- Page 1 ® HD Digital Signage Player E X T - H D - D S P Q U I C K S T A R T G U I D E www.gefen.com...
- Page 2 Chatsworth, CA 91311 dsp@gefen.com www.gefen.com Notice Gefen, LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. ® HDMI , the HDMI Logo, and High-Defi nition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing in the United States and other countries.
-
Page 3: Quick Start Guide
(1) User Manual* (1) Quick Start Guide (This document) *The full user manual can be downloaded from: http://www.gefen.com/signage/player/manuals NOTE: If any of the preceding items are missing please contact your Digital Signage Player (DSP) sales representative immediately. The following items are necessary to complete the setup procedures, but are not included in the package: (1) HDMI-compliant High Defi... - Page 4 Rev 8 CONNECTING THE HD DIGITAL SIGNAGE PLAYER DIGITAL (HDMI) ANALOG SINGLE CONNECTOR FOR A/V VGA + EXTERNAL L/R AUDIO Connect the included HDMI cable to the Connect VGA and external L/R audio HD Digital Signage Player at the rear cables to the HD Digital Signage Player panel.
-
Page 5: Power On/Off Procedure
POWER ON/OFF PROCEDURE Due to the nature of common power fl uctuations from AC power sources Gefen recommends the following powering on/off procedures. The HD Digital Signage Player contains sensitive memory and electronic components that may be damaged if improper handling and connection precautions are not followed. - Page 6 NOTE: This page can also be reached from the support tab of the HD Digital Signage Player product page. Log in to the Gefen website: If an account has already been created, enter this information. If no user account has been created, please use the Create New Account link at the bottom of the page.
- Page 7 Click to register additional HD Digital Signage Player units. To create a new user with the Gefen DSP Server Pro software: Click on the Create User option in the web page’s navigation menu. Follow the instructions displayed on the screen.
- Page 8 Rev 8 NOTES...
- Page 9 Rev 8 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefen.com support@gefen.com dsp@gefen.com...
