3. Fit left upper door hinge bracket
Qty 2
Type 3 screw (M5 x 12)
Spring washer
Flat washer
Qty 1
Left upper door hinge bracket
4. Partially install screws to left side panel assembly
DO NOT screw in fully
Qty 7
Type 1 screw (M4 x 8)
electrolux en:tice barbecue assembling the barbecue 11
Left upper door
hinge bracket
Left side panel assembly
Screw locations
Left side panel assembly
