH-P3VGA/YGA
Single phase,50Hz,220-240V / 3 phase,50Hz,380-415V (4 wires)
3.01 2.84
13.73/5.46 13.12/5.76
93/41
Linear Expansion Valve
NE52VNJM/NE52YDJM
2.5
VGA...Inner thermostat, HP switch, Discharge thermo.
YGA...Thermal relay, Discharge thermo, HP switch, Anti-phase protector.
×
Propeller (direct) 1
0.070
50 (1,770)
49
51
855 (33-5/8)
82 (181)
3.7 (8.2)
15.88 (5/8)
2. Guaranteed operating range
Upper limit
Cooling
Lower limi
Upper limit
Heating
Lower limi
PEHD-P4EAH
PEAD-P4EA
Cooling
33,100
9,700
3.90
PEHD-P4EAH
PEAD-P4EA
0.62
2.64
–
Galvanized sheets
Plate fin coil
×
2
0.27
27-34 <953-1,200>
70 (130)
<2.4>
41-46
32 (1-1/4)
1,415 (55-11/16)
740 (29-1/8)
325 (12-13/16)
65 (143)
62 (136)
PUH-P4YGA
3 phase,50Hz,380-415V (4 wires)
3.28
5.49
45
Munsell 5Y 8/1
Hermetic
NE56YDJM
2.7
Line start
38
Plate fin coil
Propeller (direct)
0.070+0.070
85 (3,000)
Reverse cycle
51
53
900 (35-7/16)
330+20 (13+3/4)
1,260 (49-5/8)
96 (212)
R407C
4.0 (8.8)
1.6 (Ester) MEL56
9.52 (3/8)
19.05 (3/4)
Flared
Flared
Max.50m
Max.50m
Indoor
D.B.35°C, W.B.22.5°C
D.B.19°C, W.B.15°C
D.B.28°C
D.B.17°C D.B.-11°C, W.B.-12°C
1 : ( ) Shows the total rating.
2 : < > Shows only the booster heater r ating.
Heating
35,500 (43,700)
10,400 (12,800)
4.07 (6.47)
0.62 <3.02>
2.64 <12.58>
–
3.45
5.79
×
2
Outdoor
D.B.46°C
D.B.-5°C
D.B.24°C, W.B.18°C
