Electrical Specifications

Specifications are warranted over a temperature range of 0 to 30 °C with default
local sensing. Above 30 °C, derate output linearly to zero at 70 °C. Specifications are
subject to change without notice.
Table 1.2 Electrical Specifications for 7.5 V to 30 V Models
Models
Output Ratings:
Line Regulation:
Load Regulation:
Meter Accuracy:
Stability:
Temperature Coefficient
Front Panel Voltage:
1. For input voltage variation over the AC input voltage range, with constant rated load.
2. For 0 to 100% load variation, with constant nominal line voltage.
3. Maximum drift over 8 hours with constant line, load, and temperature, after 30-minute
4. Change in output per °C change in ambient temperature, with constant line and load.
Release 2.2
Output Voltage
Output Current
Output Power
1
Voltage (0.01% of Vmax + 2 mV)
Current (0.01% of Imax + 250 uA)
2
Voltage (0.01% of Vmax + 2 mV)
Current (0.01% of Imax + 250 uA)
Voltage (1% of Vmax + 1 count)
Current (1% of Imax + 1 count)
3
Voltage (0.02% of Vmax)
Current (0.03% of Imax)
Voltage (0.015% of Vmax/°C)
Current (0.02% of Imax/°C)
Control Resolution
(0.02% of V max)
warm-up.
7-6
0-7 V
0-6 A
42 W
2.7 mV
0.85 mA
2.7 mV
0.85 mA
0.08 V
0.07 A
1.4 mV
1.8 mA
4
1.05 mV
1.2 mA
1.4mV
Features and Specifications
Electrical Specifications
15-4 20-3 30-2
0-15 V 0-20 V 0-30 V
0-4 A 0-3 A 0-2 A
60 W 60 W 60 W
3.5 mV 4 mV 5 mV
0.65 mA 0.55 mA 0.45 mA
3.5 mV 4 mV 5 mV
0.65 mA 0.55 mA 0.45 mA
0.25 V 0.3 V 0.4 V
0.05 A 0.04 A 0.03 A
3 mV 4 mV 6 mV
1.2 mA 0.9 mA 0.6 mA
2.25 mV 3 mV 4.5 mV
0.8 mA 0.6 mA 0.4 mA
3mV 4mV 6mV
15
