INSTALLATION AND USER INSTRUCTIONS
FOR THE GAS RANGE TOP FOR THE HOME
MODEL RGTNB
THIS APPLIANCE WAS DESIGNED FOR EASE OF INSTALLATION AND OPERATION. HOWEVER, WE
RECOMMEND THAT YOU READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN INSTALLA-
TION. INSTALLATION IS TO BE PERFORMED BY AN APPROVED GAS INSTALLATION OR GAS SER-
VICE TECHNICIAN. IN THE COMMONWEALTH OF MASSECHUSETTS A LICENSED PLUMBER OR
GAS FITTER CAPABLE OF REVIEWING AND PERFORMING THE MANUFACTURER'S INSTALLATION
CHECKLIST SHOULD INSTALL THIS APPLIANCE. THE INSTALLATION CHECKLIST IS INCLUDED AT
THE REAR OF THIS BOOKLET.
DO NOT REMOVE PERMANANTLY AFFIXED LABELS, WARNINGS OR DATA PLATES FROM YOUR
APPLIANCE. THIS MAY VOID THE MANUFACTURER'S WARRANTLY AND/OR HINDER EFFECTIVE
SERVICING AND MAINTENANCE.
THESE INSTRUCTIONS ARE TO REMAIN WITH THE APPLIANCE AND THE CONSUMER IS TO RETAIN
THEM FOR FUTURE REFERENCE.
WARNING: If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage, personal injury or death.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance
Do not touch or activate any electrical switch
Do not use any phone in your building
Immediately call your gas supplier from a neighbor's house
Follow the gas supplier's instructions
If you cannot reach your gas supplier, call the fire department
© Copyright 2007 Prizer –Painter Stoves Works
RGTNB 2008
Advertisement
Table of Contents
Related Manuals for BlueStar RGTNB
Summary of Contents for BlueStar RGTNB
- Page 1 INSTALLATION AND USER INSTRUCTIONS FOR THE GAS RANGE TOP FOR THE HOME MODEL RGTNB THIS APPLIANCE WAS DESIGNED FOR EASE OF INSTALLATION AND OPERATION. HOWEVER, WE RECOMMEND THAT YOU READ ALL SECTIONS OF THIS MANUAL BEFORE YOU BEGIN INSTALLA- TION. INSTALLATION IS TO BE PERFORMED BY AN APPROVED GAS INSTALLATION OR GAS SER- VICE TECHNICIAN.
-
Page 2: Introduction
Our quality policy is monitored by the highest levels of management. We hope you enjoy your new appliance and we THANK YOU again for believing in our product as much as we do. The staff and team at BlueStar! RGTNB 2008... -
Page 3: Welcome
You have purchased one of the finest appliances available for home use, which shows that you take cooking seriously. As the owner of a new BlueStar appliance you can look forward to years of cooking enjoyment. You will prepare meals with the speed and accuracy of a professional chef right in your own kitchen! All equipment is designed and manufactured to the highest quality standards in the industry spe- cifically to meet the needs of the world’s most demanding chefs: you. -
Page 4: Table Of Contents
Cleaning ............................... 16 Body ............................16 Burners ..........................16 Griddle Plates .......................... 16 Charbroiler ..........................16 French Top ..........................17 Helpful Hints ..........................18-19 Care and Maintenance ........................20 Troubleshooting ........................... 21 Warranty ............................22-23 Performance Checklist ........................24-25 RGTNB 2008... -
Page 5: Safety Instructions
WARNING Operation of this product could expose you to carbon monoxide if not adjusted properly. Inhala- tion of carbon monoxide is known to the state of California to cause birth defects or other repro- ductive harm. RGTNB 2008... -
Page 6: Site Preparation
SITE PREPARATION RGTNB 2008... - Page 7 • If the appliance is installed in an island or cabinet cut-out the edges should be shimmed with small metal coupons RGTNB 2008...
