REPAIR PARTS
SNOW THROWER - MODEL NO. 1130SB-XLS (96193003000), PRODUCT NO. 961 93 00-30
1
3
4
2
1
2
01.04.006
NOTE: All component dimensions given in U.S. inches.
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
3
01.00.023-A
3
4
4
KEY PART
NO. NO.
- - - - - - - -
1 532 41 61-55
2 532 40 37-32
3 532 15 04-06
4 532 18 44-71
KEY PART
NO. NO.
1 532 40 91-61
2 532 17 88-13
3 532 18 77-88
4 532 40 80-08
35

CHASSIS / ENGINE / PULLEYS

DESCRIPTION
TECUMSEH ENGINE
OH318SA-221835B
FRAME
BOTTOM PAN
BOLT 3/8−16
SCREW 10−24 X .625
DESCRIPTION
COVER ASSEMBLY
PULLEY
TRACTION BELT
IMPELLER BELT
1 inch = 25.4 mm
