- Page 1 10 INCH LCD DIGITAL FISH FINDER OPERATION MANUAL Model：DF SERIES Doc No:：NLT-DFXXXX-SSEN Version：V121112...
-
Page 2: Table Of Contents
/ RIGHT MENU contents and factory setting........6 MENU <1> ............... 6 MENU <2> (DF612 & DF1011 & DF1511 & DF2022) ..... 6 MENU <2> ( DF5088 & DF2099 ) ........7 Setting on MENU ............. 7 Pic Speed ..............7... - Page 3 Max A-Range ............8 Zoom ..............8 Fish Alarm ............... 8 Back Ground ............8 Pulse Width .............. 8 TVG ............... 9 Noise Rej..............9 Color Del ..............9 Palette ..............9 Depth Alarm ............10 Shallow Set ............10 Deep Set ...............
-
Page 4: System Description
Summary: Frequency & Transducer Model Channel Transducer cable(m) Output power maker DF612 single 50/200 kHz - 600W BP60-200-15L NINGLU DF1011 single 50 kHz - 1000W 50B-9B-15L JAPAN... -
Page 5: Specifications
Dimension: 264(H) x 270(W) x 93(D) mm Power: DC24V (19~36V) Fish finder will automatically shut down when voltage is too high Consumption: <24W Frequency & DF612 50/200kHz 600W Output power DF1011 50kHz 1000W DF1511 50kHz 1500W DF2022 50 kHz 600W，200 kHz 600W DF5088 50kHz 2000W，200kHz 1000W... -
Page 6: Operation
Operation Keyboard POWER Turn power off/on. RANGE Set the displayed depth range. SHIFT Shift displayed depth range. GAIN 1 Adjust sensitivity of frequency 1. GAIN 2 Adjust sensitivity of frequency 2. Move the expanded area toward ZOOM sea surface or sea bottom. BRILL Adjust the brightness of display. -
Page 7: Fixed Key Functions
Fixed key functions POWER 【POWER】button is used to turn on/off the system. RANGE 【RANGE】 button sets the depth range(how deep from the surface) showed on the screen: 5 10 20 30 40 50 60 80 100 120 150 180 200 250 300 400 500 600 800 1000 1500 2000m (22 optional values). -
Page 8: Brill
Bottom-Z Bottom contour is indicated as a straight line and expansion view of certain area from its contour is shown. Zoom rate is set in MENU 1 Seabed Zoom: ×2.5, ×5, ×10. BRILL 【BRILL】key is used to adjust the LCD brightness. MENU 【MENU】button facilitates selection of MENU 1, MENU 2, quit MENU. -
Page 9: Menu Contents And Factory Setting
0 ～ 40 Noise Rej. Off Low High MENU <2> Press 【MENU】into MENU <2> 【MENU】 MENU <2> (DF612 & DF1011 & DF1511 & DF2022) Color Del 0 ～ -12 Palette 0 1 2 3 4 5 6 Unit m fm... -
Page 10: Menu <2> ( Df5088 & Df2099 )
MENU <2> ( DF5088 & DF2099 ) Color Del 0 ～ -12 Palette 0 1 2 3 4 5 6 Unit m fm Depth Alarm Off Shal Midd Deep Shallow Set 1m ～ 50m Deep Set 16m ～ 501m WaterTemp AL Off Low Midd High Low Set 0 ℃... -
Page 11: Max A-Range
Max A-Range It sets maximum depth when auto range is operating. Set Max A-Range on MENU 1: 30, 100, 200, 300m, Max. Zoom Set zoom rate in MENU 1:×2.5, ×5, ×10. Fish Alarm When the response to be supposed fish school is displayed and the fish depth is above 4m, alarm goes off. -
Page 12: Tvg
This function suppresses sensitivity shallower than approx. 100m and eliminates reflected signal form plankton and air bubble. Stronger TVG is set, sensitivity near sea surface decreases. When you make TVG too strong, response near sea surface disappears. On the other hand, when you make TVG too weak, response near sea surface becomes strong and you can not judge the image in some case. -
Page 13: Depth Alarm
Depth Alarm Depth alarm goes off within the 3 depth ranges. Set depth alarm on MENU 2: Off, Shal, Midd, Deep Shallow depth and deep depth are set in MENU 2: Shallow Set, Deep Set. Shallow Set Set shallow depth alarm value. ～... -
Page 14: Watertemp Al
WaterTemp Al Water temperature alarm goes off within 3 temperature ranges. Set WaterTemp Al on MENU 2: Off, Low, Midd, High. Low set and High Set are set in MENU 2: Low Set, High Set. Low Set Set low alarm temperature value. ℃... -
Page 15: How To Get The Steady Data
How to get the steady data The key to getting the steady data lies in the correct adjustment of GAIN & Color Del. 【GAIN 1】/ 【 GAIN 2】 are used to adjust the sensitivity of signal received. GAIN may be adjusted from the min value to max one and you can get the appropriate sensitivity at one time point which comes before the time point of showing littery wave on screen. -
Page 16: Installation
Installation Operating unit installation Installation mode: Table Unit：mm... -
Page 17: Installation
Installation Connection VGA interface realizes external 15-32 inch LCD to display the echo graphics. -
Page 18: Transducer Wiring
Transducer wiring DF612 -- BP60-200-15L DF1011 -- 50B-9B-15L, DF1511 -- TGM60-50B-10L, wiring method: Shielded wire → Pin 1 of 5-pin plug Other signal wires → Pin 3/ Pin 4 of 5-pin plug DF2022 -- TGM50/200B-12L wiring method: Shielded wire → Pin 1 of 5-pin plug White/ Black wire (50kHz) →...
