Chapter 5: Each product feature

SOD14C : Standard Camera

e-42
SOD14C
Model Name
NTSC STANDARD
Broadcasting System
1/4 "SUPER HAD IT CCD
Imaging Device
510(H) x 492(V)
Effective Pixels S
Internal
Synchronization
H :330 TV Lines, V: 350 TV Lines
Resolution
VBS 1.0Vp-p(75ohms composite)
Signal Output
≤ 48 dB
S/N Ratio
Minimum Scene Illumination 2lux(F2.0, 50 IRE)
Gamma Correction 0.45
Lens Focal Length (f) : 3.8mm, Aperture Ratio (F) : 2.0
Auto Exposure Electronic Shutter lris
Audio -40dB Condenser Microphone Inclusion
I/O Connectors Modular jack (RJ-11)
Operating Temperature -10 ~ +50 °C
Power Source DC 12V
Power Consumption Approx. 2W
57(W) x 47.2(H) x 100.5(L)
Dimensions
150g
Weight

SMM-PIRCAM : PIR Camera

SMM-PIRCAM
Model Name
NTSC STANDARD
Broadcasting System
1/4'' SUPER HAD IT CCD
Imaging Device
510(H) x 492(V)
Effective Pixels
Internal
Synchronization
330 TV Lines(H), 350 TV Lines(V)
Resolution
VBS 1.0Vp-p(75ohms composite)
Signal Output
≤ 48 dB
S/N Ratio
2 lux(F2.0, 50 IRE)
Minimum Scene Illumination
Gamma Correction 0.45
Lens Focal Length (f) : 3.8mm, F Number : 2.0
Auto Exposure Electronic Shutter lris
Mounthy height : 1.5m to 3m (5ft to 10ft)
Warm-Up Period :Max. 50 seconds
Spectral Response : 5 to 14 um
PIR Sensor Sensitivity : 4860(V/W)
Detectivity : 1.5 x 10 8 cm Hz
Sensor : Off/On
Alarm LED : Off/On (0.3 to 2 second)
Alarm Output : NC (350V/130mA)
-40 dB Condenser Microphone Inclusion
Audio
Modular jack (RJ-11)
I/O Connectors
-10 ~ +50 °C
Operating Temperature
DC 12V (Camera & Sensor from Monitor)
Power Source
DC 12V (External Power Supplier)
Approx. 2W
Power Consumption
40(W) x 69.5(H) x 115(L) mm
Dimensions
About 200g
Weight
2/1 /W
e-43
