VEHICLE SPECIFICATIONS
SPECIFICATIONS
POWER SOURCE
Drive motor: Direct drive, 48 volts DC, shunt-wound, 3.2 hp
Engine: 4-cycle OHV, 286 cc, 9.5 maximum HP @3600 RPM (per SAE J 1940/1349),
single-cylinder, air-cooled, with pressure lubrication system
Engine: 4-cycle OHV, 351cc, 11.5 maximum HP @3600 RPM (per SAE J 1940/
1349), single-cylinder, air-cooled, with pressure lubrication system
Fuel system: Side-draft carburetor with float bowl, fixed jets, fuel filters, and impulse
fuel pump
Governor: Automatic ground-speed sensing, internally geared in unitized transaxle
Ignition: Transistor electronic ignition with electronic RPM limiter
Transaxle: Double reduction helical gear with 12.3:1 direct drive axle
Unitized transaxle: Fully synchronized forward and reverse with neutral and reduced
speed reverse (11.8:1 forward, 17.1:1 reverse)
Torque converter: Automatic, variable-speed, dry type
Electrical system: 48 volts DC, reduced speed reverse
Electrical system: 12 volt, 500 cca at 0 °F (-17.8 °C), 650 at 32 °F (0 °C). 105-minute
reserve capacity and 35-amp charging capacity
Batteries: High capacity, deep cycle, Trojan PowerDrive 12-volt, 117 min. capacity
Charger: Automatic, 48-volt; UL and CSA listed
STEERING/SUSPENSION/BRAKES
Steering: Self-adjusting rack and pinion
Suspension: Front and rear tapered mono-leaf springs with dual hydraulic shocks
Brakes: Dual rear wheel self-adjusting brakes with cast iron drums and single brake
pedal with automatic-release park brake
BODY/CHASSIS
Frame/Chassis: Twin I-Beam welded aluminum
Front body: ABS
Rear body: TPO
Tires: 20 x 10.0 – 8 tubeless, 4 ply rated
DIMENSIONS/WEIGHT
Overall length
Overall width
Overall height (at steering wheel)
Wheelbase
Ground clearance
Front wheel tread
Rear wheel tread
Weight (without batteries)
Weight (dry, without battery)
Vehicle Specifications continued on next page...
Page 50
2008 Husqvarna 4210-G, 4210-E, 4210-GXP, and 4210-EXP Owner's Manual
Vehicle Specifications
Electric
Electric
HUV4210-
HUV4210-E
HUV4210-G
EXP
•
•
•
•
•
•
•
•
•
•
•
•
100.2 inches (2545 mm)
45 inches (1143 mm)
46.9 inches (1191 mm)
66.5 inches (1689 mm)
5.5 inches (140 mm)
34.5 in (88 cm)
38.5 in. (98 cm)
874 lb.
889 lb.
(396 kg)
(403 kg)
Gasoline
Gasoline
HUV4210-
GXP
•
•
•
•
•
•
•
•
781 lb.
805 lb.
(354 kg)
(365 kg)
