IBM ThinkPad 510Cs Reference page 66

IBM
ThinkPad 760C - withdrawn
         
: : : : :
IBM ThinkPad
Processor type
Processor speed
Processor upgrade
L2 cache
Removable diskette
Removable CD-ROM
Price
Type - model all 9546
Preload (see side)
Pentium speed
Remv disk - size / ms
Avail / withdrawn date
Display - diagonal size
Display - type
Display - techology
Graphics - controller
Graphics - external
Graph - arch/data path
Memory - std / max
Mem - upgrade
Keyboard / # of keys
Keyboard slope
Pointing / palm rest
Ext keyboard support
Dimensions (cubic in)
Weight (with battery)
Battery - type
Battery - life (1 batt)
Battery - life (2 batt)
Charge time - on / off
Architecture
Docking Station
Port replicator
PCMCIA 2.1 slots
Serial / parallel ports
Other features
Motion video accel
MPEG decoder
DSP function
Data/fax modem
Audio support
Audio in/out jacks
Infrared ports
Telephone
Security
Preinstalled software
Warranty
The left bay (UltraBay) supports:
x 2nd disk (requires Second HDD Adapter)
y 2nd battery
z std diskette drive
{ 2.88 MB diskette drive (option)
➄ PCMCIA Cartridge (option)
➅ IBM Wireless Modem for ARDIS (option)
➆ IBM Wireless Modem for Cellular/CDPD
(option)
Maximum internal disk capacity on 760C is
2.16 GB with two 1.08 GB disks.
Easy-Setup is entered by holding F1 when
turning on.
Integrated Mwave DSP provides:
x Data modem function (to 28.8 Kbps)
y Fax modem function (to 14.4 Kbps)
z Audio function (wave table synthesis)
{ Telephone function
- Full duplex speakerphone
➄ Digital Simultaneous Voice and Data
ThinkPad EasyServ     : customer calls 1-800-772-2227, courier service picks up ThinkPad at
any location, IBM repairs and mails back (no shipping charges, most shipping is overnight,
3 business day average turnaround). Overnight repair option in US available for $99.
❍
= Removable
✂ 760C
12.1" or 10.4" TFT color
    
