Features and Specifications
Electrical Specifications
Table 1.3 Electrical Specifications for 60 V to 250 V Models
Models
Output Ratings:
Line Regulation:
Load Regulation:
Meter Accuracy:
Stability:
Temperature Coefficient
Front Panel Voltage:
1. For input voltage variation over the AC input voltage range, with constant
2. For 0 to 100% load variation, with constant nominal line voltage.
3. Maximum drift over 8 hours with constant line, load, and temperature, after
4. Change in output per °C change in ambient temperature, with constant line
16
Output Voltage
Output Current
Output Power
1
Voltage (0.01% of Vmax + 2 mV)
Current (0.01% of Imax + 250 uA)
2
Voltage (0.01% of Vmax + 2 mV)
Current (0.01% of Imax + 250 uA)
Voltage (1% of Vmax + 1 count)
Current (1% of Imax + 1 count)
3
Voltage (0.02% of Vmax)
Current (0.03% of Imax)
Voltage (0.015% of Vmax/°C)
Current (0.02% of Imax/°C)
Control Resolution
(0.02% of V max)
rated load.
30-minute warm-up.
and load.
60-1
0-60 V
0-1 A
60 W
8 mV
0.35 mA
8 mV
0.35 mA
0.7 V
0.02 A
12 mV
0.3 mA
4
9 mV
0.2 mA
12mV
120-0.5 250-0.25
0-120 V 0-250 V
0-0.5 A 0-0.25 A
60 W 60 W
14 mV 27 mV
0.3 mA 0.275 mA
14 mV 27 mV
0.3 mA 0.275 mA
2.2 V 3.5 V
0.006 A 0.003 A
24 mV 50 mV
0.15 mA 0.075 mA
18 mV 37.5 mV
0.1 mA 0.05 mA
24mV 50mV
