CLEANING THE BURNER GRATES, BURNER CAPS AND
BURNER HEADS
The Grates, Burner Caps and the Large 18k Burner Head should be routinely cleaned.
Keeping the burner ports clean will prevent improper ignition and an uneven flame. If
needed, the fixed burners should be cleaned in place with an humid cloth (do not spraw
water on them).
Refer to the following instructions:
To Remove and Replace the Surface Burner Grate, Surface
Burner Cap and Surface Burner Head - Remove in the
following order; (1st) Surface Burner Grate, (2nd) Surface
Burner Cap, (3rd) Surface Burner Head (See Figure 1).
Reverse the procedure above to replace the Surface Burner
Cap, Surface Burner Head and Surface Burner Grate. Do
not remove any burner parts from the cooktop until the
burner parts have completely cooled and are safe to
handle. Do not operate the surface burners without the
Surface Burner Heads, Surface Burner Caps and
Surface Burner Grates properly in place.
To Clean the Burner Caps, Burner Heads and Burner Grates -
Use a soap-filled scouring pad or a mild abrasive cleaner to clean
the surface burner caps and surface burner heads. The Grates
are designed to be Dishwasher safe for cleaning. The ports (or
slots) around the burner heads must be routinely cleaned. If
residue still remains in these ports, use a small-gauge wire or needle to clean the slots
or holes being careful not to damage the electrode. For proper flow of gas and ignition of
the burner—DO NOT ALLOW SPILLS, FOOD, CLEANING AGENTS OR ANY OTHER
MATERIAL TO ENTER THE GAS ORIFICE HOLDER OPENING. ALWAYS make sure
that the surface burner cap, the surface burner head and the surface burner grate are
properly in place whenever a surface burner is in use.
Surface Burner
Grate
THE COOKTOP IS NOT REMOVABLE. Do not attempt to remove or lift the cooktop.
CA
CAUTION
CA
UTION
UTION
UTION
CA
CA
UTION
!
- Use caution when replacing the burner head so the electrode is not damaged. A damaged
electrode may cause a delayed ignition or prevent the burner from igniting
- Any additions, changes or conversions required in order for this appliance to perform
satisfactorily must be made by a qualified service technician.
General Care & Cleaning
General Care & Cleaning
General Care & Cleaning
Surface Burner
Caps
1st
2nd
3rd
Orifice
Electrode
Surface Burner
Head
15
Surface Burner
Grate
Surface
Burner
Cap
Surface
Burner
Head
Figure 1
