Instruction Manual
1.8in USB to Micro SATA Hard Drive Enclosure
SAT1810U2
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 05/11/2011
Advertisement
Table of Contents
Related Manuals for StarTech.com SAT1810U2
Summary of Contents for StarTech.com SAT1810U2
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 05/11/2011...
- Page 2 Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges...
-
Page 3: Table Of Contents
Table of Contents Introduction ................................1 Packaging Contents ..........................1 System Requirements ..........................1 Installation................................2 Hardware Installation ..........................2 Driver Installation ............................3 Using the Enclosure ............................4 Specifications ..............................5 Technical Support ............................6 Warranty Information ............................6 Instruction Manual... -
Page 4: Introduction
Introduction The StarTech.com 1.8” USB 2.0 to Micro SATA external hard drive enclosure allows you to turn a 1.8” Micro SATA hard drive or SSD into a portable external storage solution. Connected through USB 2.0, this sturdy yet lightweight enclosure offers a cost-effective way to create an ultra portable storage solution that is powered by USB, eliminating the need for additional power adapters. -
Page 5: Installation
Installation WARNING: Hard drives require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Hardware Installation 1. Remove the small screw from the rear panel of the enclosure. Power/Activity LED Rear Panel screw USB mini-B... -
Page 6: Driver Installation
4. Place the drive into the tray and then slide the drive onto the connector. 5. Replace the top cover. The plastic pull tab may be removed, if desired. Pull Tab 6. Replace the screw in the rear panel. 7. Connect the USB cable from the enclosure to the computer system. Driver Installation No driver installation is required for any operating system that supports USB, as this enclosure uses native drivers that are already installed. -
Page 7: Using The Enclosure
Using the Enclosure Windows 2000/XP/Server 2003Vista/Server 2008 R2/7 If you are using a brand new hard drive that does not contain any data, then you will first need to prepare the hard drive for use. From the main desktop, right-click on “My Computer” (“Computer”... -
Page 8: Specifications
Specifications Bus Interface USB 2.0 Chipset ID Sunplus SPIF301 Connectors 1 x USB mini-B LEDs 1 x Power/Activity Maximum Data Transfer Rate USB 2.0: 480Mbps 1.8” Micro SATA HDD/SSD, with height Hard Drive Compatibility up to 8mm Operating Temperature 0°C ~ 60°C (32°F ~ 140°F) Storage Temperature -20°C ~ 85°C (-4°F ~ 185°F) Humidity... -
Page 9: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 10 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
