- Page 1 User's Manual FST-811 FST-812 FST-812S15/812S35/812S50 FST-815A FST-816A20/816B20 10/100Base-TX to 100Base-FX Smart Media Converter...
-
Page 2: Fcc Warning
Trademarks Copyright © PLANET Technology Corp. 2009. Contents subject to revision without prior notice. PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose. -
Page 3: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION ..............................4 1.1 C ................................4 HECKLIST 1.2 A 10/100B 100B -FX S ............. 4 BOUT THE MART EDIA ONVERTER 1.3 F ................................. 5 EATURES 1.4 S ................................6 PECIFICATION 1.5 P ..............................7 RODUCT UTLOOK 2. -
Page 4: Introduction
1. INTRODUCTION 1.1 Checklist Thank you for purchasing PLANET 10/100Base-TX to 100Base-FX Smart Media Converter, the 10/100Base-TX to 100Base-FX Smart Media Converter package shall contain following contents: Check the contents of your package for following parts: 10/100Base-TX to 100Base-FX Smart Media Converter x1 User's Manual CD x1 DC 5V 2A Power Adapter x1 If any of these pieces are missing or damaged, please contact your dealer immediately, if possible, retain the carton... -
Page 5: Features
1.3 Features Standards: Complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3u 100Base-FX Ethernet Stan- dard Interface: One 10/100Base-TX port with RJ-45 connector One 100Base-FX port with LC/SC/WDM connector supporting multi-mode or single-mode fiber optic cable Auto-Negotiation and Auto-MDI / MDI-X for 10/100Base-TX port Layer 2 Features: Back-Pressure &... -
Page 6: Specification
1.4 Specification FST-816A FST-816B Model FST-811 FST-812 FST-815A FST-812S15 FST-812S35 FST-812S50 Hardware Specification Standards IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX and 100Base-FX Ports 1 10/100Base-TX port , 1 100Base-FX port Fiber connector SC, WDM SC, WDM Wavelength Deploy- 1310nm (Transmit and Receive) -
Page 7: Product Outlook
Left View: there is one DC jack for DC 5V power adapter. 5V DC Fast Ethernet Bridge 10/100Base-TX to 100Base-FX Figure 1: FST-811 Outlook 5V DC Fast Ethernet Bridge 10/100Base-TX to 100Base-FX Figure 2: FST-812 / FST-812S15 / FST-812S35 / FST-812S50 Outlook... - Page 8 5V DC Fast Ethernet Bridge 10/100Base-TX to 100Base-FX Figure 3: FST-815A Outlook 5V DC Fast Ethernet Bridge 10/100Base-TX to 100Base-FX Figure 4: FST-816A20 / FST-816B20 Outlook LED Indicators Color Status Indication PWR(Power) Lights On Power on – when +5V DC detected. Green Lights Off Power off.
