BioSmart
BioSmart
®
B
Therapeutic Infrared Heat
In-Wall Heater
Owner's Manual
Therapeutic infrared heating systems
for a green, healthy environment
In-Wall Far Infrared Heaters.
.
S
I O
M A R T
Air Filtration Technology
Technologies
Feel the Difference.
with Patented BioSmart
Save these
Instructions
Includes:
Application Guidelines
User Information & Guidelines
Operating Instructions
Warranty & Servicing
.
®
®
Advertisement
Table of Contents
Related Manuals for Bio Smart Technologies BioSmart 500F
Summary of Contents for Bio Smart Technologies BioSmart 500F
- Page 1 BioSmart Technologies Feel the Difference. BioSmart In-Wall Far Infrared Heaters. ® M A R T ® Therapeutic Infrared Heat In-Wall Heater Owner’s Manual Therapeutic infrared heating systems for a green, healthy environment with Patented BioSmart ® Air Filtration Technology Save these Instructions Includes: Application Guidelines...
- Page 2 BioSmart® BIO-1000F In-Wall Edition Far Infrared Heater Customer/Warranty Service: 800-595-9605...
-
Page 3: Table Of Contents
Page 1 Table of Contents Congratulations on Your Purchase! Why Use a BioSmart Heater ® Far Infrared Technology Benefits Unpacking Your New BioSmart Heater ® Heater Care USE RESTRICTIONS BioSmart 500F Features & Functions ® BioSmart 1000F Features & Functions ®... -
Page 4: Congratulations On Your Purchase
Page 2 Congratulations on Your Purchase! Congratulations on purchasing your BioSmart Therapeutic Ceramic Far Infrared ® Heater! One of the best things about using your new BioSmart Therapeutic Ceramic Far Infrared ® Heater is the money you will save on gas and electric bills. - Page 5 Page 3 soft far infrared heat is a better, more comfortable and more healthy way to heat a room. There are many therapeutic benefits that can be attributed to far infrared heat. Its use as an integral part of many medical therapies is well documented.
-
Page 6: Why Use A Biosmart ® Heater
Page 4 Why Use a BioSmart Heater ® BioSmart® heating systems are the ultimate in green technology engineering -- easy to install, exceptionally economical and extremely quiet, they produce comfortable, healthy, therapeutic far infrared heat. BioSmart® heaters also purify the air that is processed through them, making them a sanitary source of heat. - Page 7 Page 5 Better Heat Distribution The nature of far infrared waves allows the heater to be installed higher on the wall than conventional wall heater systems without compromising the transfer of the heat to the floor. The advantage of the higher installation on the wall guarantees that furniture and other obstructions to the airflow from the heater are eliminated.
-
Page 8: Far Infrared Technology Benefits
Page 6 Far Infrared Technology Benefits Temperature (Fahrenheit) Customer/Warranty Service: 800-595-9605... -
Page 9: Unpacking Your New Biosmart ® Heater
Page 7 WARNING ANY REQUIRED SERVICE SHOULD ONLY BE PERFORMED BY AN AUTHORIZED SERVICE REPRESENTATIVE CAUTION: RISK OF ELECTRICAL SHOCK DISCONNECT POWER BEFORE SERVICING USE RESTRICTIONS READ ALL INSTRUCTIONS BEFORE USING THE HEATER • DO NOT alter the heater’s design, or you will void the warranty. •... -
Page 10: Biosmart ® 500F Features & Functions
Page 8 BioSmart 500F Features & Functions ® Heat Register Cabinet cover Intake Customer/Warranty Service: 800-595-9605... -
Page 11: Biosmart ® 1000F Features & Functions
Page 9 BioSmart 1000F Features & Functions ® Heat Register Cabinet cover Intake ©2013 BioSmart Technologies... -
Page 12: How Many Units Do I Need
Page 10 How many units do I need? When determining the number of units you will need, take into consideration: • The insulation factor, and window size & placement • The mean outside temperature during the coldest days of the year •... - Page 13 Page 11 Backets for BIO-1000F new installation Backets for BIO-500F retrofit installation ©2013 BioSmart Technologies...
