- Page 1 OPERATION MANUAL for AUTOMATIC LEVELING SYSTEMS WITH TOUCH PAD # 500629 or 140-1226 CONTROL BOX # 500630 or 140-1227 CONTENTS Page Before you level your coach Operating Instructions Retracting your leveling jacks Manually operating your jacks Preventive maintenance Warranty information 1217 E.
- Page 2 Before You Level Your Coach Park brake must be set and transmission must be in “park” (“neutral” for diesel coaches) before jacks will operate. Check leveling site to make sure obstructions have been cleared away for proper jack operation. Selecting a site: When the coach is parked on an excessive slope the leveling requirements may exceed the jack lift stroke capability.
-
Page 3: Operating Instructions
Operating Instructions Automatic Front Jacks mode button Button Manual operation Right Jack button (push and Button hold for 5-7 seconds) Rear Jacks Left Jack Button Button LEVELING YOUR COACH 1. Turn on the ignition and start the coach. Your leveling control will start a self check sequence indicated by the lights on the panel blinking in a rotating pattern. - Page 4 Manually Operating Your Leveling Jacks There are certain conditions where manually leveling your coach may be desirable. Conditions where large amounts of side to side leveling are necessary may work better using the manual leveling procedures that follows. 1. Turn on the ignition and start the coach. 2.
-
Page 5: Preventative Maintenance
PREVENTATIVE MAINTENANCE WARNING Your coach should be supported at both front and rear axles POWER GEAR LIMITED WARRANTY with jack stands before working underneath, failure to do so may result in personal injury or death. Power Gear warrants to the original retail purchaser that the product will be free from defects 1. -
Page 6: Troubleshooting Tips
TROUBLESHOOTING TIPS Locations of breakers, fuses, fuse panels, etc. are coach specific. Consult your coach owner’s manual or the coach manufacture for locations of these components. The following information will guide you to repairs that may be made on site. For problems not covered here, contact your service center or our website for more extensive troubleshooting information in the service manual for your system. - Page 7 ANY JACK RETRACTS VERY SLOWLY PROBABLE CAUSE CORRECTIVE ACTION JACK ROD GUIDE IS RUSTED OR CLEAN CHROME ROD, GREASE ROD GUIDE DIRTY IF EQUIPPED WITH GREASE FITTINGS. OTHERWISE LUBRICATE WITH SILICONE FLUID. IT MAY BE NECESSARY TO RESEAL JACK OR REPLACE. ANY JACK RETRACTS WITH NO POWER, WITH POSSIBLE POPPING SOUND PROBABLE CAUSE CORRECTIVE ACTION...
