GAS Pressure Washer
039-8578-4
Congratulations on the purchase of your new pressure
washer. In order to ensure you have the best possible
experience please read through the following instructions.
If you require any help please contact the customer ser-
vice department at:
1-866-4SIMONIZ
(1-866-474-6664)
Contact us for assistance, we're here to help.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 039-8578-4 and is the answer not in the manual?

Questions and answers

Related Manuals for Simoniz 039-8578-4

Summary of Contents for Simoniz 039-8578-4

  • Page 1 GAS Pressure Washer 039-8578-4 Congratulations on the purchase of your new pressure washer. In order to ensure you have the best possible experience please read through the following instructions. If you require any help please contact the customer ser- vice department at:...

  • Page 2: Table Of Contents

    Table of Contents 1. Safety Advice......................3 1.1 Definitions......................3 1.2 Safety Warnings....................3 1.3 Intended Application..................7 2. Scope of Delivery....................8 3. Parts List.......................10 4. Assembly Instructions..................12 5. Engine Operation....................14 5.1 Adding/Checking Oil..................14 5.2 Adding Fuel.....................14 5.3 Checking Air Filter...................15 5.4 Starting Engine....................15 5.5 Stopping Engine....................15 6.

  • Page 3: Safety Advice

    Safety Advice 1. S AFETY DVICE TOXIC GASES IMPORTANT, RETAIN FOR FU- Alerts against possible toxic gases which can be TURE REFERENCE AND harmful to your health or deadly if you are exposed to them. READ CAREFULLY! Do not attempt to install or operate this product FLAMMABLE AND COMBUSTIBLE MA- until you have read the safety instructions in this TERIALS...
  • Page 4 Safety Advice 1.2 Safety Warnings DANGER–WORK AREA SAFETY AND WARNING–PERSONAL SAFETY EXHAUST FUMES • Stay alert, watch what you are doing, and use • Keep work area clean and well lit. Cluttered and dark common sense when operating a pressure washer. areas incite accidents.
  • Page 5 Safety Advice 1.2 Safety Warnings FLAMMABLE AND POISONOUS MATE- CAUTION–ENGINE SAFETY RIALS • Certain components in this product and its related • Gasoline is highly flammable and its vapours can accessories contain chemicals which are known to explode if ignited. Take precautions when using fuel cause cancer, birth defects, or other reproductive to reduce the chance of serious personal injury.
  • Page 6 Safety Advice 1.2 Safety Warnings CAUTION–SPECIFIC SAFETY ADVICE • • This product is capable of producing high pressure CAUTION–SPECIFIC SAFETY ADVICE as rated in the Technical Specifications. To avoid • Avoid dangerous conditions. Always operate this rupture and injury, do not operate this product with product on dry, solid and level ground.

  • Page 7: Intended Application

    This equipment was not designed for industrial use. Please refer to the icons below for suggested applica- tions. For questions regarding other uses, please refer to our website at www. simoniz.ca or call us at IMPORTANT–SAFETY FEATURES 1-866-4SIMONIZ (1-866-474-6664). • • Thermal Relief Valve: Protects the pump from overheating in case the nozzle gets clogged.

  • Page 8: Scope Of Delivery

    Scope of Delivery 2. S COPE OF ELIVERY Ref. Description Qty. Visual Main Frame Wheel with Axle Spray Gun with Metal Wand High-Pressure Hose (50ft) Gun Holder Gun Storage Hose Hook Knob Bolt(M5x50), Washer(5), Nut(M5) 2sets Water Inlet Filter...
  • Page 9 Scope of Delivery 2. S COPE OF ELIVERY Ref. Description Qty. Visual Spray Tip Cleaner Pump Breather Spare O-Rings (2 for high pressure hose, 1 for quick-connector) Oil funnel Wrench Spark Plug Wrench Screwdriver...

  • Page 10: Parts List

    Parts List 3. P ARTS...
  • Page 11 Parts List 3. P ARTS Ref. Description Ref. Description Spray Nozzles (x5) Engine I/O Switch Muffler Detergent Dial Air Filter Detergent Tank Caps Choke Lever Close-Open Pressure Hose(15 meters) Fuel Valve OFF-ON Pump Detergent Inlet Start Cord Handle Pump Fresh Water Inlet 3/4” Throttle Lever LOW-HIGH Spark Plug Trigger Safety Lock...