- Page 14 Page 12 Heater Wiring Regardless of the model chosen, there are 5 wires inside the base of the heater which must be wired correctly. Three wire contacts are required to obtain the power source. The wiring code is the same for 120 volt units. The heater must be provided with a disconnect device (switch/breaker) from the supply mains having a contact separation in all poles that provide full disconnection with a contact separation of at least 3 mm.
-
Page 15: Wiring Diagrams
Page 13 Wiring Diagrams BIO-1000F/120v Wiring Schematic * Switch must have a contact separation in all poles that provide full disconnection with a contact separation of at least 3 mm and rated 10A minimum. BIO-500F/120v Wiring Schematic ©2013 BioSmart Technologies... -
Page 16: For Your Safety/Warning
Page 14 For Your Safety/Warning Do not place objects in front of infrared wall units that have been mounted lower than those parameters suggested in the installation instructions. Doing so will cause the unit to overheat, which will trigger the high temperature limit switch, resulting in a potential service call to reset/ replace the switch. -
Page 17: Troubleshooting Your Biosmart ® Heater
Page 15 Troubleshooting Your BioSmart Heater ® Problem Solution Check for any objects that could obstruct airflow. Heater’s airflow is If the heater’s airflow is still diminished or has reduced. stopped, please call Customer Service. Heater fan still on This is most likely a defective fan relay. Please call 20 minutes after Customer Service. -
Page 18: Biosmart ® 1000F In-Wall Heater Specifications
Page 16 BioSmart 1000F In-Wall ® Heater Specifications Model BIO-1000F Cabinet: All metal - 22 & 24 gauge with synthetic, • paintable shell Weight: 13 lbs • • Dimensions: 16” x 12 5/8” x 4” (HxWxD) Power Requirements: 120 or 220 volt AC •... -
Page 19: Biosmart ® 500F In-Wall Heater Specifications
Page 17 BioSmart 500F In-Wall Heater ® Specifications Model BIO-1000F Cabinet: All metal - 22 & 24 gauge with synthetic, • paintable shell Weight: 8 lbs • • Dimensions: 20 1/2” x 4 3/4” x 4” (HxWxD) Power Requirements: 120 or 220 volt AC •... -
Page 20: Diagram Of Biosmart ® 1000F In-Wall Heater
Page 18 Diagram of BioSmart 1000F In-Wall Heater ® Cover Top Case Bracket Case Bottom Case Bracket Heater Core Ceramic Heating Element D. Grill PCBoard Fan Holder M. Baffle Fans N. Heat Resistant Insert G. Insulator Cover O. Solid state relay H. -
Page 21: Diagram Of Biosmart ® 500F In-Wall Heater
Page 19 Diagram of BioSmart 500F In-Wall Heater ® A. Front Cover N. Inside Insulator Cover B. Grill O. Insulator C. IR and Sensor Case Top P. Outside Insulator Cover D. IR and Sensor Case Bottom Q. Case E. Fan Case R. -
Page 22: Warranty & Service Information
Page 20 Warranty & Service Information Five-Year Limited Warranty BIOSMART TECHNOLOGIES (BT) warrants this product, to the original purchaser or gift recipient, to be free from defects in workmanship and materials under normal use and service, for a period of one year from the date of purchase. - Page 23 Page 21 Warranty & Service Information (continued) IN NO EVENT SHALL BT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS OF PROFIT, OR MEDICAL EXPENSES CAUSED BY ANY DEFECT, FAILURE, MISUSE, OR MALFUNCTION OF THE PRODUCT. Note: Some jurisdictions do not allow the exclusion of limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
- Page 24 BioSmart® Far Infrared Heaters Green Technology for a Modern World North American Distribution and Sales BioSmart Technologies d, Suite 1 18324 Cook Roa Yelm, Washington 98597 Customer/Warranty Service: 800-595-9605 www.BioSmartSolutions.com...
