WIRING DIAGRAM BY MODEL
This document describes car models to which the AFC neo (Product code:
401-A017) is applicable, and ECU terminal arrangement drawings. For the
operating method and precautions for the AFC neo, refer to the Instruction
Manual
When installing the AFC neo, both this document and the Instruction Manual
are required.
Even if the car model and manufacturing year coincide with the contents de-
scribed in this document, this product may not be installed in certain specifica-
tion vehicles or remodeled vehicles.
The manufacturing years of applicable vehicles are as of February, 2006. For
the latest vehicles applications, Please contact your local APEXERA Office or
dealer for more information.