  • Page 12: Assembly Instructions

    Assembly Instruction 4. A SSEMBLY NSTRUCTIONS Letters refer to Scope of Delivery diagrams on pages 8 and 9. Lift the main frame (A) with one hand and at- tach one of the wheels (B) by pressing the Attach gun holder (E) to the upper position of wheel’s pin and inserting the wheel shaft into frame, secure with bolt, washer, nut (I).

  • Page 13: Assembly Instruction

    Assembly Instruction 4. A SSEMBLY NSTRUCTIONS Use a wrench (not included) to unscrew the hex Insert the water inlet filter (J) into the pump screw on the pump unit (22), and then with your fresh water inlet (17). Then attach a garden hose or other means of water supply (not pro- hand screw the pump breather (L) in.

  • Page 14: Engine Operation

    Engine Operation 5. E NGINE PERATION 5.1 Adding/Checking Oil 5.2 Adding Fuel IMPORTANT WARNING • • • Make sure there is enough fuel in the fuel tank Oil has been drained for shipping. Failure to fill en- gine with oil before starting engine will result in per- fore operating the pressure washer.

  • Page 15: Checking Air Filter

    If you have problems starting the pressure washer, housing. call the Simoniz toll-free number at 1-866-4SIMONIZ 5.3 Stopping Engine (1-866-474-6664) and one of our customer service • To stop the engine move the choke lever (4) representatives will be glad to assist you.

  • Page 16: Operating Instructions

    Operation Instructions 6. O PERATION NSTRUCTIONS 6.1 Using Spray Nozzle 6.3 Adjusting Water Pressure This pressure washer comes with 5 different The water pressure can be adjusted using the nozzles (1) that can be installed on the stain- throttle lever (7). •...

  • Page 17: Cleaning With Detergents

    6.6 Shutting Down and Cleaning Up Follow the detergent manufacturer’ s directions or call the Simoniz toll-free number at 1-866-4SIMONIZ 1. Skip step two if you are not using detergent. (1-866-474-6664) if you have any questions or con- 2.

  • Page 18: Engine Maintenance

    Cleaning and Maintenance 7. C LEANING AND AINTENANCE Inspecting, Replacing or Cleaning the Spark Plug WARNING The spark plug should be checked every 100 DO NOT operate this pressure washer without the hours of operation or every 6 months. water inlet filter in place, as deposits could build up internally and affect the functioning of the unit.

  • Page 19: Cleaning The Spray Tips

    Cleaning and Maintenance 7. C LEANING AND AINTENANCE 3. Check the gap with a wire gauge. If neces- 7.4 Storing sary, reset the gap to 0.7-0.8 mm. Install and Store idle product out of the reach of children tighten the spark plug to the recommended and do not allow persons unfamiliar with the torque–180 lb-in (20 Nm).

  • Page 20: Winterizing Procedures

    Cleaning and Maintenance/Technical Specifications 7. C LEANING AND AINTENANCE IMPORTANT • If the pressure washer is to be stored with gasoline in the fuel tank and carburetor, it is important to re- duce the hazard of gasoline vapor ignition. • Select a well-ventilated storage area away from any appliance that operates with a flame, such as a furnace, water heater, or clothes dryer.

  • Page 21: Troubleshooting

    NOTE: If your unit still is not functioning properly once you have used this guide please call the SIMONIZ toll-free service number at 1-866-4SIMONIZ (1-866-474-6664). Please do NOT bring the unit back to the store until you have called this number.
  • Page 22 Troubleshooting 9. T ROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Nozzle tip not attached Attach required nozzle tip Turn on faucet. Ensure there are Water supply faucet closed no kinks or blockage in hose Ensure faucet is fully opened. Water supply pressure is Check to make sure water supply is a minimum 30 psi, 4 GPM Clean the water filter.

  • Page 23: Limited Warranty

    The warranty is void if the equipment is used for commercial, rental, or industrial purposes. If you have further questions, please visit our website (www.simoniz.ca) or call 1-866-4SIMONIZ (1-866-474-6664).

  • Page 24: Explosion View

    Explosion View 11. E XPLOSION...
  • Page 25 Explosion View 11. E XPLOSION Brake Line Locknut M5 φ32 Plug Cross Pan Head Screw M5×50 Over Flow Valve Cap Gun Holder φ8 Spring Washer Locknut M6 Plain Washerφ6 Inner Hexagon Bolt M8×25 Thermal Relief Cap Wand Drain Pipe Engine Isolator Knob Component 6.5HP Kohler Engine Circlip φ8...
