Owners &
Freestanding Woodstove
Installation Manual
MODEL:
H200
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
918-427
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
05/25/06
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY H200
Summary of Contents for HAMPTON BAY H200
- Page 1 Owners & Freestanding Woodstove Installation Manual MODEL: H200 Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 918-427 FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4...
- Page 2 fi re offi cials, or authority having jurisdiction about restrictions and installation inspection requirements in your area. The authority having jurisdiction should be consulted before installation to determine the need to obtain a permit. Hampton H200 Cast Freestanding Woodstove...
-
Page 3: Table Of Contents
TABLE OF CONTENTS OPERATING INSTRUCTIONS SAFETY LABEL Operating Instructions ..........20 Safety Label for H200 ............4 Fan Operation .............20 First Fire ..............20 INSTALLATION Safety Guidelines And Warnings .........21 Draft Control ..............21 Unit Dimensions ............5 Ash Drawer Kit Installation ..........22 Pre-installation Assembly ..........6 Ash Disposal ...............23... -
Page 4: Safety Label
DO NOT REMOVE THIS LABEL LISTED SPACE HEATER, SOLID FUEL TYPE, ALSO SUITABLE FOR MOBILE HOME INSTALLATION MODEL: HAMPTON CAST FREESTANDING WOOD STOVE - H200 TESTED TO: UL 1482 / ULC S627 REPORT NO: 219-S-09-2 INSTALL AND USE ONLY IN ACCORDANCE WITH THE MANUFACTURER'S INSTALLATION AND OPERATING INSTRUCTIONS. -
Page 5: Installation
INSTALLATION UNIT DIMENSIONS Hampton H200 Cast Freestanding Woodstove... -
Page 6: Pre-Installation Assembly
1) Loosen the bolts that secure the elbow to the unit. Ensure elbow does not fall off. 2) Bend the tabs on the rear heat shield inwards 90 degrees. Draft Control Lever Bend tabs inwards 90 degrees. Hampton H200 Cast Freestanding Woodstove... -
Page 7: Residential Installation
Side Shelves Add to the traditional look of the stove and double as a warming area for your cookstove creations. Ash Drawer Adding the ash drawer will allow for easier removal and transport of ashes. Hampton H200 Cast Freestanding Woodstove... -
Page 8: Minimum Clearance To Combustible Materials
"C" Vent single wall pipe is not approved for Mobile Home installations (refer to Mobile Home Instructions). Unit (with Heat Shield) From Unit From From Flue Center-Line Corner H200 15" (381mm) 10" (254 mm) 9" (228mm) 27" (686mm) 12-1/8" (308mm) 15-7/8" (381mm) Hampton H200 Cast Freestanding Woodstove... -
Page 9: Minimum Alcove Clearance To Combustible Materials
15" (381 mm) max. 9" (228 mm) Note: Floor Protection must extend 2" (50mm) Min. Mantel Height (from fi nished fl oor): 48" (1219 mm) Max. Mantel Depth: 12" (305 mm) to each side of the elbow. Hampton H200 Cast Freestanding Woodstove... -
Page 10: Floor Protection
8" (203 mm) 45" 8" (203 mm) (1143 mm) (1143 mm) (1143 mm) (1143 mm) Minimum Overall Width (X) of Floor Protector for all installations: H200 36" (914 mm) - US 40" (1016 mm) - Canada Hampton H200 Cast Freestanding Woodstove... -
Page 11: Step-By-Step Chimney And Connector Installation
5) Place the storm collar over the fl ashing, sealing the joints with a silicone caulking. 6) Fasten the raincap with spark screens (if required) to the top of your chimney. Hampton H200 Cast Freestanding Woodstove... -
Page 12: Masonry Chimney
There are listed kits available to connect a stove to a masonry fi replace. The kit is an adapter that is installed at the location of the fi replace damper. The existing damper may have to be removed to allow installation. Hampton H200 Cast Freestanding Woodstove... -
Page 13: Combustible Wall Chimney Connector Pass-Throughs
Cover opening with and support chimney section on both sides with 24 gage minimum sheet metal supports. See that the supports are fastened securely to wall surfaces on all sides. Make sure fasteners used to secure chimney fl ue liner. Hampton H200 Cast Freestanding Woodstove... -
Page 14: Recommended Heights For Woodstove Flue
23.0 20.5 25.5 8000-9000 16.0 17.0 18.5 20.0 24.0 21.0 26.5 9000-10000 16.5 17.5 19.0 20.5 24.5 22.0 27.0 NOTE: No more than two offsets (four elbows) allowed. Two 45 elbows equal one 90 elbow. Hampton H200 Cast Freestanding Woodstove... -
Page 15: Mobile Home Installation
11) WARNING: DO NOT INSTALL IN A SLEEP- ING ROOM OF A MOBILE HOME. 12) Use silicone to create an effective vapour barrier at the location where the chimney or other component penetrates to the exterior of the structure. Hampton H200 Cast Freestanding Woodstove... -
