User manual Version 1.1
SE5408/SE5416 Multi-port Serial Server
5. Web-based Configuration
The Web-based configuration method is the most common method to set up SE5408/SE5416 Multi-Port
Serial Server, and is the most user-friendly one as well. The only thing you need to do is to make sure that
the SE5408/SE5416 Multi-Port Serial Server to be configured is on the same LAN as the host computer.
The rest of configuration is fairly self-explanatory.
Login to System
Every SE5408/SE5416 Multi-Port Serial Server device is equipped with a built-in Web server in the
firmware. Therefore, it can be accessed by using a web browser to configure device's parameters.
While on a Web browser, enter the device IP (for example,
http://10.0.50.100
if it connects to LAN1 port or
http://192.168.1.1
if it connects to LAN2 port), and the following authentication screen shall appear. If the
device is connected to LAN1 port, the default IP address is 10.0.50.100, or if it is connected to LAN2 port,
the default IP address is 192.168.1.1. Enter User name (default: admin) and Password (default: blank)
then click "OK".
Fig 13. First (Authentication) Screen on a Web Browser
General Information
Once the User name and Password are correctly entered, the Overview window (Fig 14) shall appear.
Fig 14. Overview Window: Web Configuration
Copyright © 2010 ATOP Technologies, Inc.
All rights reserved. Designed in Taiwan
- 19 -
