- Page 1 VT207 Series LCD Monitor User Guide...
-
Page 2: Table Of Contents
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. -
Page 3: Notices
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. -
Page 4: Safety Information
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. -
Page 5: Care & Cleaning
Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord. • Cleaning. - Page 6 Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS websites worldwide provide updated information on ASUS hardware and software products. Refer to http://www.asus.com Optional documentation Your product package may include optional documentation that may have been added by your dealer.
-
Page 7: Welcome
With these features, you can enjoy the convenience and delightful visual experience that the VT207 Series brings you! Package contents Check your VT207 Series LCD package for the following items: LCD monitor Monitor base Quick start guide 1 x Power cord... -
Page 8: Assembling The Monitor Base
Assembling the monitor base To assemble the monitor base: Connect the base with the arm of monitor and turn clockwise. A click indicates that the base has been connected successfully. Adjust the monitor to the angle that is most comfortable for you. We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. -
Page 9: Monitor Introduction
Press this button to activate the QuickFit function designed for alignment. • The QuickFit function contains 2 pages of common grid patterns, and photo sizes. (Please refer to 1.5.3 QuickFit Function) MENU Button: • Press this button to enter the OSD menu. ASUS LCD Monitor VT207... - Page 10 • Press this button to enter/select the icon (function) highlighted while the OSD menu is activated. • This is QuickFit cycle key. Button: • Press this button to increase the value of the function selected or move to the previous function. This is also a hotkey for Brightness adjustment.
-
Page 11: Rear Of The Lcd Monitor
1.5.2 Rear of the LCD monitor AC-IN port USB port (only for touch function) DVI port VGA port Kensington Lock Screw holes for VESA Wall Mount Control buttons ASUS LCD Monitor VT207... -
Page 12: Quickfit Function
1.5.3 QuickFit Function The QuickFit function contains two patterns: (1) Grid (2) Photo size. Grid patterns The grid patterns facilitate designers and users to organize content and layout on a page and achieve a consistent look and feel. Alignment Grid Photo size The various real photo sizes displayed in the QuickFit function provides photographers and other users to accurately view and edit their photos in... -
Page 13: Detaching The Arm/Stand (For Vesa Wall Mount)
Detaching the arm/stand (for VESA wall mount) The detachable stand of the VT207 Series LCD monitor is specially designed for VESA wall mount. To detach the arm/stand: Pull the stop lever and turn anticlockwise to unlock. Detach the base from the monitor. -
Page 14: Adjusting The Monitor
Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling while changing its angle. -
Page 15: Touch Operation
Touch Operation • ASUS VT207 is a touch monitor which uses 10 point touch panel technology. Please used with latest OS like Windows 8. • You can use either single finger touch, or multi-finger touch up to maximum simultaneous 10 touch points. - Page 16 Left edge swipe (on Windows 8 only) Swipe from the left edge of the screen to shuffle your running apps. Right edge swipe (on Windows 8 only) Swipe from the right edge of the screen to launch the Charm bar. Finger slide( on Windows 8 only) Slide your finger to scroll up and down and slide your finger to pan the screen left or right.
- Page 17 Bring together your two fingers on the touch panel. Zoom in Spread apart your two fingers on the touch panel. Single Tap/Double tap Single Tap Touch the target on the screen with one fingertip for one quick tap, then release. ASUS LCD Monitor VT207...
- Page 18 Double Tap Touch the target on the screen with one fingertip for two quick taps, then release. Tap an app to launch it (on Windows 8 only). Double-tap an item to launch it. Tap and hold To move an app, tap and hold the app tile and drag it to a new location. To close an app ( on Windows 8 only), tap and hold the top side of the running app and drag it down to the bottom of the screen to close it.
- Page 19 NOTE:• You can access to OS website to get more description on touch operation. • Do not touch the screen with sharp objects, it may result in damage, and void warranty. • Do not push hard, or rest anything on the glass surface (if in horizontal position) as it will damage the screen and void warranty. • Please keep your hands clean and dry before touching the screen to ensure fluid touch operation. • The touch function works only on OS and applications which support touch functions. ASUS LCD Monitor VT207...
-
Page 20: Osd (On-Screen Display) Menu
OSD (On-Screen Display) menu 4.1.1 How to reconfigure VT207 Splendid Scenery Mode Color Standard Mode Image Theater Mode Input Select Game Mode System Setup Night View Mode sRGB Move Menu Exit Press the [MENU] button to activate the OSD menu. Press and to navigate through the functions. Highlight and activate the desired function by pressing the [MENU] button. - Page 21 PCs. In the Standard Mode, the Saturation, Skin Tone, Sharpness, and ASCR functions are not user-configurable. In the sRGB, the Brightness, Contrast, Saturation, Color Temp., Skin Tone, Sharpness, and ASCR functions are not user- configurable. ASUS LCD Monitor VT207...
- Page 22 Color Select the image color you like from this function. VT207 Splendid Brightness Color Contrast Image Saturation Input Select Color Temp. User Mode System Setup Skin Tone Natural Smart View Move Menu Exit Brightness: The adjusting range is from 0 to 100. The button •...
-
Page 23: Input Select
Aspect Control: Adjust the aspect ratio to “Full”, “4:3”. • • ASCR: Select ON or OFF to enable or disable dynamic contrast ratio function. (ASCR: ASUS Smart Contrast Ratio. Disabled at “Standard Mode” and “sRGB Mode”.) • Position: Adjust the horizontal postition (H-Position) and the vertical position (V-Position) of the image. -
Page 24: System Setup
System Setup Adjust the system configuration. VT207 Splendid Splendid Demo Mode ECO Mode Color OSD Setup Image Language English Input Select Information System Setup All Reset Move Menu Exit • Splendid Demo Mode: Activate the demo mode for the Splendid function. •... -
Page 25: Specifications
VESA Wall Mounting Yes (75mm x 75mm) Phys. Dimension (WxHxD) 481 x 362 x 200mm Box Dimension (WxHxD) 553 x 420 x 127mm Net Weight (Esti.) 2.9kg Gross Weight (Esti.) 4.7kg Voltage Rating AC 100~240V(Built-in) *Specifications subject to change without notice. ASUS LCD Monitor VT207... -
Page 26: Troubleshooting (Faq)
Troubleshooting (FAQ) Problem Possible Solution Power LED is not ON • Press the button to check if the monitor is in the ON mode. • Check if the power cord is properly connected to the monitor and the power outlet. The power LED lights amber and • Check if the monitor and the computer are in the there is no screen image... -
Page 27: Supported Timing List
1280 x 1024 75Hz 79.976KHz 1600 x 900 60Hz 60KHz * The modes not listed in the above tables may not be supported. For optimal resolution, we recommend that you choose a mode listed in the above tables. ASUS LCD Monitor VT207...