Pentium (P54LM) / 64 bit to L2 cache / 32 bit to memory
90/60 or 120/60 MHz (see below)
to Pentium 120/60 MHz
256 KB / write-through / direct mapped / 10 ns / synchronous / soldered
Internal 3.5" 1.44 MB ❍ (in UltraBay)
None (diskette bay is called UltraBay) - cannot install an int CD-ROM
U21 U2A U22
SelectaSys Win 95 SelectaSys Win 95
90/60 MHz 90/60 MHz
❍
720 MB / 13 ms / EIDE 720 MB / 13 ms / EIDE
Oct 1995 / Oct 1996 Oct 1995 / Oct 1996
12.1 inch 10.4 inch
SVGA color / 640 x 480 or 800 x 600 / 65,536 simultaneous colors
Black Matrix TFT - active matrix / 100 to 1 contrast ratio
Trident CYBER9320 with 1 MB DRAM
External SVGA to 1024 x 768 w/ 256 colors up to 75 Hz
VL-Bus 2.0 local bus / 32 bit / Simultaneous LCD and CRT / 180 degree tilt
8 MB / 64 MB 70 ns / non-parity / 3.3 volt / fast page
2 sockets for two JEDEC 88 pin EDO SO DIMMs of 8 or 16 MB (acts like fast page)
Full size alp/num / 85 (8 Fn key functions)
Automated tilt up keyboard (5.5 degrees)
TrackPoint III / integrated palm rest
Yes (with option cable)
10.4" models: 11.7 x 8.3 x 1.74" (169) 12.1" models: 11.7 x 8.3 x 1.92" (186)
10.4" models: 6.1 pounds
10.4" models: Lithium Ion / intelligent
10.4" models: 3.8 hours Opt
NiMH
10.4" models: 7.6 hours
10.4" models: 2 to 3 hrs / 1.5 to 2.5 hrs 12.1" models: 2 to 3 hrs / 1.5 to 2.5 hrs
ISA (EIDE, audio, PCMCIA, diskette, serial, parallel, 240 pin ext expansion)
VL-Bus 2.0 / 32 bit / 33 MHz (graphics)
Dock I and II
Port Replicator I and II
2 Type I or 2 Type II or 1 Type III
One 9 pin; 16550A / one (IEEE P1284-A, EPP, ECP, bidirectional)
APM-aware BIOS / Universal AC adapter 3 prong (35 watts) / Selectable boot
None
None
Mwave MDSP2780 DSP with modem, fax, audio, telephony function
Data/fax modem function via DSP (v.34 to 28.8 Kbps) / Mwave 2.0
16 bit audio chip on planar with Mwave DSP
Int stereo speakers / .5 watt / slide volume control / internal microphone
Input jack (3.5 mm) / output jack (3.5 mm)
Infrared ports (front and back) / IrDA 1.0 compatible / up to 115 kbs
Telephone / answering machine / full duplex speakerphone
Power-on password / Hard disk password / Supervisor password / Locking
device keyhole (Kensington MicroSaver cable lock) / Security latch for
keyboard and DIMMS (requires Kensington) / PC Card lock
Choice of two preloaded configurations (listed to right)
3 year - ThinkPad EasyServ only (optional Overnight Repair Option) or carry-in
Compatible in ThinkPad 760 family:
- Disks: (360/750/755 IDE disks not supported)
- Second HDD Adapter
- Dock I (1 slot / 1 bay)
- Dock II (2 slot / 2 bay)
- Port Replicator I (w/ PCMCIA)
- Port Replicator II
- 1.44 MB diskette
- 2.88 MB diskette
- PCMCIA Cartridge
- 760 NiMH Battery (black)
- Li-Ion Battery Pack II (gray)
- Travel Quick Charger
- FDD External Attachment Kit
- Pentium 120/60 MHz upgrade
- Car Battery Adapter
- ThinkPad AC Adapter (50 watts)
- 8 MB SO DIMM 3.3v non-parity EDO
- 16 MB SO DIMM 3.3v non-parity EDO 92G7316
- ThinkPad headset
U2B U27
SelectaSys Win 95
120/60 MHz
❍
720 MB / 13 ms / EIDE
Nov 1995 / Oct 1996
12.1 inch
Liftable (pop-up) keyboard to
access and remove diskette
drive, 1st/2nd disk, and
1st/2nd battery
12.1" models: 6.8 pounds
12.1" models: Lithium Ion / intelligent
12.1" models: 3.5 hours
12.1" models: 7 hours
720 MB HDD II EIDE 12.5 mm 29H9383
1.08 GB HDD II EIDE 12.5 mm 29H9319
1.2 GB HDD II (CD only) 17 mm 29H9325
ThinkPad 760C strengths:
➭ ➭ ➭ ➭ ➭ Tilt up keyboard and palm rest space
➭ ➭ ➭ ➭ ➭ Largest notebook display models -- 12.1 inch
➭ ➭ ➭ ➭ ➭ UltraBay: 2nd disk, 2nd battery, diskette
➭ ➭ ➭ ➭ ➭ Integrated 28.8 Kbps modem, audio, telephony
➭ ➭ ➭ ➭ ➭ Two high speed infrared ports
U2H U28
SelctaSys
120/60 MHz
❍
1.08 GB / 13 ms / EIDE
Jan 1996 / Oct 1996
12.1 inch
SELECTASYSTEM PRELOAD
- IBM DOS 7.0
- Windows 3.11
- OS/2 Warp 3.0 (dual boot) with
selected BonusPak
- IBM PC Card Director 3.0
- Online Users Guide
Opt
- ThinkPad Features Program
NiMH - Diskette Factory

1. Lotus cc:Mail, e-mail for IBM Global
network; 2. Lotus Organizer
3. Lotus ScreenCam
4. Triton CoSession Host; 5. PRODIGY
6. SofNet FaxWorks Voice
7. Video For Windows 1.1 Runtime
8. Puma TranXit 9. COMPEL PE
10. Mind Path Presentation F/X Pro
11. Internet for Windows
12. Compuserv for Win; 13. WIN32s Runtime
14. NetFinity for Windows and OS/2
- Complimentary Applications CD-ROM
- Lotus SmartSuite 4.0 CD-ROM
WINDOWS 95 PRELOAD
- Microsoft Windows 95
- Online User's Guide
- ThinkPad Features Program
- Diskette Factory

1. Lotus cc:Mail, e-mail for IBM Global
network; 2. Lotus Organizer
3. Lotus ScreenCam
4. Triton CoSession Host; 5. PRODIGY
6. SofNet FaxWorks Voice
7. Puma TranXit
8. Compuserv for Windows
9. Mind Path Presentation F/X Pro
10. COMPEL Personal Edition
- Lotus SmartSuite 96 CD-ROM
29H9333
FEATURES OF 760 MODELS
3545001
Product Map; LCD indicator panel
3546001
LCD of remaining battery life
66G3510
LCD icons for two batteries
66G3520
Plug and Play 1.0a
std in newer
Discharge battery via mouse click
66G0108
Non-disruptive battery exchange
84G1301
Standby, suspend, and hibernation modes
41H9720
US EPA Energy Star compliant
29H9329
Personalized nameplate in indention
85G1522
Personalization screen at startup
66G3618
International Warranty Service
29H9340
24 hour / 7 day telephone, bulletin
49G2167
board, fax, electronic, and Internet
66G3541
(http://www.pc.ibm.com) support
92G7315
IBM and dealer warranty/service
Online Housecall (remote diagnostics)
85G1301
All trademarks are the property of their respective owners
No warranties are expressed or implied in this summary
(760C) Compiled by Roger Dodson, IBM. October 1996
U2J
Win 95
❍




