- Page 1 Stainless Steel Gas Grill USE AND CARE GUIDE MODEL NO.: 720-0247-LP ® FOR OUTDOOR USE ONLY PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION ONE SECTION FIVE Safety Instructions…………………………1~5 Using the Side Burner…………………… Placement of the grill………………………5 Care & Maintenance ………………. Care & Maintenance of Side Burner….. SECTION TWO Trouble Shooting………………………… Installation of Side Shelves .………..….….6 19~21 Installation of Push Bar…………………….7 SECTION SIX Installation of Spice Tray and Diving Shelf Exploded View…………………………….. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS ***** WARNING ***** FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open Lid. 4. If odor continues, immediately call your gas supplier or your fire department. FOR YOUR SAFETY 1. - Page 4 SAFETY INSTRUCTIONS RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS WARNING Do not try lighting this appliance without first reading the “LIGHTING INSTRUCTIONS” section of this manual. DO NOT USE ALUMINUM FOIL TO LINE THE GRILL This can severely upset RACKS OR GRILL BOTTOM. combustion airflow or trap excessive heat in the control area.
- Page 5 SAFETY INSTRUCTIONS RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS WARNING: Always keep your face and body as far away from the burner as possible when lighting. WARNING: IMPORTANT! BEFORE LIGHTING… Inspect the gas supply hose prior to turning the gas “ON”. If there is evidence of cuts, wear, or abrasion, it must be replaced prior to use.
- Page 6 SAFETY INSTRUCTIONS CHILDREN SHOULD NOT BE LEFT ALONE OR TESTED IN ACCORDANCE WITH ANSI Z21.58b UNATTENDED IN AN AREA WHERE THE GRILL IS LATEST STANDARD 1.6b-2002 BEING USED. NEVER ALLOW THEM TO SIT, STANDARD FOR OUTDOOR COOKING GAS STAND OR PLAY ON OR AROUND THE GRILL AT APPLIANCES.
-
Page 7: Placement Of The Grill
SAFETY INSTRUCTIONS When using the grill, do not touch the grill rack, that produce the spraying action could, in the burner grate or immediate surroundings as presence of heat, ignite or cause metal parts to these areas become extremely hot and could corrode. -
Page 8: Installation Of Side Shelves
INSTALLATION OF SIDE SHELVES (OPTIONAL) The screws used to attached the side shelves are already screwed into the two side panels of the grill. Remove the screws from the side panel and align with the holes in the left side panel. Then install the left shelf as shown in the figure below. -
Page 9: Installation Of Push Bar
INSTALLATION OF PUSH BAR The screws used to attach the push bar are already screwed into the one shelf. Remove the screws from the one side shelf, align with the holes in the push bar, and then re-screw into the holes on the one shelf of the grill. Press the cap against the ends of the push bar, and gently tap them into place.. -
Page 10: Installation Of Spice Tray And Diving Shelf
INSTALLATION OF SPICE TRAY AND DIVIDING SHELF Put the spice tray into the hook on the right door. Place the spice tray inside the right door. Assembly steps as shown in the figure below. Place the dividing shelf inside the right door. -
Page 11: Installation Of Battery
INSTALLATION OF BATTERY In order to install the battery, remove the ignition button housing. Repeat the ignition button housing after battery is installed. Please keep the positive pole facing toward you. Tight the ignition button after installed the battery. -
Page 12: Installation Of Rotisserie Kit
INSTALLATION OF ROTISSERIE KIT The screws for rotisserie mount are already screwed into the rotisserie kit. Take off the screw and install the rotisserie motor mount, then assemble the rotisserie skewers as shown in the figure below. -
Page 13: Installation Of Propane Tank
INSTALLATION OF PROPANE TANK • With hand attach regulator to the propane tank by turning the regulator handle clockwise until tight as shown in figure below. • LP gas cylinder must be fitted with a listed overfull prevention device (OPD). CAUTION! ASSEBLY TO PROPANE TANK. -
Page 14: Slide-Out Tray Locking System
SLIDE-OUT TRAY LOCKING SYSTEM To lock and unlock the liquid propane gas cylinder tray, press the gas cylinder tray’s top button A to lock. Press the side button B to unlock. TO MATCH LIGHT THE GRILL If the burner will not light after several attempts then the burner can be match lit. If you’ve just attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. -
Page 15: Gas Hook-Up
GAS HOOK-UP Only the pressure regulator and hose assembly LP Gas Cylinder must be fitted with Overfill supplied with the grill should be used. Any Protection Device (OPD). replacement pressure, regulator and hose LP GAS HOOK-UP: assembly must be specified by the grill Ensure that the black plastic grommets on the LP manufacturer. -
