Installation and
Maintenance Manual
Logalux SM300/1
Logalux SM400/1
Solar and High Capacity -
Domestic Hot Water
Documentation for the con-
tractor
Please read carefully prior
to installation and mainte-
nance
When the anode rod is not profes-
sionally and annually maintained, the
tank will lose its warranty. Annual
service records must be maintained
and shown in case of a warranty
claim along with an original proof of
purchase. Refer to page 23 to 27 for
annual maintenance instructions to
maintain tank warranty.
