Frigidaire Home Comfort FRS22PYS1 Features page 2

Frigidaire Baseline
Model Numbers
System Model Number
Indoor Unit Part Number
Outdoor Unit Part Number
1
Performance
BTU (Cool)
BTU (Heat Pump)
Cooling Area (Sq. Ft.)
SEER (Air Conditioner)
HSPF (Heat Pump)
Inverter Technology
Electrical
Volts
Amps (Cool) Indoor/Outdoor
Watts (Cool) Indoor/Outdoor
Amps (Heat) Indoor/Outdoor
Watts (Heat) Indoor/Outdoor
Fuse (Amps) Indoor/Outdoor
Features
Controls
Fan Speeds (Cool/Fan/Heat)
Low Voltage Start-Up
Turbo Fan
Auto Fan
Energy Saver
Sleep Mode
24 Hour On/Off Timer
Remote Control
Air CFM (High/Med/Low) Indoor
Air Direction Control (Vert. / Horz.)
Air Discharge (Full-Width)
Filter Type
Filter Access
Air Direction Control - Horizontal
Air Direction Control - Vertical
dB (Indoor) (High/Med/Low)
dB (Outdoor)
Warranty
2
Included Accessories
Drain Kit (Outdoor Unit)
Installation Plate (Indoor Unit)
Line Set (Indoor Unit)
Remote Holder (Indoor Unit)
Certifications
ENERGY STAR®
Performance
Specifications
Refrigerant
Shipping Weight (Approx.)
Includes 16.4 ft. line set.
1
Warranty 5 year sealed system / 1 year full parts and labor.
2
USA 10200 David Taylor Drive Charlotte, NC 28262
• •
CANADA 5855 Terry Fox Way Mississauga, ON L5V 3E4
• •
FRS22PYS1 07/10
FRS22PYS1
FRS22PYW2
FRS22PYC2
21,500 C
26,600
1,430
18
10.2
Yes
230 / 208
0.5 / 7.9
38 / 1,835 (320-2,530)
0.5 / 12.3
38 / 2,800 (340-2,800)
3.15 / 25
Ready-Select™ Controls
4 / 3 / 4
Yes
Yes
Yes
Yes
Yes
Yes
A
Full-Function
276 / 242 / 107
Yes / Yes
Bottom
Antimicrobial Mesh
Slide-Out
Manual
Swing
44 / 40 / 35
56
Yes
Yes
Yes
Yes
Yes
Yes
ARI
R410a
132
1-800-FRIGIDAIRE frigidaire.com
• •
1-800-265-8352 frigidaire.ca
• •
© 2010 Electrolux Home Products, Inc.
FRS22PYS1 Ductless Mini-Split Air Conditioner / Heat Pump
FRS22PYW2
C
FRS22PYC2
NOTE: For planning purposes only. Always consult local and
national electric codes. Refer to Product Installation Guide for
detailed installation instructions on the web at frigidaire.com.
Product Dimensions
Indoor –
A - Height
B - Width
C - Depth
Max. Wall Thickness
Outdoor –
A - Height
B - Width
C - Depth
Illustration may not represent actual model.
1
All refrigeration and electrical work must be performed by a certified and licensed
refrigeration technician for full parts and labor warranty validation. Insulated line sets
and control wires are required and available for Frigidaire split systems in 16.4 ft.
length. Each line set is equipped with flare nuts on both ends. Each system requires
one line set for each indoor unit installed.
Home Comfort
B
Indoor
1
B
Outdoor
1
12-7/16"
39-11/16"
8-7/8"
18"
31-1/8"
36-1/4"
14-5/8"
Accessories information available
on the web at frigidaire.com
Printed in the U.S.A.
A
Specifications
subject to change.