Page 16: Leak Testing
LEAK TESTING to shipment; however, variations in the local gas GENERAL Although all gas connections on the grill are leak supply may make it necessary to adjust the burners, tested at the factory prior to shipment, a the flames of the burners Should be visually complete tightness check... -
Page 17: Installer Final Check
INSTALLER FINAL CHECK Specified clearance maintained 24” from Unit tested and free of leaks. combustibles. User informed of gas supply shut off valve All internal packaging removed. location. Knobs turn freely. Burners are tight and sitting properly on PLEASE RETAIN THESE INSTRUCTIONS FOR orifices. -
Page 18: Operating Instructions
OPERATING INSTRUCTIONS DO NOT LEAVE THE GRILL UNATTENDED WHILE It may also be necessary to wrap the food with COOKING. butchers string (never use nylon or plastic string) to secure any loose portions. Once the food is secure USING ROTISSERIE BURNER: insert the skewer into the motor. -
Page 19: Lighting Instructions
LIGHTING INSTRUCTIONS WARNING: IMPORTANT! these conditions exist call our customer service line. If the flame is yellow, it indicates insufficient BEFORE LIGHTING… air. If the flame is noisy and tends to lift away Inspect the gas supply hose prior to turning the from the burner, it indicates too much air. -
Page 20: Using The Side Burner
USING THE SIDE BURNER control knob counterclockwise to the “HI” position. If WARNING: IMPORTANT! the burner does not light, turn the control knob to USING THE SIDE BURNER: “OFF”. If the smell of gas is detected and the igniter Inspect the gas supply hose prior to turning the is not functioning, immediately turn the control knob gas “ON”. -
Page 21: Care & Maintenance Of Side Burner
CARE & MAINTENANCE OF SIDE BURNER SIDE BURNER CLEANING: SIDE BURNER GRATE: Clean the exterior of the burner with a wire The top burner grate is stainless steel. To avoid brush. Clear any clogged burner ports with a burns do not clean a hot grate. They may be straightened paper clip. -
Page 22: Trouble Shooting
TROUBLE SHOOTING PROBLEM SOLUTION When I light the grill it does not -Make sure you have turn on the gas flame immediately. --Make sure it has spark while you are trying to ignite the burner. --Push in for approximately 5 second before to turn and ignite the grill. - Page 23 Rotisserie motor will not turn --Check the voltage at the outlet. --If an extension cord is required, ensure it is a 16 gauges, grounded cord. --Ensure the on/off switch is on. --Ensure the load does not exceed the 40 pounds operational capacity.
-
Page 24: Exploded View
EXPLODED VIEW 50 0 80 0 10 0... -
Page 25: Parts List
MODEL 720-0247-LP PARTS LIST DESCRIPTION Q’TY REF# DESCRIPTION Warming Rack Lighting, Rod Cooking Grid Lid, Front Cooking Grid With Hole Heat Indicator Flame Tamer Heat Insulating Spacer Sear Burner Handle Assembly, Lid Main Burner Name Plate Rear Burner Rear Baffle, Rear Burner... -
Page 26: Grilling Hints
GRILLING HINTS The doneness of meat, whether rare, medium, or Use a spatula instead of tongs or a fork to turn well done, is affected to a large degree by the the meat, as a spatula will not puncture the thickness of the cut. -
Page 27: Grill Cooking Chart
GRILLING COOKING CHART FOOD WEIGHT OR FLAME APPROXIMATE SPECIAL INSTRUCTIONS THICKNESS SIZE TIME AND TIPS VEGETABLES Slice. with butter margarine. Wrap in heavy-duty foil. Grill, turning occasionally. Fresh: Beets Medium 12 to 20 minutes Grill, turning once. Brush Carrots occasionally with melted butter Turnips or margarine. - Page 28 Lamb Chops & Steaks Rare 1 inch High 10 to 15 minutes Remove excess fat from edge. Slash remaining fat at 2-inch intervals. Grill, turning once. 1-1/2 inch High 14 to 18 minutes Medium 1 inch Medium to 13 to 20 minutes 1-1/2 inch High 18 to 25 minutes...
-
Page 29: Grill Recipe Suggestion
GRILL RECIPE SUGGESTIONS BBQ SALMON 1 20 oz. Can pineapple chunks in juice aluminum foil. Bake covered 25 minutes 2 large salmon steaks drained In medium bowl, combine shrimp on medium with the lid of your BBQ grill 2 tbs. oil and scallops. - Page 30 ½ tsp. salt Bring marinade to boil on the side 1 chicken bouillon cube ½ tsp. celery salt burner in a saucepan. Add remaining 1 can beer for basting sauce ¼ tsp. garlic powder 1/3 c. water and peanut butter. Stir to ½...
-
Page 31: Limited Warranty
Our obligation under this warranty is limited to repair or replacement, at our option, of the product during the warranty period. The extent of any liability of Nexgrill Industries, Inc. under this warranty is limited to repair or replacement. This warranty does not cover normal...
