Do you have a question about the Perfectemp PT4 and is the answer not in the manual?

Questions and answers

Summary of Contents for PoolFact Industries Perfectemp PT4

  • Page 1 Swimming Pool ® Heat Pump CE OWNER’S MANUAL Models PT4, PT6, and PT8 9900276 This manual should be maintained in legible condition and kept adjacent to the heat pump or in a safe place for future use. For additional information call: (800) 375-7378...
  • Page 2 PRODUCT SAFETY SIGNS AND LABELS Recognize this symbol in the manual as an indication of important safety information! This manual, as well as the pool heat pump itself, contains CE-approved product safety signs and labels. Please read these signs and labels, as they convey important safety information about hazards that may be potentially present in and around the heat pump.
  • Page 3: Table Of Contents

    Perfectemp Swimming Pool Heat Pump ® OWNER’S MANUAL CE CONTENTS Introduction............. 1 I.
  • Page 4: Introduction

    Introduction This pool heat pump is an electromechanical machine that incorporates a pressurized refrigerant gas in a sealed system. ONLY trained and qualified service personnel are authorized to install or service this equipment. Without proper training and knowledge of such equipment, any attempt to install or service the unit could result in serious injury or even death.
  • Page 5: Electrical Connections

    Situate the pool heat pump carefully to minimize installation costs while providing maximum efficiency of operation, and to allow adequate service access, as follows: • For unrestricted air intake and service access, position each side of the unit at least 1 ft from walls, pipes and other obstructions.
  • Page 6: Controls And Indicator Lamps

    Water connections from the heat pump to the main return line can be PVC pipe or flexible pipe approved for the purpose and, in either case, should be at least equal in size to the main pool/spa circulation piping. 4. In cold weather (freeze zone) areas, shutoff valves (ball or gate type) must be installed at the heat pump inlet and outlet to facilitate service and cold weather drain-down.
  • Page 7: System Start-Up

    Indicator Lamps: There are 6 indicator lamps located on the unit control panel: Control panel Indicator lamps When this lamp is lit, unit requires service. When any combination of these 5 lamps is lit, operation is normal. • (amber lamp): When lit, indicates power is applied to the unit. Power NOTE: The heat pump will not run when the Remote position is selected and there is no remote control system attached.
  • Page 8: Summer Shutdown

    4.Allow the heat pump to operate for a few minutes to stabilize operating pressures and to allow various Spa thermostat component temperatures to normalize. 5. Verify that the discharge air temperature is Pool/Spa selector approximately 5° C cooler than the air entering the switch unit.
  • Page 9: Freeze Protection

    VII. Freeze Protection If the heat pump is installed in a location subject to freezing conditions, it is important to protect the water circuit from freezing, just as should be done for the pump and filter. System Drain-Down 1. Turn the heat pump circuit breaker or disconnect switch to OFF. 2.
  • Page 10: Troubleshooting

    C. Unplug Condensation Drain Holes - The heat pump extracts humidity from the air as it passes through the coil, similar to the way a cold drink outside “sweats” on a hot day. This con- densation drains from the bottom of the unit. 1.
  • Page 11: Service Call Verification

    B. UNIT IS NOT RUNNING • Is the control panel lamp ON? If not, the circuit breaker may be shut OFF or tripped. Power Reset the breaker by switching it OFF, then back ON. Verify that the breaker is set and operating properly before calling for service.
  • Page 12: Plumbing Diagrams

    Plumbing Diagrams Water In Water Out Filter (from pool (to pool or spa) or spa) For systems with pumps of <1490 joules/sec (2 HP), that pump <300 l/m, no external bypass is required. Connections are 5 cm unions. Plumb the heat pump after the filter and before any chlorinators. Water In Water Out (from pool...
