VADDIO Domeview Installation And User Manual

Camera and Electronic Products for Integrators
D V I E
D V I E
O M E
O M E
Integrated Indoor Pendant Mount Dome Systems
and Indoor Pendant Mount Dome Enclosures for
Sony® and Canon® PTZ Cameras
OVERVIEW:
The Vaddio™ DomeVIEW Indoor Pendant Mount Domes (Figure 1)
are integrated camera mounting systems that are attractive and
easy to install. Designed for indoor security applications, the 7.3"
(18.54cm) Indoor Pendant mount dome enclosure is outfitted with
the internal brackets to support the option of using the Sony EVI-
D70 or the Canon VC-C50iR robotic PTZ cameras.
The DomeVIEW Indoor Pendant Mount Dome Package is sold complete with the Camera. The DomeVIEW
system for the Sony EVI-D70 and the VC-C50iR feature the standard Vaddio EZCamera Cabling System.
The EZCamera cabling solution provides for fast and efficient installations using Cat. 5 cabling for video,
power and control. The enclosures are also sold without the camera to accommodate an existing camera to
be used with the Indoor Pendant Mount Dome enclosure without the EZCamera cabling system.
The Domes are formed from optical grade polycarbonate and are available in clear (standard) or smoked tint
(optional). The DomeVIEW Indoor Pendant Mount Domes are excellent values that are high quality,
attractive and durable solutions for indoor security applications.
This Manual covers the following Vaddio DomeVIEW Indoor Pendant Mount Dome Systems:
999-9100-050 DomeVIEW 50iR Indoor Pendant Dome with Canon VC-C50iR, EZCamera Cabling
System and Internal Mounting Bracket
999-9100-070 DomeVIEW 70 Indoor Pendant Dome with Sony EVI-D70, EZCamera Cabling System
and Internal Mounting Bracket
This Manual covers the following Indoor Pendant Mount Dome Enclosures:
998-9100-050 Indoor Pendant with Internal Mounting Bracket for VC-C50iR (Camera Not Included)
998-9100-070 Indoor Pendant with Internal Mounting Bracket for EVI-D70 (Camera Not Included)
Note: The Indoor Pendant Mount Domes mount to a 1-1/2" NPT Pipe, which are not part of the DomeVIEW packages or the
Indoor Pendant Mount Dome enclosures.

INTENDED USE:

Before operating the DomeVIEW system, please read the entire manual thoroughly. The DomeVIEW Indoor Pendant Mount systems
were designed, built and tested for use indoors and with the provided power supply. The use of a power supply other than the one
provided or outdoor operation has not been tested and could damage the electronics and/or create a potentially unsafe operating
condition.
SAVE THESE INSTRUCTIONS:
The information contained in this manual will help you install and operate your Vaddio DomeVIEW. If these instructions are misplaced,
Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product drawings for the Vaddio product line on
the website. These documents can be downloaded from

IMPORTANT SAFEGUARDS:

Read and understand all instructions before using. Do not operate the system if it has been dropped or damaged. In this case, a Vaddio
technician must examine the product before operating. To reduce the risk of electric shock, do not immerse in water or other liquids and
avoid extremely humid conditions.
ⓒ2009 Vaddio - DomeVIEW Systems - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and
pricing are subject to change without notice. Vaddio, DomeVIEW, EZCamera, Quick-Connect, WallVIEW, CeilingVIEW, EZCable and PowerRite are
trademarks of Vaddio, Inc. All other trademarks are property of their respective owners. Document 341-444 Rev C.
W ™
W ™
www.vaddio.com
Installation and User Guide
Figure 1:
