14 assembling the barbecue electrolux en:tice barbecue
9. Fit rear panel
Alight rear panel slots with screws and slide
rear panel slots under screw heads and tighten
screws 9 places (3 each side & 3 at bottom)
10. Fit upper rear panel
Align upper rear panel slots at side with screws
and slide rear panel slots under screw heads
and tighten screws 4 places (2 each side)
DO NOT fit screws to these
holes until next step
Rear panel
Upper rear panel
angled bend at top
