LOW VIBRATION AIR BODY SAW
WARNING:
INSTRUCTIONS before operating. Failure to follow the safety
rules and other basic safety precautions may result in serious
personal injury.
OWNER'S MANUAL
Read
carefully
Item #16491
1 OF 7
and
understand
all

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 16491 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Klutch 16491

Summary of Contents for Klutch 16491

  • Page 1 LOW VIBRATION AIR BODY SAW OWNER’S MANUAL WARNING: Read carefully understand INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #16491 1 OF 7...

  • Page 2: Intended Use

    Thank you very much for choosing a Klutch™ Product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Work Area

    SAVE THESE INSTRUCTIONS WORK AREA • Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. • Do not use your Air Saw where there is a risk of causing a fire or an explosion; e.g. in the presence of flammable liquids, gases, or dust.

  • Page 4: Tool Set Up

    • Disconnect air supply from tool and place the switch in the locked or off position before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. • Secure work with clamps or a vise instead of your hand to hold work when practical.

  • Page 5: Maintenance

    damage and/or personal injury. 1. Make sure that the air valve (or trigger) is in the “off” position before connecting to the air supply. 2. An air pressure of 90 PSI is required. 3. Drain the air tank daily. Water in the air line can damage the tool. 4.

  • Page 6: Diagram & Parts List

    DIAGRAM & PARTS LIST NO. PARTS NO DESCRIPTION NO. PARTS NO DESCRIPTION 14691-01 Lever Pin 3x22 16491-20 Rear End Plate 14691-02 Throttle Lever 16491-21 Screw M4x8 14691-03 Bushing 16491-22 Valve Spring Washer 14691-04 Work Guide 16491-23 Retainer Ring IR28 14691-05...

  • Page 7: Warranty

    14691-10 Valve Spring 16491-29 O-Ring 4x2 14691-11 Blade Chuck 16491-30 Valve Stem 14691-12 Screw M3x6 16491-31 Valve Spring 14691-13 Front Plate 16491-32 Valve Stem Rear Cover 14691-14 Front Plate Washer 16491-33 Muffle 14691-15 Rear Bumper 16491-34 Muffler 14691-16 Piston Stem...
