    572-2 Infrared Thermometer Getting Started PN 4307046 March 2013 ©2013 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
  • Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and work- manship for two years from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from acci- dent, neglect, misuse, alteration, contamination, or abnormal con- ditions of operation or handling.

  • Page 3: Table Of Contents

    Table of Contents Title Page Introduction............1 Safety Information ..........1 Thermometer Use ..........6 Cable Connections and Battery Replacement .. 6 Menu Overview ..........7 Specifications Summary ........9...
  • Page 4 572-2 Getting Started...

  • Page 5: Introduction

    Introduction The 572-2 Infrared Thermometer (the Product) is for non- contact temperature measurement. The Product determines the surface temperature of an object by measuring the amount of infrared energy radiated by the object surface. A K-type thermocouple can be used with the Product for contact- temperature measurement.
  • Page 6 572-2 Getting Started • See emissivity information for actual temperatures. Reflective objects result in lower than actual temperature measurements. These objects pose a burn hazard. • Do not look directly into the laser with optical tools (for example, binoculars, telescopes, microscopes).
  • Page 7 Infrared Thermometer Safety Information For safe operation and maintenance of the Product: • Remove the batteries if the Product is not used for an extended period of time, or if stored in temperatures above 50 °C. If the batteries are not removed, battery leakage can damage the Product.
  • Page 8 572-2 Getting Started See Figure 1 for the safety markings. Laser Aperture hdp01.eps Figure 1. Safety Markings...
  • Page 9 With reference to the equipment types in the WEEE Directive Annex I, this product is classed as category 9 "Monitoring and Control Instrumentation” product. Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information.  Battery...

  • Page 10: Thermometer Use

    572-2 Getting Started Thermometer Use To take a temperature reading, point the Product at the desired object and pull the trigger. You can use the laser pointer to aim the Product. You may also insert the K-type thermocouple probe for contact measurement.

  • Page 11: Menu Overview

    Infrared Thermometer Menu Overview Menu Overview There are many settings that can be changed by using the menu. Table 2 is a top-level description of the menu. Push the Menu button to advance the menu to the next level. Figure 3 shows the LCD and menu interface.
  • Page 12 572-2 Getting Started Table 2. Top-Level Menu Description Left Center Right Level Description Description Softkey Softkey Softkey Save reading Turn on bright Save Menu Light to memory backlight Review / delete ε Menu Set emissivity memories Enables Enable MnMx Menu...

  • Page 13: Specifications Summary

    Infrared Thermometer Specifications Summary Specifications Summary See Users Manual on CD for full specifications. IR Temperature -30 °C to 900 °C (-22 °F to 1652 °F) Range <0 °C: ±(1.0 °C + 0.1 °/1 °C) ≥0 °C: ±1 % or ±1.0 °C, whichever is greater Accuracy <32 °F: ±2 °F ±0.1 °/1 °F ≥32 °F: ±1 % or ±2 °F, whichever is greater...
  • Page 14 572-2 Getting Started Storage Altitude 12,000 meters above mean sea level 10 % to 90 % RH non-condensing up to 30 °C Relative Humidity (86 °F) Operating 0 °C to 50 °C (32 °F to 122 °F) Temperature Storage -20 °C to 60 °C (-4 °F to 140 °F)