Page 16: Listed Components For Mobile Home Installation
INSTALLATION LISTED COMPONENTS FOR MOBILE HOME INSTALLATION The Hampton H200 Cast Freestanding unit is approved for installation in a Mobile Home if one of the following pipe systems is used. U.S. Installation* AMERI-TECHS Canadian Installations* Qty.Part # Description 6DCC Connector... -
Page 17: Brick Installation
3) Pull door down and lift out to remove. Bottom of door lifts right out. Spring Lever Optional Ash Plug shown. Bottom part of door fi ts into slot. Hampton H200 Cast Freestanding Woodstove... -
Page 18: Optional Blower/Fan Installation
INSTALLATION An optional blower is available for the Hampton OPTIONAL BLOWER/FAN INSTALLATION H200. The blower is factory assembled, wired and ready for attachment to the stove. 1) Remove fan cover plate from back shield 4) Hook fan over the bolts. -
Page 19: Optional Side Shelf Installation
Underside of Left Hand Side Shelf Shown. when the stove top is put back in place. Gusset Side Casting Front Casting Left side of stove shown. Left Bracket 5) Place top back on stove. Bracket Cut-Out 3) Remove stove top. Hampton H200 Cast Freestanding Woodstove... -
Page 20: Operating Instructions
12) Before opening your door to reload, open open for too long. draft fully for approximately 10 to 15 seconds until fi re has been re-established. This will minimize any smoking. Hampton H200 Cast Freestanding Woodstove... -
Page 21: Safety Guidelines And Warnings
11) Open the draft control fully for 10 to 15 seconds prior to slowly opening the door when refuelling the fi re. 12) Do not connect your unit to any air distribu- tion duct. Hampton H200 Cast Freestanding Woodstove... -
Page 22: Ash Drawer Kit Installation
6) Push the ash plug into the hole inside the fi rebox and re-install the on the underside of the fi rebox) by removing the 2 nuts and bolts bricks and andirons. holding the 2 plates together from underneath the stove. Ash Plug Hampton H200 Cast Freestanding Woodstove... -
Page 23: Ash Disposal
fi re. 3) To remove the drawer, slide it out. When the drawer is completely out, slide the cover plate over the ash drawer and carry away. Pull out Ash Drawer Hampton H200 Cast Freestanding Woodstove... -
Page 24: Maintenance
fi re. WARNING: Things to remember in case of a chimney fi re: 1. Close all draft and damper controls. 2. CALL THE FIRE DEPARTMENT. Glass Retainer Hampton H200 Cast Freestanding Woodstove... -
Page 25: Front Door Gasket
Use the 3/16" allen key enclosed in the packaged manual to make this adjustment. Spacer Front of Bracket Handle Hex Head Lock Bolt Washer Remove spacer washers behind screws. Allen Key Hampton H200 Cast Freestanding Woodstove... -
Page 26: Parts List
21) 200-120 FIREBOX INNER 22) 200-217 BRACKET HINGE 23) 200-361 FRONT VENTS CHARCOAL GREY 200-365 FRONT VENTS TIMBERLINE BROWN 24) 200-381 FRONT SKIRT CHARCOAL GREY 200-385 FRONT SKIRT TIMBERLINE BROWN 25) 220-042 SKIRT BRACKET (X2) Hampton H200 Cast Freestanding Woodstove... - Page 27 PARTS LIST Hampton H200 Cast Freestanding Woodstove...
-
Page 28: Door Assembly
11) 948-153 DOOR HANDLE 12) 904-018 1/4 FLAT WASHER x 5/8 O.D. 13) 904-525 1/4 LOCK WASHER 14) 904-751 1/4-20 x 4 1/2 HEX HEAD 15) 948-155 HINGE PIN 16) 948-163 CANE BOLT LATCH (LH) Hampton H200 Cast Freestanding Woodstove... -
Page 29: Ash Drawer Assembly
H200 ASH DRAWER ASSEMBLY PART# DESCRIPTION 200-911 ASH DRAWER PACKAGE 1) 942-110 ASH PLUG 2) 936-236 1/2" ROPE GASKET 3) 200-232 ASH DRAWER GUIDE RIGHT 4) 200-231 ASH DRAWER GUIDE LEFT 5) 820-249 ASH PLUG TOOL HANDLE Hampton H200 Cast Freestanding Woodstove... -
Page 30: Fan Assembly
1) 220-026 FAN HOUSING FRONT 2) 220-022 FAN HOUSING BOTTOM 3) 220-036 SENSOR MOUNT 4) 200-227 FAN BRACKET RIGHT HAND 5) 200-228 FAN BRACKET LEFT HAND 6) 200-229 FAN HOUSING BACK 7) 910-157 8) 910-142 THERMODISC Hampton H200 Cast Freestanding Woodstove... -
Page 31: Warranty
The Warranty: Limited Lifetime H200: Firebox castings and stainless steel baffl es on all Hampton Wood burning Appliances are covered against manufacturer defects for a period of three (3) years parts and subsidized labour* and a further two (2) years, parts only. - Page 32 Hampton fi replace products are designed with reliability and simplicity in mind. In addition, our internal Quality Assurance Team carefully inspects each unit thoroughly before it leaves our door. FPI Fireplace Products International Ltd. is pleased to extend this Limited Lifetime Warranty to the original purchaser of a Hampton Product.
