PROXIMITY TOILET
CONCEALED FLUSH VALVE
1.28 & 1.6 GPF
Certified to comply with ASME A112.19.2M
© 2010 AS America, Inc.
M968550 REV. 1.5
NOTE TO INSTALLER: Please give this manual to the customer after installation.
To learn more about American Standard Faucets visit our website at: www.americanstandard-us.com
or U.S. customer's e-mail us at: faucetsupport@americanstandard.com
For Parts, Service, Warranty or other Assistance,
1-800-442-1902 (In Canada: 1-800-387-0369)
please call
Concealed Flushometer
for 1-1/2" Top or Back Spud Bowls
CLOG RESISTANT
• Self-cleaning piston valve prevents clogging and reduces maintenance.
ONE SENSOR FITS ALL
• Only 1 sensor for entire Selectronic™ line of faucets, urinals, and
flush valves.
• Range can be adjusted manually or with optional remote control.
• Sensor Features Low Battery Indicator.
(In Toronto Area only: 1-905-3061093)
(In Toronto Area only: 1-905-3061093)
MODEL NUMBERS
6065.22X
6065.26X
6067.22X
6067.26X
6068.22X
6068.26X
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for American Standard SELECTRONIC 6065.22X
Summary of Contents for American Standard SELECTRONIC 6065.22X
- Page 1 M968550 REV. 1.5 NOTE TO INSTALLER: Please give this manual to the customer after installation. To learn more about American Standard Faucets visit our website at: www.americanstandard-us.com or U.S. customer's e-mail us at: faucetsupport@americanstandard.com For Parts, Service, Warranty or other Assistance,...
-
Page 2: Installation Instructions
M968550 REV. 1.5 NOTE TO INSTALLER: Please give this manual to the customer after installation. To learn more about American Standard Faucets visit our website at: www.americanstandard-us.com or U.S. customer's e-mail us at: faucetsupport@americanstandard.com For Parts, Service, Warranty or other Assistance,... -
Page 3: Roughing-In Dimensions
Fig. 1 Roughing-in Dimensions 160mm (6-1/4) 160mm (6-1/4) OVERRIDE BUTTON SENSOR 406mm (16) SUPPLY DN 25mm (1) I.P.S. -C-L- 115mm-134mm (4-1/2 TO 5-1/4) -C-L- 152mm 403 TO 441mm (6) MIN. (15-7/8) MIN. TO (17-3/8) MAX. 51mm TOP SPUD 483mm TOILET (19) MAX. - Page 4 INSTALL ELECTRICAL BOX ASSEMBLY; Fig. 3 1. Cut a 127x127mm (5"x 5") opening in finished wall for ELECTRICAL BOX (1) at the deminsion shown in Fig.3. 2. Rotate the 4 MOUNTING TABS (2) flat against the electrical box. Holding the MOUNTING TABS (2) in position install the ELECTRICAL BOX (1) into the opening.
-
Page 5: Installation
4 INSTALL VACUUM BREAKER AND FLUSH CONNECTIONS; Fig. 6 1. Place the SPUD FLANGE (1) over the spud on the Fixture. Fig. 6. 2. Thread SPUD COUPLING NUT (2) onto Spud. Make sure SEAL WASHER (4) and FRICTION WASHER (3) are installed. - Page 6 INSTALL FLUSH VALVE; Fig. 8 1. Insert the side ADJUSTABLE TAILPIECE (1) on the FLUSH VALVE (2) into the SUPPLY STOP (3). Lubricate the TAILPIECE O-RING (4) with water if necessary. Lightly tighten COUPLING NUT (5). Fig. 8. Important: Do not use lubricants (other than water) or any type of thread sealing paste or tape.
- Page 7 CONNECT FRONT PANEL TO ELECTRICAL BOX (AC POWER); Fig. 10 1. Remove the four COVER SCREWS (1) and COVER from (2) ELECTRICAL BOX (4). Fig. 10. 2. Pull the CIRCUIT BOARD (3) out from ELECTRICAL BOX (4). Fig. 10. 3. Knock out lower blank in ELECTRICAL BOX (4) with flat blade screwdriver.
- Page 8 CONNECT FRONT PANEL TO ELECTRICAL BOX (DC POWER BATTERY); Fig. 11 1. Remove the four COVER SCREWS (1) and COVER (2) from ELECTRICAL BOX (3). Fig. 10. 2. Install BATTERY (4) into holder on DC circuit board. Press BATTERY (4) down (contacts facing downward) into position until tabs lock BATTERY (4) into place.
- Page 9 CONNECT OVERRIDE HOSES, AC & DC POWER; Fig. 13 1. Push the BLACK HOSE (1) into the BOTTOM HOSE CONNECTOR (2) and the other end into the back of the OVERRIDE SWITCH (3). 2. Push the BLUE HOSE (4) into the TOP HOSE CONNECTOR (5) on the valve and the other end into the BOTTOM CONNECTOR (6) on the OVERRIDE SWITCH (3).
- Page 10 Fig. 15 Unit #1 T O P SENSOR WIRE FOR AC-VERSION (MULTI HOOK-UP); Fig. 15, 15a . Remove the COVER SCREWS (1) and COVER (2) from each ELECTRICAL BOX (3). 2. See AC Version Electrical Hook-up for Unit #1 of the Multi hook-up.
- Page 11 HOW TO INSTALL NEW BATTERY; Fig. 16 1. Remove FRONT PANEL. For removing front panel see Step 9 for instructions. 2. Remove the four COVER SCREWS (1) and COVER (2) from ELECTRICAL BOX (3). Fig. 16. 3. Disconnect GREY SENSOR WIRE (4) from CIRCUIT BOARD (5).
- Page 12 HOW TO SET DETECTION RANGE (If Required) ; Fig. 18 & 19 Note: The detection distance is preset and is ideal for most installations. Should an adjustment be required follow the steps below. 1. Remove FRONT PANEL (1). See Step 9 for removing front panel instructions.
- Page 13 M968550 REV. 1.5...
-
Page 14: Model Numbers
A922267-0070A ROUND GROMMET A922290-0070A POWER SUPPLY GROMMET M962745-0070A ELECTRICAL BOX ASSEMBLY M962747-0070A COVER WITH SCREWS M962749-0070A CHAIN ASSEMBLY A906680-0070A BONNET NUT M962664-0070A SOLENOID ASSEMBLY M962663-0070A PISTON ASSEMBLY M962750-0070A MANUAL VALVE HOSE KIT M962751-0070A VACUUM BREAKER ASSEMBLY M962752-0020A SLIP JOINT COUPLING A901978-0070A A901978-0070A ELBOW...