-
Page 9: Hardware Installation
2. HARDWARE INSTALLATION This product provides two different running speeds – 10/100Base-TX and 100Base-FX in the same device and the 10/100Base-TX RJ-45 port can automatically distinguish the speed of incoming connection. This section describes the hardware installation of FST-81x. Before connecting any network device to the FST-81x, read this chapter carefully. -
Page 10: Slide Media Converter Module Into Mc-1600Mr / Mc-1610Mr Series Chassis Installation
2.2 Slide Media Converter module into MC-1600MR / MC-1610MR series Chassis Installation Step 1- Unscrew and pull out the FST-81x Media Converter board. Step 2- Remove a blank faceplate from an empty expansion slot on the front of the Media Converter Chassis. The FST-81x Media Converter board can be installed in any expansion slot. -
Page 11: Real Ethernet Environment Application
2.3 Real Ethernet environment application Fiber-Optic Networking for ISP, Enterprise, and Home The FST-81x provides advanced Media conversion technology- 10/100Base-TX and 100Base-FX interfaces to fulfill dif- ferent kinds of demand followed with the growth and expanding of the current network. The FST-81x provides diverse fiber connector types for different network applications. -
Page 12: Manage The Media Converter
3. MANAGE THE MEDIA CONVERTER This product provides two different managed methods – configure through its DIP Switch or install into the central Web Smart / Managed Media converter chassis for centralize management. This section describes how to managed the FST-81x through its DIP Switch and Web Smart / Managed Media converter chassis. -
Page 13: Managed Media Converter Module Through Mc-1600Mr/R48 & Mc-1610Mr/R48 Chassis
3.2 Managed Media Converter module through MC-1600MR/R48 & MC-1610MR/R48 ssis The Web Smart / Managed Media Converter Chassis that can control FST-81x through the management system, FST-81x can be controlled through Web Browser and terminal emulation program. The Web Smart Media Converter Chassis-MC-1600MR/R48 will display out the status of FST-81x, also the Web Smart Media Converter Chassis can control the function through the management system. - Page 14 The Managed Converter Chassis-MC-1610MR/R48 will display out the status of FST-81x, also the Managed Media Converter Chassis can control the function and OAM / Bandwidth control setting through the management system. Through the Managed Media Converter Chassis System, you can control the setting of FST-81x, such as device (Disable / Enable), LFP (Disable / Enable).
- Page 15 For easily to know the TP / Fiber port link status of oppsite device, the Managed Media Converter Chassis System provide OAM Setting that include TS-1000 OAM / IEEE 802.3ah OAM / Loop Back Test function. Also the bandwidth control function allow to define available transmit / receive bandwidth on TP / Fiber port of FST-81x. Item Description Ingress Rate Limit...
-
Page 16: Link Pass Through Function
4. LINK PASS THROUGH FUNCTION The LFP function includes the Link Fault Pass Through function (LLCF/LLR) and the DIP Switch design. LLCF/LLR can immediately alarm administrators the problem of the link media and provide efficient solution to monitor the net. The DIP Switch provides disable or enable the LFP function. -
Page 17: Link Loss Return (Llr)
4.2 Link Loss Return (LLR) The fiber ports of FST-81x have been designed with an LLR function for troubleshooting a remote connection. LLR works in conjunction with LLCF. When LLR is enabled*, the port’s transmitter shuts down when its receiver fails to detect a valid receive link. LLR should only be enabled on one end of the link and is typically enabled on either the unmanaged or remote device. -
Page 18: Troubleshooting
5. TROUBLESHOOTING This chapter contains information to help you solve issues. If the FST-81x is not functioning properly, make sure the FST-81x was set up according to instructions in this manual. The Power LED is not lit Solution: Check the power cable connection between power adapter and FST-81x. Why I connect FST-81x to device with 100Base-FX interface and the 100Base-FX fiber connection fail? Solution: Please check the fiber connection between two devices is correct. -
Page 19: Appendix A Networking Connection
APPENDIX A NETWORKING CONNECTION A.1 Switch‘s RJ-45 Pin Assignments 10/100Mbps, 10/100Base-TX RJ-45 Connector pin assignment Contact MDI-X Media Dependant Media Dependant Interface Interface -Cross Tx + (transmit) Rx + (receive) Tx - (transmit) Rx - (receive) Rx + (receive) Tx + (transmit) 4, 5 Not used Rx - (receive) -
Page 20: Cable Connection Parameter
A.3 Cable Connection Parameter The limitations are shown as below; Duplex Connection Limitation (max.) Twisted Pair Half / Full Node to Node 100 meters Node to Switch/ Hub Multi-Mode Converters MM Half Node to Node 412 meters Node to Switch MM Full Node to Node 2 kilometers... -
Page 21: Ec Declaration Of Conformity
For the following equipment: *Type of Product : 10/100Base-TX to 100Base-FX Smart Media Converter *Model Number : FST-811 / FST-812 / FST-815A / FST-812S15 / FST-812S35 / FST-812S50 / FST-816A20 / FST-816B20 * Produced by: Manufacturer‘s Name : Planet Technology Corp.
