Page 1: Instructions For Installation And Use
Instructions for Installation and Use Electric Hood Model HDI90X... -
Page 2: Table Of Contents
CONTENTS RECOMMENDATIONS AND SUGGESTIONS INSTALLATION ELECTRICAL CONNECTION GETTING TO KNOW YOUR COOKER HOOD CARE AND CLEANING AFTER SALES SERVICE GUARANTEE KEY CONTACTS CE marking certifies that this appliance conforms to the following EEC directives:- Low Voltage Equipment Electromagnetic Compatibility Retention of this Instruction Book This Instruction Book must be kept handy for reference as it contains important details on the safe and proper use of the appliance. -
Page 3: Recommendations And Suggestions
• After having removed the packaging, check the condition of the appliance, if in any doubt, do not use and contact Hotpoint Service (see Key Contacts, back page). • The minimum safety distance between the hob and the extractor hood is 650 mm. -
Page 4: Installation
INSTALLATION Dimensions... - Page 5 INSTALLATION Components Ref. Qty Product Components Hood Body, complete with: Controls, Light, Blower, Filters Telescopic Chimney comprising: Upper Section Lower Section Telescopic frame complete with extractor, consisting of: 7.1a Upper Frame 7.1b Lower Frame Right Air Outlet Grill Left Air Outlet Grill Reducer Flange ø...
- Page 6 INSTALLATION Drilling the Ceiling/shelf and fixing the frame DRILLING THE CEILING / SUPPORT SHELF • Use a plumb line to mark the centre of the hob on the ceiling/support shelf. • Place the drilling template 21 provided on the ceiling/support shelf, making sure that the template is in the correct position by lining up the axes of the template with those of the hob.
- Page 7 INSTALLATION FIXING THE FRAME Before fixing, seperate the Upper section 2.1 and the Lower section 2.2 from the frame by unscrewing the screws 12c. Then seperate the two sections of the frame (Upper and Lower) by unscrewing the 8 side screws. Fix the Fixing Part of the Upper Chimney 26 to the hanging kit using the 2 screws 12w (M3 x 8).
-
Page 8: Ducted Version Air Exhaust System
INSTALLATION DUCTED VERSION AIR EXHAUST SYSTEM When installing the ducted version, connect the hood to the chimney using either a flexible or rigid pipe ø 150 or 120 mm, the choice of which is left to the installer. • To install a ø 120 mm air exhaust connection, insert the reducer flange 9 on the hood body outlet. -
Page 9: Electrical Connections
INSTALLATION Before fixing the hood body to the frame: • Remove the grease filters from the hood body. • Remove any activated charcoal filters. • From below, use the 4 screws 12f (M6 x 10) provided, to fix the hood body to the frame. •... -
Page 10: Cord Clamp
WARNING: This appliance MUST be earthed. Connect to a 230 - 240V A.C. Supply only. • Connection to the electricity supply should be made via a properly earthed, readily accessible wall socket which is adjacent to and not more than 1.25m away from the appliance and capable of electrical isolation. -
Page 11: Getting To Know Your Cooker Hood
GETTING TO KNOW YOUR COOKER HOOD The Controls Light Switches the lighting system on and off. Motor Switches the extractor motor off and on at low speed. Used to provide a continuous and silent air change in the presence of light cooking vapours. Speed Reduces the operating speed. -
Page 12: Care And Cleaning
CARE AND CLEANING Before cleaning your cooker hood or carry out any maintenance, switch off and remove the plug from the socket to disconnect it from the electricity supply. The filters must be cleaned every 2 months of operation, or more frequently with heavy usage, and can be washed in a dishwasher. - Page 13 NOTES...
-
Page 14: After Sales Service
Hotpoint appliance than us - the manufacturer" As part of our commitment to you, all Hotpoint appliances have the added benefit of a fully inclusive parts and labour guarantee for the first 12 months. In addition to this you also have the advantage of free replacement parts for the first 5 years when fitted by a Hotpoint engineer. -
Page 15: Guarantee
All Hotpoint appliances carry a fully inclusive 12 month parts and labour guarantee as well as free replacement parts for the first 5 years (except microwaves, selected integrated appliances and cooker hoods, which have a one year guarantee) provided that they are fitted by a Hotpoint engineer. -
Page 16: Key Contacts
Over 1200 trained specialists, directly employed by us, ensure that you can have complete confidence in both the appliances and services we offer. Repair Service and Information Desk (Open 8 to 8 Mon - Fri, 8 to 6 Sat, 10 to 4 Sun & Bank Holidays) Note: Our operators will require the following information: (Open 8-30 to 5-30 Mon - Fri &...