-
Page 8: Installation
INSTALLATION Range top Dimensions for RGTNB RGTNB 2008... -
Page 9: Unpacking
3. Move the container as close to its installa- shipped with your appliance. Make sure tion location as possible. This will reduce no hardware or accessories are left to be moving and handling your appliance once disposed of unintentionally. it is out of its shipping container. RGTNB 2008... -
Page 10: Backguard
This chan- All backguards follow the same basic installa- nel provides extra support for the higher rise tion. Using hardware supplied, align the of the 21 inch back. backguard with the wrap around on each side RGTNB 2008... -
Page 11: Gas Connections
Under no circumstances should the detect all the small leaks that a soapy so- factory installed regulator be removed or lution will. by-passed. 15. Air shutter adjustments are preset at the RGTNB 2008... -
Page 12: Electrical Connections
BACKGUARD WHILE IN USE. THIS COULD 7. We recommend the circuit for your appli- OBSTRUCT THE VENTING SYSTEM OF THE ance be a non-GCFI dedicated line. OVEN’S FLUE PRODUCTS. 8. It is recommended that your circuit never include a microwave oven. RGTNB 2008... -
Page 13: Operation
• After approximately 30 minutes, wipe any reason. away the oil and apply a second coat. • At the High setting, flames should be Wipe away the excess. RGTNB 2008... -
Page 14: Charbroiler
Adjust the flame to the desired height. to the burner the sparking ignites it. After • After cooking allow to cool completely. the flame lights the ignitor senses its heat • Remove the drip pan slowly, discard and the clicking automatically stops. RGTNB 2008... -
Page 15: French Top
• Allow to cool when done cooking. • Never flood a hot steel plate with cold wa- ter. This may cause the steel to crack or warp and will void your warranty. RGTNB 2008... -
Page 16: Cleaning
• Remove the drip pan by pulling straight GRIDDLE PLATES toward you - SLOWLY. • Always allow the griddle to cool before • Beware to avoid spilling the pan. Clean trying to clean it. with hot soapy water. RGTNB 2008... -
Page 17: French Top
Be sure to follow the manu- facturer’s instructions for use. After use, rinse TWICE – once with vinegar and wa- ter, then with plain water. Insure the cleaning chemical does not come in con- tact with any painted surfaces on your ap- pliance. RGTNB 2008... -
Page 18: Helpful Hints
• A front top grate may be removed and the cooking pan placed directly into the cut- out for stir-fry cooking. Suggested Griddle Settings Eggs Pancakes Medium High Hamburgers or High Steaks (rare) Hamburgers or Medium High Steaks (medium) Grilled Sandwiches Medium RGTNB 2008... -
Page 19: Helpful Hints
1” thick Middle Rack Medium-High 10-15 minutes 1/2 “ Thick Top Rack Medium-High 8-10 minutes Chicken Boneless Breast Middle Rack Medium 15 minutes/side Leg & Thigh Lower Rack Medium 25 minutes/side Garlic Bread Lower Rack Medium 3-5 minutes RGTNB 2008... -
Page 20: Care And Maintenance
(22K) the cones are close together and blend into one another. Yellow tips nor- mally flicker occasionally with natural gas, more often with propane. The flame should be almost all blue all the time. RGTNB 2008... -
Page 21: Troubleshooting
Call for service. LAZY flame—floating, larger in size than Air shutter adjustment or problem with gas normal supply. LIFTING flame—well defined with visible Air shutter adjustment or problem with gas inner core, noisy, gap between burner and supply. flame RGTNB 2008... -
Page 22: Warranty
Prizer-Painter is willing and able to repair and/or replace defective Products in the manner prescribed herein or to provide a refund if, in Prizer-Painter's sole judgment, repair or replacement is not feasible or appropriate under the circumstances. RGTNB 2008... -
Page 23: Warranty
All warranty repairs must be performed by a factory authorized service agent. Service will be provided during normal business hours. The purchaser will be responsible for any labor performed at over-time or premium rates. The pur- chaser is also responsible for making the Product accessible for service. RGTNB 2008... -
Page 24: Performance Checklist
Oven Burner Oven Burner Oven Burner French Top Broiler French Top Broiler French Top Broiler French Top Broiler Controls Oven Door Burner knobs Alignment Thermostats Door seal Convection oven fan & switch Hinges Oven light switch CUSTOMER COPY RGTNB 2008... - Page 25 Infrared Broiler Infrared Broiler Infrared Broiler French Top Broiler French Top Broiler French Top Broiler French Top Broiler Controls Oven Door Burner knobs Alignment Thermostats Door seal Convection oven fan & switch Hinges Oven light switch MAIL-IN COPY RGTNB 2008...
